CYBEX VR1 Overhead Press Owner's Manual page 13

Apply weight plate decal
1. Peel off half of backing from weight plate decals, making sure that the decals remain attached to the front
sheet.
2. Place decals front sheet in the correct position on weight plates.
3. Insert a guide pin through each hole of the decals front sheet. A guide pin can be anything that fits through
the weight stack hole, such as a weight stack selector pin.
4. Align decals and rub them onto weight plates.
5. Remove front sheet, do not peel decals off of weight plates.
6. Repeat above steps for other half of the weight plate decals.
Cable routing
1. Verify cable is routed through all pulleys.
2. Route cable through top pulley bracket and then route cable end to top weight connector.
1
2
3
1
2 Weight stack selector pin
Page 13 of 23
Description
Backing
Front sheet
Weight decals
Description
Weight plate decal
Qty
1
1
1
Qty
1
1
