  • Page 1 IEM 200 R UHF receiver user manual...
  • Page 2 Musikhaus Thomann e.K. Treppendorf 30 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 05.08.2013...

  • Page 3: Table Of Contents

    Table of contents Table of contents General notes............................... 4 Safety instructions............................. 7 Features and scope of delivery......................12 Installation and starting up........................ 14 Components and functions........................ 17 Setting up the receiver......................... 23 Troubleshooting............................28 Technical specifications........................31 8.1 Receiver............................... 31 8.2 Frequency charts..........................

  • Page 4: General Notes

    General notes General notes This user manual contains important information on safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device, include the manual for the next owner.
  • Page 5 General notes Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. CAUTION! This combination of symbol and signal word indicates a possible dangerous situation that can result in minor injury if it is not avoided.
  • Page 6 General notes Warning signs Type of danger Warning – danger zone. UHF receiver...

  • Page 7: Safety Instructions

    Safety instructions Safety instructions Intended use This device is intended to be used for the wireless transmission of audio signals to earplugs. Use the device only as described in this user manual. Any other use or use under other oper‐ ating conditions is considered to be improper and may result in personal injury or property damage.
  • Page 8 Safety instructions DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug.
  • Page 9 Safety instructions CAUTION! Possible hearing impairment The use of earphones at high volume over a longer period of time can cause per‐ manent hearing damage. Adjust the output volume of your audio device to a medium value and use the earphones no longer than about one hour a day.
  • Page 10 Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.
  • Page 11 Safety instructions NOTICE! Possible damage by leaking batteries Leaking batteries can cause permanent damage to the device. Take batteries out of the device if it is not going to be used for a longer period. IEM 200 R...

  • Page 12: Features And Scope Of Delivery

    Features and scope of delivery Features and scope of delivery As part of the UHF wireless system IEM 200, the bodypack receiver IEM 200 R is especially suit‐ able to be used at professional events, on rock stages and in concert halls, theatres and musi‐ cals.
  • Page 13 Features and scope of delivery Device description Item no. Frequency range IEM 200 R 606 MHz 278194 610.250 MHz…629.750 MHz IEM 200 R 710 MHz 278287 714.250 MHz…733.625 MHz IEM 200 R 740 MHz 288289 744.250 MHz…763.625 MHz IEM 200 R 820 MHz 278290 824.250 MHz…843.750 MHz IEM 200 R...

  • Page 14: Installation And Starting Up

    Installation and starting up Installation and starting up Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
  • Page 15 Installation and starting up Inserting batteries into the receiver Make sure that the main switch / volume control (17) of the receiver is in ‘OFF’ position. Simultaneously press on both snap-in locks of the battery compartment at the side and pull it completely out of the receiver.
  • Page 16 Installation and starting up Phone socket for earplugs Drawing and table indicate the pin assignment of a 1/8" TRS mini phone plug for stereo use. Signal (left) Signal (right) Ground, shielding Starting up the system Make sure that both transmitter and receiver are switched off. The transmitter display is dark.

  • Page 17: Components And Functions

    Components and functions Components and functions Front panel of the receiver 16 Flexible antenna. 17 OFF/ON/VOL Main switch and volume control. Turn this knob clockwise past the point of resist‐ ance to turn on the receiver. Turn it further to increase the volume. Turn this knob counter-clockwise to reduce the volume.
  • Page 18 Components and functions 22, 23 + / – Buttons to increase or decrease the currently shown value. 24 Fasteners of the battery compartment for two AA cells (LR6, 1.5 V) or comparable rechargeable batteries. UHF receiver...
  • Page 19 Components and functions Top panel of the receiver 16 Flexible antenna. 17 OFF/ON/VOL Main switch and volume control. Turn this knob clockwise past the point of resist‐ ance to turn the receiver on. Turn it further to increase the volume. Turn this knob counter-clockwise to reduce the volume.
  • Page 20 Components and functions Rear panel of the receiver 16 Flexible antenna. 17 OFF/ON/VOL Main switch and volume control. Turn this knob clockwise past the point of resist‐ ance to turn the receiver on. Turn it further to increase the volume. Turn this knob counter-clockwise to reduce the volume.
  • Page 21 Components and functions Display of the receiver K STEREO Indicates the selected operating mode (stereo or mono). L Radio signal strength indicator (one to five bars). M Indicates that the unit is locked to prevent unintentional operation. N HF Indicates the activated high frequency boost function. O LTD Indicates that the overload protection (dynamic limiter) is turned on, preventing clipping and volume peaks.
  • Page 22 Components and functions R Indicates the frequency that is assigned to the set combination of frequency group and channel. S G: / CH: Indicates the selected frequency group and the set channel. UHF receiver...

