thomann t.bone Tour Guide Talkback Receiver User Manual

Tour Guide Talkback Receiver

Safety instructions

Intended use
This device is used to receive radio signals and transform them into
acoustic signals. Any other use or use under other operating conditions is
considered to be improper and may result in personal injury or property
damage. No liability will be assumed for damages resulting from improp-
er use.
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of prop-
erly and are not within reach of babies and young children.
Choking hazard! Ensure that children do not detach any small
parts (e.g. knobs or the like) from the unit. They could swallow the pieces
and choke! Never let unattended children use electrical devices.
Interference with other electrical equipment
Using the device near radios or TV sets may cause interference. Then
increase the distance between the devices.
Where to use the product
Never use the product
• in direct sunlight
• in conditions of extreme temperature or humidity
• in extremely dusty or dirty areas
• at locations where the unit can become wet
• near magnetic fields
Features
• Guide system receiver, system component with return channel (switch-
able)
• 20 switchable channels in the UHF range 863 - 865 MHz
• Automatic synchronization of all receivers in a group

Operating elements

1
2
3 4 5
Front view Rear view
Display
Channel change
Mute
Volume value 5
2-way communi-
cation on / Ear-
phone volume
value 4
2-way communi-
cation on
Thomann GmbH • Hans-Thomann-Straße 1 • 96138 Burgebrach • www.thomann.de • info@thomann.de
8
Top view
7
6
Bottom view
9
10
Side view
100 % battery charge level
70 % battery charge level
30 % battery charge level
10 % battery charge level
No signal is received

User manual

This manual contains important information on the safe operation of the
device. Read and follow the safety advice and instructions given. Retain
the manual for future reference. If you pass the device on to others please
include this manual.
Interference with other electrical equipment
Using the device near radios or TV sets may cause interference. Then
increase the distance between the devices.
General handling
• To prevent damage, never use force when operating the switches and
controls.
• Never immerse the appliance in water. Just wipe it with a clean dry
cloth. Do not use liquid cleaners such as benzene, thinners or flamma-
ble cleaning agents.
Keep foreign substances from the unit!
Keep the device away from containers with liquids. Should any liquid get
into the unit, this could lead to its destruction or fire. Be sure not to let
any metal objects into the unit.
Possible hearing damage
When earphones are connected, the unit can produce volume
that may cause temporary or permanent hearing impairment. Do
not operate the device continuously at high volume. Turn down
the volume immediately if background noise or hearing failure should
occur.
• LCD display
• Built-in lithium-polymer battery, micro-USB charging port
• 3.5 mm mini jack socket for earphones
• Built-in microphone for queries
• Including earphone and lanyard
• Not compatible with t.bone Tour Guide Mini transmitters / receivers
1. Antenna
2. LCD display
3. Channel selection / volume down
4. On / off switch / Mute / Calling up setting parameters
5. Channel selection / volume up
6. Earphone connection
7. Switch for 2-way communication
8. Eyelet for lanyard
9. Forced shutdown switch
10. Micro USB charging port
DocID: 463216_16.05.2019
EN
