Xplorer 870

10. DHCP SERVER

The DHCP Server setup entry comes with the following parameters:
Parameters
DHCP/DNS
service
DHCP server
System allocates
address pool
Assign address
pool range
Max Lease Time
Primary DNS server
IP address
Secondary DNS server
IP address
DNS Relay
DNS Relay
Auto discovery
Manual settings
The default configuration for DHCP server is enabled with 32 addresses from
192.168.1.2 to 192.168.1.33 for DHCP clients. While DHCP is enabled, you can
select "System allocates address pool"(The default setting is 32 IP addresses.) or
"Assign address pool range" (To Manually assign IP address range.)
Note: The DNS IP MUST be set to a valid value to enable the DHCP server to deliver the DNS IP
to the host. Consult your ISP for DNS IP address. You may input the secondary DNS IP if there
are two DNS servers in your network.
Description
DHPC parameteres and
DNS server addresses
DHCP Server option
System assigned address pool range.
Beginning and end address
of the pool range.
Maximum lease time for an
IP address in seconds.
Primary DNS server IP address
provided by ISP.
Secondary DNS server IP address
provided by ISP.
DNS Relay settings
For enabling DNS Relay
To find DNS server automatically
IP address for the DNS Rlay
88 88 88 88 88 88 88
Default Value
Enable
Off
2-33
86400
N/A
N/A
Disable
Off
Off