  • Page 23: Setting Up The Receiver

    Setting up the receiver Setting up the receiver Opening the menu If the receiver is turned on, keep [SET] pressed for some seconds until the menu appears in the display. Use the [+] / [–] buttons to select a menu item. IEM 200 R...
  • Page 24 Setting up the receiver Selecting frequency group and Select the menu item ‘2. Group/Channel’ . Press [SET]. ‘Setup Group’ appears in the first row of channel the display. Use the [+] / [–] buttons to increase or decrease the displayed value. When the desired value is shown, press [SET] to confirm the setting and to proceed to the channel setting.
  • Page 25 Setting up the receiver Setting the frequency directly As an alternative to selecting the frequency group and channel, you can also adjust the trans‐ mission frequency directly. Select the menu item ‘1. Frequency’ . Press [SET]. ‘Frequency’ appears in the top row of the dis‐ play.
  • Page 26 Setting up the receiver Enabling treble boost Select the menu item ‘4. Hi Freq. Boost’ . Press [SET]. ‘Hi Freq. Boost’ appears in the top row of the display. Use the [+] / [–] buttons to turn the treble boost (increasing the high frequencies) on or off (display shows ‘ON’...
  • Page 27 Setting up the receiver Setting the display contrast Select the menu item ‘7. Contrast’ . Press [SET]. The display shows a symbolic slider. Use the [+] / [–] buttons to change the contrast in a range of –3 and +3. When the display has the desired contrast, press [SET] to confirm the setting and to leave this menu item.

  • Page 28: Troubleshooting

    Troubleshooting Troubleshooting In the following we list a few common problems that may occur during operation. We give you some suggestions for easy troubleshooting: UHF receiver...
  • Page 29 Troubleshooting Symptom Remedy No sound 1. Check the power supply of the transmitter and receiver. 2. Make sure that both transmitter and receiver operate in the same frequency range and that the transmitting antenna is designed for this frequency range. The frequency range is stated on the devices.
  • Page 30 1. Change the setting of the level control on the transmitter (if available). 2. Turn the overload protection on. Also note the user manual that belongs to the transmitter. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. UHF receiver...

  • Page 31: Technical Specifications

    Technical specifications Technical specifications 8.1 Receiver Modulation type Frequency modulation (FM) Image frequency rejection > 60 dB Sensitivity –102 dBm @ 12 dB SINAD, typical Audio output level 100 mW Operating supply voltage 2 × AA cells (LR6, 1.5 V) Dimensions (W ×...

  • Page 32: Frequency Charts

    Technical specifications 8.2 Frequency charts the t.bone IEM-200 R 606 MHz – 630 MHz (item no. 278194) Frequency group A Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 610.250 MHz 611.500 MHz 612.500 MHz 613.125 MHz 614.250 MHz...
  • Page 33 Technical specifications the t.bone IEM-200 R 606 MHz – 630 MHz (item no. 278194) Frequency group C Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 607.125 MHz 607.750 MHz 608.625 MHz 609.750 MHz 610.500 MHz 612.125 MHz 612.875 MHz...
  • Page 34 Technical specifications the t.bone IEM-200 R 710 MHz – 734 MHz (item no. 278287) Frequency group A Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 714.250 MHz 715.500 MHz 716.500 MHz 717.125 MHz 718.250 MHz 719.125 MHz 720.500 MHz...
  • Page 35 Technical specifications the t.bone IEM-200 R 710 MHz – 734 MHz (item no. 278287) Frequency group C Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 711.125 MHz 711.750 MHz 712.625 MHz 713.750 MHz 714.500 MHz 716.125 MHz 716.875 MHz...
  • Page 36 Technical specifications the t.bone IEM-200 R 740 MHz – 764 MHz (item no. 278289) Frequency group A Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 744.250 MHz 745.500 MHz 746.500 MHz 747.125 MHz 748.250 MHz 749.125 MHz 750.500 MHz...
  • Page 37 Technical specifications the t.bone IEM-200 R 740 MHz – 764 MHz (item no. 278289) Frequency group C Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 741.125 MHz 741.750 MHz 742.625 MHz 743.750 MHz 744.500 MHz 746.125 MHz 746.875 MHz...
  • Page 38 Technical specifications the t.bone IEM-200 R 820 MHz – 844 MHz (item no. 278290) Frequency group A Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 824.250 MHz 825.500 MHz 826.500 MHz 827.125 MHz 828.250 MHz 829.125 MHz 830.500 MHz...
  • Page 39 Technical specifications the t.bone IEM-200 R 820 MHz – 844 MHz (item no. 278290) Frequency group C Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 821.125 MHz 821.750 MHz 822.625 MHz 823.750 MHz 824.500 MHz 826.125 MHz 826.875 MHz...

  • Page 40: Protecting The Environment

    Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose these materials with your normal household waste, but make sure that they are fed to a recovery.
  • Page 41 Protecting the environment Disposal of your old device This device is subject to the European directive 2002/96/EC. Do not dispose the device with your normal household waste. Dispose this device through an approved waste disposal firm or through your local waste facility.
  • Page 42 Notes UHF receiver...
