USB2connect User's Guide
Installing USB2connect
Discharge any static electricity buildup by touching a grounded
metal object (such as the exposed metal parts on the back of your
computer) before handling the USB2connect adapter.
WARNING: Turn
the power cord.
1
After you turn
OFF
open the computer cabinet.
Note: See your computer documentation for specific
instructions on opening your computer cabinet.
2
Locate an unused 32-bit or 64-bit PCI expansion slot and
remove the expansion slot cover. Save the cover screw for use
in Step 4.
Slot Cover
Screw
Expansion
Slot Cover
3
Insert the USB2connect into the PCI expansion slot. Press
down firmly until the card clicks into place.
Note: Some PCI slots may need considerable force to insert
the card completely.
4
power to the computer and disconnect
OFF
your computer and unplug the power cord,
64-bit PCI Slot
32-bit PCI Slot
