Summary of Contents for Altimium SP8H2-4K
- Page 1 User Manual SP8H2-4K HDMI 2.0 1x8 Splitter with 4K to 1080P Down-scaling All Rights Reserved Version: SP8H2-4K_2019V1.0...
-
Page 2: Safety Precaution
2x Mounting Ears with 4 Screws 4x Plastic Cushions 1x Power Adapter (12V DC 1A) 1x User Manual Note: Please contact your distributor immediately if any damage or defect in the components is found. Altimium www.altimium.com... -
Page 3: Product Introduction
Built-in equalizer for signal enhancement to avoid signal attenuation in transmission. Supports CEC control to turn on/off displays and adjust their volume. Provides LEDs to indicate the current operating status and to assist troubleshooting and installation. Firmware upgrade by Micro-USB port. Altimium www.altimium.com... -
Page 4: Panel Description
Please refer to the EDID Management for more details. ⑨ FW: Micro-USB port for firmware upgrade. Note: Only the displays which support CEC can be controlled by DISPLAY ON, DISPLAY OFF, VOLUME UP and VOLUME DOWN buttons. Altimium www.altimium.com... -
Page 5: Edid Management
In this mode, the 4-pin DIP switch on the rear panel can be used to PRESET select predefined EDID and customize a specific EDID as need. The splitter reads all EDID information from all connected displays, H.RES and choose the one with highest resolution passing to the source. Altimium www.altimium.com... - Page 6 Obtains EDID from the display connected to the HDMI output port 7. 0111 Obtains EDID from the display connected to the HDMI output port 8. 1000 720P LPCM 1001 1080P LPCM 1010 1080P DTS/Dolby 1011 3840x2160@30Hz LPCM 1100 3840x2160@30Hz DTS/Dolby 1101 3840x2160@60Hz LPCM 1110 3840x2160@60Hz DTS/Dolby Altimium www.altimium.com...
- Page 7 Remove the USB cable, and then reboot the splitter. The new EDID now can be invoked via the 4-pin DIP switch directly. The EDID ID and its corresponding switch status is shown in the below list. Switch Status 1111 Altimium www.altimium.com...
-
Page 8: Firmware Upgrade
“SUCCESS.TXT”, if yes, the firmware was upgraded successfully, otherwise, the firmware updating is fail, the name of upgrade file (.bin) should be confirm again, and then follow the above steps to upgrade again. 6) Remove the USB cable after firmware upgrade. Altimium www.altimium.com... -
Page 9: System Connection
The following diagram illustrates the typical input and output connection of the splitter: HDMI: HDBaseT: 4K@60 4:4:4 HDR Down Scaling 4K/60 Display 4K/60 Blu-ray 4K/60 Display 1080p Display HDMI 2.0 Tx HDMI 2.0 Rx 4K/60 Display 4K/60 Display Altimium www.altimium.com... -
Page 10: Technical Specification
10%-90% Power Supply Input:100V~240V AC; Output: 12V DC 1A Power Consumption 7W(Max) Dimension (W*H*D) 260mm x 20mm x 70mm Net Weight 500g Note: Please adopt high-qualified HDMI cable fully compliant with HDMI 2.0 for reliable transmission and connection. Altimium www.altimium.com... - Page 12 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
