Toro 835S Series Installation And Service Instructions Manual

Installation Procedure ____________________________________________________________
To assure maximum performance from your 800S series sprinklers, read these instructions
completely prior to installation or service.
Constructing Swing Joints
1. Construct or provide triple swing joints for each sprinkler as shown in Figure 1. Use PVC or
ABS pipe nipple for the sprinkler connection.
Note: On sites where the possibility of heavy equipment rolling over a sprinkler exists, the
swing joint will flex preventing damage to the lateral or main lines. On a new installation in raw
ground where the sprinklers are to be initially installed above the finished grade and lowered
when new turf is established, the swing joint allows sprinkler repositioning without changing
risers.
2. Flush lines thoroughly prior to installing sprinkler.
3. Apply Teflon™ tape on riser threads (not required on ACME threads). Install sprinkler to the
riser and tighten.
CAUTION: Use only Teflon tape on riser threads. Use of pipe dope or other types of sealing compounds can cause
deterioration of sprinkler body threads.
Connecting Control Wires (Electric Models Only)
1. Route control wires to sprinklers. Provide extra wire at sprinkler to allow for height adjustment. One common wire and station wire
is required for each sprinkler. See Wire Sizing Chart, Table 1 for proper application.
Table 1: Wire Sizing Chart
Voltage AWG mm
23 14/14 2.5/2.5
23 2.5/4.0
14/12
23 14/10 2.5/5.5
23
12/12 4.0/4.0
23 4.0/5.5
12/10
23
12/8 4.0/7.0
23
10/10
5.5/5.5
24 14/14
2.5/2.5
24 14/12 2.5/4.0
24 14/10
2.5/5.5
24
12/12 4.0/4.0
24 12/10 4.0/5.5
24
12/8
4.0/5.5
24
10/10 5.5/5.5
Note: Wire length data provided in Table 1 is the sum
of the station and common wire legs. See example in
Figure 2.
2. Attach control wires to solenoid leads using an
approved waterproof splicing method.
CAUTION: All wire splices and field connections
must be waterproofed to prevent short circuit to
ground and subsequent controller damage.
835S and 855S Series Rotary Sprinklers
Installation & Service Instructions
2
Voltage Drop Circular Mils
4 4100
4 5315
4 7250
4 6530
4 8465
4 11515
4 10400
5 4100
5 5315
5 7250
5 6530
5 8465
5 11515
5 10400
Total Wire Length Between Controller and Sprinkler
1 Sprinkler 2 Sprinklers
6571' 2003 m 3285'
8518' 2596 m 4259'
11619' 3541 m 5809'
10465' 3190 m 5232'
13566' 4135 m 6783'
18454' 5625 m 9227'
16667' 5080 m 8333'
8213' 2503 m 4107'
10647' 3245 m 5324'
14523' 4427 m 7262'
13081' 3987 m 6540'
16957' 5168 m 8479'
23067'
7031 m 11533'
20833' 6350 m 10417'
Figure 2
Total Wire Length = 2190' (668m)
Figure 1
3 Sprinklers
1001 m 2190' 668 m
1298 m 2839' 865 m
1771 m 3873' 1180 m
1595 m 3488' 1063 m
2067 m 4522' 1378 m
1875 m
2812 m 6151'
2540 m 5556' 1693 m
1252 m 2738' 835 m
1623 m 3549' 1082 m
2213 m 4841' 1476 m
1993 m 4360' 1329 m
2584 m 5652' 1723 m
3515 m 7689' 2344 m
3175 m 6944' 2117 m
Station Wire = 1095' (334m)
Common Wire = 1095' (334m)
4 Sprinklers
1643'
501 m
2129' 649 m
886 m
2905'
798 m
2616'
3391' 1034 m
1406 m
4613'
4167' 1270 m
2053' 626 m
2662' 812 m
3631' 1107 m
3270' 997 m
4239' 1292 m
5767' 1758 m
5208' 1581 m
