Model No. WLEVEX13590
Serial No.
Write the serial number in the
space above for future reference.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or find that there
are missing or damaged parts,
we will guarantee you complete
satisfaction through our
Customer Service Department.
Please CALL:
0345-089009
Or WRITE:
ICON Fitness Lifestyle Ltd.
Greenwich House
223 North Street
Sheepscar
West Yorkshire
Leeds LS7 2AA
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
All manuals and user guides at all-guides.com
Serial
Number
Decal
USER'S MANUAL
Class HC Fitness Product
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pursuit 655s and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weslo Pursuit 655s

Summary of Contents for Weslo Pursuit 655s

  • Page 1 Leeds LS7 2AA Class HC Fitness Product CAUTION Visit our website at Read all precautions and instruc- tions in this manual before using www.weslo.com this equipment. Keep this manual for future reference. new products, prizes, fitness tips, and much more!

  • Page 2: Table Of Contents

    HOW TO USE THE PURSUIT 655s ........

  • Page 3: Important Precautions

    All manuals and user guides at all-guides.com IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the exercise cycle. 1. Read all instructions in this manual before caught on the exercise cycle. Always wear using the exercise cycle.

  • Page 4: Before You Begin

    WLEVEX13590. The serial number can be found on a provide you with a low-impact workout in the conve- decal attached to the PURSUIT 655s (see the front nience and privacy of your own home. cover of this manual for the location of the decal).

  • Page 5: Part Identification Chart

    All manuals and user guides at all-guides.com PART IDENTIFICATION CHART Use the chart below for help identifying the small assembly. Note: Some parts may have been pre- parts used in assembly. The number in parenthesis attached for shipping purposes. If a part is not below each part refers to the key number of the part.

  • Page 6: Assembly

    All manuals and user guides at all-guides.com ASSEMBLY Place all parts of the PURSUIT 655s in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench...
  • Page 7 All manuals and user guides at all-guides.com 4. Press the Side Shield Cover (40) onto the Left and Right Side Shields (1, 2). 5. Insert the Seat Post (20) into the Frame (15). Align one of the holes in the Seat Post with the hole in the Frame.

  • Page 8: How To Use The Pursuit 655S

    All manuals and user guides at all-guides.com HOW TO USE THE PURSUIT 655s HOW TO ADJUST THE SEAT HOW TO APPLY AN INFORMATION DECAL TO THE CONSOLE For effective exer- All of the infor- cise, the Seat (19) mation on the...
  • Page 9 All manuals and user guides at all-guides.com DIAGRAM OF THE CONSOLE 2. When the power is turned on, the The console console will Arrow offers six modes begin displaying that provide all modes in a instant exercise repeating cycle feedback. Each (except for the mode is dis- pulse mode).

  • Page 10: Conditioning Guidelines

    All manuals and user guides at all-guides.com CONDITIONING GUIDELINES The following general guidelines will help you to plan Aerobic Exercise your exercise program. Remember that proper nutri- tion and adequate rest are essential for successful If your goal is to strengthen your cardiovascular sys- results.
  • Page 11 All manuals and user guides at all-guides.com SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips.

  • Page 12: Maintenance And Trouble-Shooting

    All manuals and user guides at all-guides.com MAINTENANCE AND TROUBLE-SHOOTING Inspect and tighten all parts of the exercise cycle HOW TO ADJUST THE REED SWITCH regularly. Replace any worn parts immediately. If the console does not display correct feedback, the The exercise cycle can be cleaned with a soft, damp reed switch should be adjusted.
  • Page 13 All manuals and user guides at all-guides.com HOW TO ADJUST THE BELT If the Belt (16) is properly adjusted, reattach the side shields and pedals. If the Belt needs to be adjusted, The exercise cycle features a precision belt that must loosen the M8 Washer Nut (37) on each side of the be kept properly adjusted.

  • Page 14: Part List

    All manuals and user guides at all-guides.com PART LIST—Model No. WLEVEX13590 R0699A Key No. Qty. Description Key No. Qty. Description Left Side Shield Crank/Pulley Right Side Shield M4 x 38mm Self-tapping Screw Double Tree Fastener Flywheel Spacer M4 x 12mm Self-tapping Screw Flywheel Axle Handlebar M8 Washer Nut...

  • Page 15: Exploded Drawing

    All manuals and user guides at all-guides.com EXPLODED DRAWING—Model No. WLEVEX13590 R0699A 41 8...

  • Page 16: How To Order Replacement Parts

    • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST on page 14 of this manual). WESLO is a registered trademark of ICON Health & Fitness, Inc. Part No. 156580 R0699A...
