Kit Instructions
Bead Gun Kit for LL250
Pressurized Bead System
For professional use only.
Model 16R963
psi (MPa, bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in the bead system and striper manual.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
and LL200
SPS
ti20740a
332226C
HS
EN
Advertisement
Related Manuals for Graco 16R963
Summary of Contents for Graco 16R963
- Page 1 LL200 332226C Pressurized Bead System For professional use only. Model 16R963 psi (MPa, bar) Maximum Working Pressure Important Safety Instructions Read all warnings and instructions in the bead system and striper manual. Be familiar with the controls and the proper usage of the equipment.
-
Page 2: Tools Needed
• Adjustable Wrench • Phillips Screwdriver • Cutting Blade Gun Kit Assembly 16R963 1. If needed, configure unit gun assembly with gun arm brackets included in Retro-fit Kit. ti20548a 250 Models: ti20709a 5. Install 10 in. air line (G) and push into bottom valve. - Page 3 Gun Kit Assembly 16R963 7. Push one end of remaining air line into top hole on 8. Zip tie air and bead hoses together with supplied air switch and run along bead hose to tank and then ties. route and push into elbow fitting (J) on air tank.
- Page 4 Gun Kit Assembly 16R963 0 to 8 in. Line Setup 2 Tank 1 Gun Setup For wider lines it may be necessary to mount bead gun Connect “Y” fitting as shown below to allow two tanks to as shown below.
-
Page 5: Parts List
Parts Parts ti20722a Parts List Ref. Part Description Ref. Part Description 114109 FITTING, elbow, male, swivel 16T646 SWITCH, air 116876 WASHER, flat 16T804 BRACKET, switch, air 115483 NUT, lock 16T771 BOOT, button, push 100020 WASHER, lock 238329 GUN, spray, bead 116610 SCREW, mach, phil, pan, #10 16U274 HOSE, pneumatic 103473 STRAP, tie, wire... -
Page 6: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
