KAZALO
1. INSTALLATION.....................................................3
1.1. EXTERIOR UNIT MOUNTING............................3
1.2. INTERIOR UNIT MOUNTING.............................3
2. FIRST START UP...................................................3
2.1. APPLICATION DOWNLOAD...............................3
2.2. CONNECTING TO THE DEVICE..........................4
3. DEVICE MANAGEMENT.......................................4
3.1. PROPER USE....................................................4
3.2. ADMINISTRATOR'S ROLE AND ENROLMENT....5
3.3. USER ENROLMENT...........................................6
3.4. DELETING A USER/ADMINISTRATOR................6
3.5. SETTINGS.........................................................6
3.6. MAINTENANCE................................................8
3.7. LIGHT SIGNALS TABLE......................................9
3.8. EXPLANATIONS AND NOTES..........................10
4. TROUBLESHOOTING ........................................11
5. MANUFACTURER'S WARRANTY........................12
6. NAVODILA ZA MONTAŽO..................................14
6.1. PRITRDITEV ZUNANJE ENOTE........................14
6.2. PRITRDITEV NOTRANJE ENOTE......................14
6.3. NAVODILA ZA PRIKLOP...................................14
6.4. SPISEK KONTAKTOV........................................15

1. INSTALLATION

1.1. EXTERIOR UNIT MOUNTING

The exterior unit is designed to be installed on top
of an electrical mounting box with a dimension of Ø
60 mm. It is recommended that the exterior unit be
mounted at a height of 150 cm. The average user
will find it easy to swipe their finger over the sensor
at this height.
The exterior unit should be protected from rain and
should not be exposed to direct sunlight.

1.2. INTERIOR UNIT MOUNTING

The interior unit fits on the DIN rail in a fuse box
and occupies four fuse spots.
Installation should be performed by a qualified
person.

2. FIRST START UP

Communication between the exterior and interior
unit is protected by a unique code, which is pre-set
for each device individually. When the interior and
exterior units are connected to the power supply
and the communication link is established, the
orange and red LED will flash and the buzzer will
buzz simultaneously. In this period, the connection
is established and when the orange LED starts to
shine continuously, the device is ready to be used.
When the orange LED shines the device is in frees
can mode, waiting for a finger to be swiped over
it. After performing any of the functions the device
returns to the free scan mode.

2.1. APPLICATION DOWNLOAD

The ARX-manager is managed by a mobile phone
of a newer generation or a laptop computer,
3
