NRS Healthcare Stanton M11120 User Instructions

User Instructions
Stanton Raised Toilet Seat Range
M11120 - 2" (50mm) Stanton Raised Toilet Seat with Lid
M11132 - 4" (100mm) Stanton Raised Toilet Seat with Lid
N05266 - 6" (150mm) Stanton Raised Toilet Seat
N05289 - 6" (150mm) Stanton Raised Toilet Seat with Lid
General Safety Warning
Please ensure these instructions are fully
read and understood before installation/ use.
Retain these instructions in a safe place for
future reference.
Intended Use
The Stanton Raised Toilet Seat with is fitted to a
standard toilet bowl and is designed to provide a
secure raised toilet seat surface for those with
reduced mobility.
Contents
Raised Toilet Seat
2 Part Side Brackets (x2)
Unpacking
Check all parts carefully before assembling the
product. Do not assemble if any of the parts are
damaged. Do not assemble if any of the
contents are missing.
Fitting Instructions
1. Assemble the side brackets; Place screw into
threaded section of "L" shaped bracket as
shown in fig 1.
2. Slot bracket into threaded slots in underside
of seat as shown in fig 2 and secure using
screw.
3 - Fitting to the Toilet
(Note: Ensure the toilet to which the seat is
being fitted is safe and secure.)
4 - Lift the existing toilet seat up.
5 - Loosen the two side brackets an equal
amount by turning the screws anti-clockwise
and position the seat on the toilet bowl, ensure
the front lip is outside of the bowl and the seat is
evenly positioned about the bowl (see main
picture)
Fig 1
"L" Bracket
Support
Bracket
Fig 2
Page 1
Maximum
User Weight:
30st
190kg
Seat
Screw
