Installation Instructions
TRANSFORMER HOUSING MUST BE INSTALLED ABOVE GRADE. POWER PIPE™ IS LABELED AT GRADE LEVEL.
Soil Prep
5 7/8" Dia.
(149mm)
5"
(127mm)
90° Angle = B
A. Determine Soil Type by referencing DIG-IT Guide.
Prep soil according to DIG-IT Guide.
Power Pipe with Anchor Base Mounting Option
Finished grade
Finished grade
PS-LED
1. Excavate trench according to designed lighting
plan. Dig hole a minimum of 18" deep and 10"
wide to accommodate Power Pipe™ at desired
fixture locations.
Finished grade
4. Back fill with pea gravel or sand prior to pour.
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
Optional
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
Stability Flange
B-K LIGHTING
& Low Voltage
with
TECHNOLOGY
TRANSFORMER HOUSING INSTALLED BELOW GRADE WILL VOID WARRANTY
B. Dig hole 10" wide and 24" deep.
Concrete
Optional Pea gravel
or sand
Stability Flange
S000733
2. Slide optional Stability Flange onto Power
Pea gravel
or sand
5. Pour concrete (By Others).
Pea gravel Pea gravel
or sand or sand
TECHNOLOGY
Finished grade
Conduit
trench
Finished grade
Pipe™. Use optional Stability Flange to aid in
installation of Power Pipe™.
Concrete
Pea gravel
Finished grade
or sand
Label on Power Pipe™ indicates installation
depth with finished grade.
Pea gravel
Finished grade Above Ground Above Ground
or sand
Finished grade Finished grade
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX 559.438.5900
www.bklighting.com • info@bklighting.com
Concrete
Pea gravel
Finished grade
or sand
Excavated
for Housing
C. Prep soil according to DIG-IT Guide.
Pea gravel
or sand
3. Pull branch circuit wiring necessary for
installation (By Others) to Power Pipe™. Place
Power Pipe™ in hole.
Allow for additional cable to make connections
to fixture leads and future service. Do not cut
PVC.
Remote
Transformer
Remote Transformer
6. Make watertight connections from remote 12V
transformer to LED source leads (18 gauge wire)
using waterproof wire connectors (By Others).
See wiring diagram.
Below Ground
Finished grade
Concrete
RELEASE DATE
11-30-16
Pea gravel Pea gravel
or sand or sand
PS™ / PSL™
Conduit
Trench
REFERENCE NUMBER
INS000733.1
