Viking Installation Guide
Viking Range Corporation
111 Front Street
Greenwood, Mississippi 38930 USA
(662) 455-1200
For product information,
call 1-888-VIKING1 (845-4641)
or visit the Viking Web site at
vikingrange.com
Outdoor Gas Grills
F20456
(071607J)
Advertisement
Table of Contents
Related Manuals for Viking VGBQ30?
Summary of Contents for Viking VGBQ30?
- Page 1 All manuals and user guides at all-guides.com Viking Installation Guide Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-VIKING1 (845-4641) or visit the Viking Web site at vikingrange.com Outdoor Gas Grills F20456 (071607J)
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com Table of Contents IMPORTANT – Please Read and Follow! Important Information________________________________________________________________________3 D NGER WARNING WARNING T-Series ______________________________________________________________________________________5 Dimensions (30” and 41”) _______________________________________________________________5 FOR YOUR SAFETY FOR YOUR SAFETY Specifications (30” and 41”) _____________________________________________________________6 If not installed, operated and maintained in I I f f y y o o u u s s m m e e l l l l g g a a s s : : Dimensions (53”)_________________________________________________________________________7... -
Page 3: Dimensions (30" And 41")
All manuals and user guides at all-guides.com Dimensions Specifications (T-Series Grills) (T-Series Grills) 30”W. & 41”W. T-Series Grills 30” T-Series Grill VGBQ410T/ VGBQ412T/ Description VGBQ030T VGBQ300T VGIQ300T VGIQ410T VGIQ412T Cutout width 28-5/8” 28-5/8” 28-5/8” 40-1/4” 40-1/4” - 1 / ( 7 4 2 ”... -
Page 4: Specifications (53")
All manuals and user guides at all-guides.com Dimensions Specifications (T-Series Grills) (T-Series Grills) 53”W. T-Series Grills 53” T-Series Grill Description VGBQ530T/VGIQ530T VGBQ532T/VGIQ532T Cutout width 52-1/4” (132.7 cm) Cutout depth 28” (71.1 cm) Cutout height 10-1/4” (26.0 cm) Overall width 53-13/16” (135.1 cm) Overall depth 32-3/4”... -
Page 5: Specifications (30" And 41")
All manuals and user guides at all-guides.com Dimensions Specifications (E-Series Grills) (E-Series Grills) 30”W & 41”W E-Series Grills 30” E-Series Grill Description VGBQ300E VGBQ410E/VGIQ410E VGBQ412E Cutout width 28-5/8” (72.7cm) 40-1/4” (102.2cm) - 1 / ( 7 4 2 ” Cutout depth 28”... -
Page 6: Dimensions (53")
All manuals and user guides at all-guides.com Dimensions Specifications (E-Series Grills) (E-Series Grills) 53”W E-Series Grills 53” E-Series Grill Description VGBQ530E/VGIQ530E VGBQ532E/VGIQ532E Cutout width 52-1/4” (132.7 cm) Cutout depth 28” (71.1 cm) Cutout height 10-1/4” (26.0 cm) Overall width 53-13/16” (135.1 cm) Overall depth 32-3/4”... -
Page 7: General Information
All manuals and user guides at all-guides.com General Information Built-In Information • Keep grill area clear and free from • A minimum of 6” (15.2 cm) from the sides, T-Series Grills: WARNING combustible materials, gasoline, and other or a minimum of 8” (20.3 cm) from the •... -
Page 8: Clearance Dimensions (30")
All manuals and user guides at all-guides.com Clearance Dimensions Clearance Dimensions (30” Grill) (41” Grill) VGBQ300T/030T VGBQ410T/VGIQ410T VGBQ300E/VGIQ300T VGBQ410E/VGBQ412T/VGBQ412E - 1 5 / 1 6 ( 5 8 - 1 5 . 3 c ” / 1 6 ( 5 8 . -
Page 9: Clearance Dimensions (53")
All manuals and user guides at all-guides.com Clearance Dimensions Cutout Dimensions (53” Grill) (30” Grill) VGBQ530T/VGIQ530T Gas inlet and power cord location area VGBQ530E/VGBQ532T/VGIQ532T VGBQ532E - 1 5 / 1 6 ( 5 8 - 5 / ” . 3 c ”... -
Page 10: Cutout Dimensions (41")
All manuals and user guides at all-guides.com Cutout Dimensions Cutout Dimensions (41” Grill) (53” Grill) Gas inlet and power cord location area Gas inlet and power cord location area ” - 1 / ( 1 0 . 1 c 4 ” 2 . -
Page 11: Ventilation For Built-In Installations
All manuals and user guides at all-guides.com WARNING Ventilation for Built-In Installations Gas and Electrical Connection DANGER GAS CONNECTION GAS CONVERSION Verify the type of gas supply to be used, To convert a grill from natural to Not less than either natural or LP, and make sure the LP/Propane or LP/Propane to natural, you 5.00 inches... -
Page 12: Natural Fixed Piping Connection
1/2” (1.3 cm) female flare adapter to the NOT : If using a Viking GSH12 flexible a 3/8” female flare adapter to the 3/8” male accessible location. -
Page 13: Lp/Propane Tank Requirements
All manuals and user guides at all-guides.com LP/Propane Tank Requirements LP/Propane Tank Connection Outdoor grills orificed for use with connector to the LP/Propane tank. Open the A dented or rusty LP/Propane tank may be All LP/Propane tanks must be mounted in a LP/Propane gas come equipped with a high tank valve and check the connection between hazardous and should be checked by your... -
Page 14: Leak Testing
All manuals and user guides at all-guides.com WARNING DANGER Leak Testing Although all gas connections on the grill are • Do not smoke while leak testing. leak tested at the factory prior to shipment, • Extinguish all flames. a complete gas tightness check must be •... -
Page 15: Burner Adjustment
All manuals and user guides at all-guides.com Burner Adjustment Flames should be blue and stable with no Each burner is tested and adjusted at the factory prior to shipment; however, variations in yellow tips, excessive noise or lifting. If any of the local gas supply may make it necessary to these conditions exist, check if the air shutter or adjust the burners. -
Page 16: Rotisserie System
All manuals and user guides at all-guides.com Rotisserie System The rotisserie motor is attached to the WARNING mounting bracket located on the right side of the grill frame. The rotisserie motor must ELECTRICAL SHOCK HAZARD be electrically grounded in accordance with This appliance is equipped with a grounding plug for your protection against shock hazard local codes. -
Page 17: Performance Checklist
All manuals and user guides at all-guides.com Performance Checklist Service & Registration A qualified installer should carry out the Service & Parts following checks: Only authorized replacement parts may be used in performing service on the appliance. • All internal packaging removed. •...
