Getting started

Lactate Scout+ analyzer
· Insertion slot (1)
· Display window
readiness, the blood lactate concentration,
warnings and setting options
· Scroll wheel (3) for easy operation of the
analyser. Scroll up and down to view menu
options. Press the wheel to access the menu
Scrolling: Select option or search
Pressing: Activate/confirm selection or
deactivate/cancel selection
Turn on or off by pressing for 2 seconds
Lactate Scout+ sensor
· Measurement chamber
the collection of the blood sample
· Connecting contacts
completely into the insertion slot of the
measuring device with the black contact
surface facing up
6
for the sensor
(2) for the display of test
(4)
with opening for
(5)
must be inserted
1
2
3
4 5
