Wfly WFT09SII Summary Manual

2.4ghz 1024 / 4096 pcms
Hide thumbs Also See for WFT09SII:
Table of Contents

Advertisement

Quick Links

2.4GHz
1024 / 4096 PCMS
WFT09SII
&WFT09II
SUMMARY MANUAL
Customer service strategy
Safety tips
Precautions
Product features
Product illustration
Product configuration
Functions instruction
Receiver Coding
Model Selectting & Setting
Fail Safe Function
Stick Setting
Thank you for purchasing WFLY products,pls read the instruction before using it.
Shenzhen WFLY Technology Development Co.,Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WFT09SII and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wfly WFT09SII

Summary of Contents for Wfly WFT09SII

  • Page 1 Customer service strategy Safety tips Precautions Product features Product illustration Product configuration Functions instruction Receiver Coding Model Selectting & Setting Fail Safe Function Stick Setting Thank you for purchasing WFLY products,pls read the instruction before using it. Shenzhen WFLY Technology Development Co.,Ltd.

  • Page 2: Terms Of Sale

    5.The terms of after service are limited to products sold in mainland china. Product Usage And Modification Warning 1.WFLY products are limited to model usage under the Provisions of the Radio Act of China. 2.WFLY will take no responsibility for the the modification, adjustment and replacement parts products.

  • Page 3: Safety Tips

    Edit button is very dangerous. Danger e sure to use the specified receiver This product supports only part of the WFLY receiver models, if you use another receiver,this product will not be operated. angerous situation will occur ,fever, fire, electric shock, injury, etc.
  • Page 4 Safety Tips emote control distance will shorter: Antenna fracture can cause remote distance becomes shorter and out of control Warning lease do not use remote control device in following cases: >Other signals interfere. >Over the speeding vehicle . Prohibited >Near station buildings, ship radios and other wireless transmitting station. >Near or over the residential or buildings or pedestrian.
  • Page 5 Safety Prompts (battery selection and installation) Transmitter Battery Selection Caution ransmitter standard input voltage range 9.6V - 12V, the battery can select the following configuration: >Standard AA - 5 # NiMH / 1.2V rechargeable nickel-cadmium batteries, together use with 8 standard battery box equipped by this product. >Standard 3S-12.6V Lithium Battery.

  • Page 6: Products Accessories

    Products Accessories (on the basic of official newest data) WFR09S Lithium buck Neck strap Battery box...

  • Page 7: Product Features

    Improve response speed Increasing the usage distance. Enhances the reliability and robustness of R/C [Two antennas should installed at the angle of 90 for better using.] All WFLY 2.4GHz series receivers are fit on PPM,PCMS1024/PCMS4096 system, equipped with failsafe function.

  • Page 8: Product Illustration

    Product Illustration (WFT09SII/WFR09II) Antenna Buzzer R/F LED Caution LED Power LED Handle Knob VC Knob VB Switch D Switch E knob VA Coach switch TRN switch A switch B Switch F switch C Knob VR Knob VL Neckstrap attachment Elevator/Rudder...
  • Page 9 Auxiliary channel Auxiliary channel Auxiliary channel/+5V Auxiliary channel/+5V Receiver Coding (suitable for WFT09SII / WFT09II) Caution o not coding at following situations: >When other WFLY receivers are coding. >Powered by ESC when connected with motor. >Electromagnetic complicated places:Transformers, high-voltage wires, routers, communication base stations,etc.

  • Page 10: Boot Status

    BOOT Boot Status urn on the power switch,power light shows green lights,LCD shows initial surface) Power LED on Timer Battery voltage Communication mode Battery charge Throttle trim display Elevator trim display Menu key Arrow keys Exit key Enter key Add key Reduce key Timer C Arrow trim display...

  • Page 11: Model Settings

    RF Indicator RF LED off:this situation occur will when the RF SETTING off; Close RF used in editing seting or simulator ,it can save electricity. Boot Warning aused by the Low pressure alarm and Stunt switch alarm open and Throttle Lock status open;...

  • Page 12: Fail-Safe Function

    Fail-Safe Function Warning he importance of Failsafe :reduce the rate of injury when the aircraft lost control. dvice: set failsafe data first before calibration or flight. The information is automatically transferred to the receiver, you do not need to set at every flight.
  • Page 13 Function Instruction/Catalogue (more information please refer to the WFLY official website) HELICOPTER NORMAL SETTING 1.MONITOR Observes status of each channel output. 2.DUAL RATE&EXPONENTAIL.. Action curve adjustment for each channel,changing the feel and sensitivity of each. 3.SERVO REVERSE Set the direction of the positive and negative steering.
  • Page 14 Function Instruction/Catalogue (more information please refer to the WFLY official website) FIXED-WING NORMAL SETTING Regulating flap and aileron linkage 9. FLAPERON Adjust flap total stroke,alone change flap channel,mixing synchronized 10. FLAP TRIM Adjust aileron and aileron differential 11. AIL-DIFF Adjust the elevator and flap-way ,mixing 12.ELEV-FLAP...
  • Page 16 ：0755-2658 1817 ：0755-2658 5126 MAIL ：info@wflysz.com SUPPORT ：http://en.wflysz.com/n_ser vice.htm ：C2 Building,4th Floor, Xiang Li Industrial Park , He Ping Hao Ye Road, Fuyong Street, Bao'an District, Shenzhen City, Guangdong Province, China...
