Supplement to the Operating and Installation Instructions No. 0020044359
for mixer module VR 61
The mixer module VR 61/2 can be used together with controller types VRC 430/VRC 430f and VRC 470.
> Observe the following instructions on installation, commissioning and operation.
VRC 430/VRC 430f
> Observe the Operating and Installation Instructions No. 0020044359 enclosed with the mixer module.
VRC 470
> When installing the mixer module, observe the enclosed Operating and Installation Instructions No. 0020044359.
> For commissioning and operation observe the Installation instructions No. 0020116690 and the Operating
Instructions No. 0020116689 for the VRC 470.
Supplier
Manufacturer

Advertisement

Table of Contents
loading

Related Manuals for Vaillant VR-61

Summary of Contents for Vaillant VR-61

  • Page 1 All manuals and user guides at all-guides.com Supplement to the Operating and Installation Instructions No. 0020044359 for mixer module VR 61 The mixer module VR 61/2 can be used together with controller types VRC 430/VRC 430f and VRC 470. > Observe the following instructions on installation, commissioning and operation. VRC 430/VRC 430f >...
  • Page 2 All manuals and user guides at all-guides.com For the heating engineer/for the owner Operating and Installation Manual Mixer module VR 61 Mixer module for VRC 430 / VRC 430f VR 61...

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com Contents Contents Notes on the documentation 3 Storage of the documents ........3 Symbols used ............3 Validity of the instruction manual ......3 Description of the device .......4 Identification plate ..........4 CE-mark/conformity ..........4 Intended use .............4 Safety instructions and regulations ...4 Safety instructions ..........4 Regulations ...............4...

  • Page 4: Notes On The Documentation

    All manuals and user guides at all-guides.com Notes on the documentation 1 Notes on the documentation Validity of the instruction manual This operating and installation instruction manual is only The following notes are intended to help you throughout applicable to equipment with the following part the entire documentation.

  • Page 5: Description Of The Device

    The CE label documents that the mixer module VR 61, in shock. connection with Vaillant heating equipment, fulfils the basic requirements of the following guidelines: Before working on the mixer module VR 61 and...

  • Page 6: Incorporation Of The Vr 61 In The Heating System

    All manuals and user guides at all-guides.com Incorporation of the VR 61 in the heating system 4 4 Incorporation of the VR 61 in The following conventions apply to the hydraulic the heating system drawings: The application possibilities of the mixer module VR 61 Lines: are shown in the four hydraulic diagrams.

  • Page 7: Hydraulic Drawing 1

    All manuals and user guides at all-guides.com 4 Incorporation of the VR 61 in the heating system Hydraulic drawing 1 VR 81 VRC 430 230 V ~ AF (VRC 693, VR 61 VRC 9535) VRC 9642 VF 2 (VR 10) HK2-P VF 1 (VR 10) HK1-P...

  • Page 8: Hydraulic Drawing 2

    All manuals and user guides at all-guides.com Incorporation of the VR 61 in the heating system 4 Hydraulic drawing 2 VR 81 VRC 430 230 V ~ AF (VRC 693, VR 61 VRC 9535) VRC 9642 VR 40 VF 2 (VR 10) HK2-P VF 1 (VR 10)

  • Page 9: Hydraulic Drawing 3

    All manuals and user guides at all-guides.com 4 Incorporation of the VR 61 in the heating system Hydraulic drawing 3 VRC 430 VR 81 VR 61 230 V ~ SP 1 (VR 10) VRC 9642 VF 2 (VR 10) AF (VRC 693, HK2-P VRC 9535) HK1-P...

  • Page 10: Hydraulic Drawing 4

    All manuals and user guides at all-guides.com Incorporation of the VR 61 in the heating system 4 Hydraulic drawing 4 VR 81 VRC 430 230 V ~ AF (VRC 693, VR 61 VRC 9535) VR 40 HK2-P HK1-P SP 1 (VR 10) Fig.

