In accordance with IKA warranty conditions, the warranty
period is 24 months. For claims under the warranty please
contact your local dealer. You may also send the machine
direct to our factory, enclosing the delivery invoice and giv-
ing reasons for the claim. You will be liable for freight costs.
Pump performance curve measured with water:
(Measurements done according DIN 12876-2 with water at 20 °C; pump in a closed-loop circuit).
700
500
300
100
-100
-300
-500
0 5 10
Fig. 15

Warranty

Pump performance curve

15 20 25 30
Q [l/min]
The warranty does not cover worn out parts, nor does it
apply to faults resulting from improper use, insufficient
care or maintenance not carried out in accordance with
the instructions in this operating manual.
4600 rpm
3200 rpm
2000 rpm
35
