ROFU 2400 Kit Installation Instructions

Standard information for the ROFU 2400 Kit
Power Input:
Voltage tolerance: +/- 15%
Current Draw:
Operating Temp:
Humidity:

Optional Accessories:

ROFU # 5525 1" Lip Extension
ROFU # 5550 2" Lip Extension
ROFU # 2402 Installation Jig
The ROFU 2400 kit is designed for use with cylindrical locksets. It has a keeper depth of 1/2" (12mm), and
can accept a 5/8" latch bolt with up to a 1/8" door gap. The kit is supplied with two stainless steel faceplates,
an ANSI 1 1/4" x 4 7/8" and an 1 7/16" x 7 15/16" faceplate. The strike has a low depth profile of 1 1/4" overall
and it is designed to easily install into an aluminum storefront or hollow metal jamb. Also in the kit we include
We now include a "trim plate" to cover "accidents" around the
lip. These will not work on previous models as there were no
mounting holes for the trim plate.
Installation instructions for the
ROFU 2400 Kit
12VDC or 24VDC
280mA @ 12VDC
140mA @ 24VDC
32-120 degrees Fahrenheit
0-49 degrees Celsius
0-85% +/- 5%
- - - - - -
mounting tabs, and all the screws you could need.
ROFU Security International Corp.
10029 S. Tacoma Way, E-11
Lakewood, WA 98499
Ph. 1-800-255-7638 Fax
1-888-840-7272
www.rofu.com
4 7/8" Faceplate
w/ Cylindrical Lockset
Optional: Lip extensions for wider aluminum jambs
R F U O
7 15/16" Faceplate
w/ Cylindrical Lockset