  • Page 11: Assembly

    Depending upon the configuration of the heating system, additional sensors may be required as storage tank sensors. Only the standard sensor VR 10 from the Vaillant accesories programme should be used. Fig. 5.1 Opening the casing The heating control using Vaillant components ⇒...

  • Page 12: Assembling Vr 10 Standard Sensor

    All manuals and user guides at all-guides.com Assembly 5 Electrical installation6 ⇒ Electrical installation Mark the two fixing points at a suitable position in accordance with the fixing openings (1). ⇒ Drill two holes for the suitable plugs and screw the The electrical connection must be done by a suitably casing securely in position.

  • Page 13: Pump For Heating Circuit

    All manuals and user guides at all-guides.com 6 Electrical installation VRC 430 VR 61 230 V~ Fig. 6.1 Connection of eBUS and mains cable in the system Heating unit 2 230 V line from the user 3 eBUS connection (twin core) 230 V~ 5 V / 24 V 230 V~...

  • Page 14: Start-Up

    All manuals and user guides at all-guides.com Electrical installation 6 Start-up 7 Start-up Note! If a charging pump or circulation pump is connected, the configuration is carried out The commissioning of the mixwe module VR 61 is carried using the installation assistant of the controller out in conjunction with the commissioning of the VRC 430 or VRC 430f.

  • Page 15: Vrc 430 / Vrc 430F Operating Level For The Expert Technician

    All manuals and user guides at all-guides.com 7 Start-up – Display screen A3 If you wish to leave the installation assistant: ⇒ Turn the left hand adjuster of the controller VRC 430 VRC 430f in a clockwise direction to Installation assistant System configuration reach the display screen A6.
  • Page 16 All manuals and user guides at all-guides.com Start-up 7 Display Title display adjustable Remarks Unit Min. Max. Step width Preset screen screen operating values value value value (just display = A) Feed set target (A) Flow temperature target °C Information value Pump status (A) On, Off...
  • Page 17 All manuals and user guides at all-guides.com 7 Start-up Display Title display adjustable Remarks Unit Min. Max. Step width Preset screen screen operating values value value value (just display = A) Set-back For the times between °C parameters temperature the time windows you can set a set-back temperature.
  • Page 18 All manuals and user guides at all-guides.com Start-up 7 Display Title display adjustable Remarks Unit Min. Max. Step width Preset screen screen operating values value value value (just display = A) Set-back For the times between °C parameters temperature the time windows you can set a set-back temperature.
  • Page 19 All manuals and user guides at all-guides.com 7 Start-up Display Title display adjustable Remarks Unit Min. Max. Step width Preset screen screen operating values value value value (just display = A) Total system Mode Auto_OFF Determines the heating Frost Frost parameters control outside the protection,...

  • Page 20: Function Floor Drying

    All manuals and user guides at all-guides.com Start-up 7 VRC 430 / VRC 430f Operating level for the operator 8 8 VRC 430 / VRC 430f Function floor drying Operating level for the operator The floor-drying function is used to “heat dry” a freshly- laid heating layer according to instructions.

  • Page 21: Display Screens In The Operating Level For The Operator

    All manuals and user guides at all-guides.com 8 VRC 430 / VRC 430f Operating level for the operator – Display screen 3 HC2 Time programmes – Display screen 9 HC2 parameters Parameter Time programme Night set back temp. 15 . 0 ° C 06 : 00 - 10 : 40 21.5 °C Heating curve...
  • Page 22 All manuals and user guides at all-guides.com VRC 430 / VRC 430f Operating level for the operator 8 Display Title display adjustable Remarks Unit Min. Max. Step Preset screen screen operating values value value distance value Selection (just display = A) possibilities Day of week / week Select single weekday...

  • Page 23: Technical Data

    All manuals and user guides at all-guides.com 8 VRC 430 / VRC 430f Operating level for the operator 9 Technical data Display Title display adjustable Remarks Unit Min. Max. Step Preset screen screen operating values value value distance value Selection (just display = A) possibilities Set-back...
  • Page 24 All manuals and user guides at all-guides.com...
  • Page 25 All manuals and user guides at all-guides.com...
