- Page 1 Rangehood Model Number STR-BRH INSTRUCTION MANUAL AFTER SALES SUPPORT info@tempo.org 1300 886 649 E209 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018...
-
Page 2: Welcome
Welcome Congratulations on choosing to buy a STIRLING product. ® ® All products brought to you by STIRLING are manufactured to the highest standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 3 Year in Home Warranty. -
Page 3: Table Of Contents
05 General Safety Instructions 08 Product Overview 10 Installation 17 Instructions 18 FAQs & Troubleshooting Guide 19 Other Useful Information 23 Repair and Refurbished Goods or Parts Notice AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018... -
Page 4: Warranty Details
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018... -
Page 5: General Safety Instructions
• Disconnect: Before cleaning the rangehood, make sure to switch it off and unplug it from the electrical supply. Do not disconnect the appliance with wet hands. Grip by the plug, do not pull by the cord when disconnecting. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018... - Page 6 There is a fire risk if cleaning is not carried out in accordance with the instructions. • After use: Make sure to switch off the rangehood after use and before cleaning. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018...
- Page 7 • Liability: We assume no liability for any eventual damages caused by incorrect installation, misuse of the product or noncompliance with these instructions. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018...
-
Page 8: Product Overview
Due to continued product improvement, images and illustrations in this manual may vary slightly from the product purchased. All images in this manual are for reference purposes only. Parts are not necessarily pictured to scale. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018... - Page 9 Flue outlet adaptor (for use in ducted mode) Flue outlet cover (for use in recirculating mode) Front vent cover (for use in ducted mode) Aluminium exhaust duct AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018...
-
Page 10: Installation
• For optimum performance, the outlet duct should not exceed 4 metres in length, nor have more than 90 degree bends, and its diameter should be at least 120mm. • Please remove any protective film before installation. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018... - Page 11 (Fig. 1). Fig. 1 • Check and ensure that the dial on the motor assembly points to desired venting mode position (Fig. 2). Fig. 2 DUCTED RECIRCULATING AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018...
- Page 12 Fig. 4 • Refit the aluminium mesh filters. • Attach the flue outlet cover to the top of the rangehood. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018...
- Page 13 45mm fascia rail supplied in the box (Fig. 6). Fig. 6 • Install the flue outlet adaptor to the top of the rangehood. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018...
- Page 14 Installation (Cont.) Product dimensions Fig. 7 (dimensions in millimetres) Installation diagram Fig. 8 (dimensions in millimetres) AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018...
- Page 15 (Fig. 10). Fig. 10 WARNING: Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards! AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018...
- Page 16 • Attach one end of the exhaust duct to the flue outlet adaptor on top of the rangehood (Fig. 11). Fig. 11 • Lead the other end of the exhaust duct to the hole in your ceiling or wall. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018...
-
Page 17: Instructions
• Push in the fascia rail to stop operation. Both the fan and light will stop working. • The next time the fascia rail is pulled out, the rangehood will start working at the previously set level. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018... -
Page 18: Faqs & Troubleshooting Guide
Tighten the bulbs, or replace them, if burnt out. necessary. The bulbs do not light up. The unit is not properly Ensure the power plug is firmly connected. inserted in the electrical outlet. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018... -
Page 19: Other Useful Information
This is not a fault and no cause for concern. It does not affect performance and does not warrant replacement of these parts. Fig. 13 Fig. 12 AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018... - Page 20 • Carefully unscrew the light bulb and remove. • Replace the bulb with one of the same type and wattage (E14, 28W). AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018...
- Page 21 Our after sales support centre stocks a wide range of spare parts for the STR-BRH STIRLING Rangehood. To purchase a part, call the centre on 1300 886 649 or email us at info@tempo.org •...
- Page 22 Observe any local regulations regarding the disposal of electrical consumer goods and dispose of it appropriately for recycling. Contact your local authorities for advice on recycling facilities in your area. AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018...
-
Page 23: Repair And Refurbished Goods Or Parts Notice
Tempo (Aust) Pty Ltd ABN 70 106 100 252 PO BOX 6056 Frenchs Forest, Sydney, Australia NSW 2086 Tempo Help Desk: 1300 886 649 (Aust) (Operating Hours: Mon-Fri 08:30am to 06:00pm EST) Email: info@tempo.org AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018... - Page 24 V1.1 09 January 2018 Minor updates, page 15 V1.2 22 January 2018 Minor updates, pages 10, 15, 18, 20 V1.3 23 January 2018 Minor update page 21 AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: STR-BRH PRODUCT CODE: 60158 06/2018...
