Summary of Contents for Stirling SUM52
- Page 1 52cm Undermount Rangehood Model Number SUM52 INSTRUCTION MANUAL IM Version No.: V1.1 Issue Date: 04/2018 MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018...
-
Page 2: Welcome
Welcome Congratulations on choosing to buy a STIRLING® product. All products brought to you by STIRLING® are manufactured to the highest standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 3 Year In Home Warranty. We hope you will enjoy using your purchase for many years to come. -
Page 3: Table Of Contents
General Safety Instructions Product Overview Getting Started Installation 12 Cleaning and Maintenance 13 FAQs and Troubleshooting 14 Technical Data 14 Specifications 15 Repair and Refurbished Goods or Parts Notice 16 Warranty Returns MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018... -
Page 4: Warranty
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018... -
Page 5: General Safety Instructions
Do not connect or disconnect the electric plug when your hands are wet. Turn the power switch off before removing the plug from the socket. MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018... - Page 6 There shall be adequate ventilation of the room when the range hood is used at the same time as appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the room). CAUTION: Accessible parts may become hot when used with cooking appliances. MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018...
-
Page 7: Product Overview
Product Overview 52cm Undermount Rangehood Key: A. LED Light B. Push-button Control Panel C. Decorative Filter D. Filter Handle E. Stainless Steel Fascia Also included but not shown: 1 × Pack of screws MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018... - Page 8 When high density of smoke or steam produced, press high-speed button for highest effective ventilation. Light button NOTE If Low / Medium / High speed buttons are press at the same time, the unit will only operate at the highest speed. MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018...
-
Page 9: Getting Started
• Level: Ensure that the rangehood is mounted in a level position, both horizontally and vertically. This is essential to ensure the rangehood improper installation. operates correctly and prevents grease build up at one end. MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018... - Page 10 • Avoid sharp 90 degree bends as much as possible, use 45 degree bends instead wherever possible. • Duct to the outside atmosphere using the shortest duct run possible. • Use cylindrical ducting whenever possible. MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018...
- Page 11 • Screw the rangehood into the cabinet using 8 screws (supplied). • Re-fit the fascia panel with the 4 screws (previously removed). • Re-fit grease filter. Fascia panel Grease filter Fig. 4 MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018...
-
Page 12: Cleaning And Maintenance
Cleaning & Maintenance By ensuring proper cleaning and maintenance of your Stirling rangehood, you can ensure that it will have a long and fault free operation. Cleaning the grease filters Keeping this filter clean will keep the rangehood extraction performance at an optimum. Please strictly follow the guidelines below. -
Page 13: Faqs And Troubleshooting
Insufficient suction. The distance between the rangehood Have your installer re-adjust the and your cooktop is too great. installation position, ensuring that the minimum distances are observed as per the building code. MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018... -
Page 14: Technical Data
Specifications Model Extraction Other features: SUM52 750m3/hr extraction • 3 speed push button control • 2 × 2W LED Lamp • 1 × 5 layer aluminium grease filter with s/steel Facia MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018... -
Page 15: Repair And Refurbished Goods Or Parts Notice
118 Campbell Street 1/32 Wangaratta St Collingwood VIC 3066 Richmond VIC 3121 Australia Australia Email: support@residentiagroup.com.au Email: support@residentiagroup.com.au Helpline hours of operation: Mon–Fri 9:00 AM - 5:00 PM MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018 0000 000 000 www.xxxxxxx.com... - Page 16 MODEL: SUM52 | PRODUCT CODE: 60143 | 4/2018...
