Machine Specifications

Total Weight and Size VR1 Overhead Press 13010 Standard Stack
Weight
466 Lbs
212 Kg
Total Weight and Size VR1 Overhead Press 13010 Light Stack
Weight
406 Lbs
130 Kg
Maximum User Weight
300 lbs/135kg

Choosing and Preparing a Site

Before assembling the unit, verify the chosen site meets the following criteria:
• Area is well lit and well ventilated.
• Surface is structurally sound and properly leveled.
• Free area for access to unit and emergency dismount. Minimum clearance is 23.6 inches (0.6 meters).
• Adjacent units may share the free area.
It is the responsibility of the facility owner/owner of the equipment to ensure that there is appropriate clearance
around each machine to allow for safe use and passage.
In compliance with the ADA (American Disabilities Act) there must be clear floor space of at least 30 by 48 inches
and be served by an accessible route for at least one of each type of exercise equipment. If the clear space is
enclosed on three sides (e.g., by walls or the equipment itself), the clear space must be 36 by 48 inches.

Assembly

Machine Dimensions at Rest
57" L x 51" W x 62" H
146 cm L x 129 cm W x 157 cm H
Machine Dimensions at Rest
57" L x 51" W x 62" H
146 cm L x 129 cm W x 157 cm H
51" L x 52" W x 80" H
130 cm L x 132 cm W x 204 cm H
51" L x 52" W x 80" H
130 cm L x 132 cm W x 204 cm H
Maximum Training Weight
Page 8 of 23
Machine Dimensions in Use
Machine Dimensions in Use
197.5 lbs/90 kg
