- Page 1 User Manual CVHA2 HDMI Audio Splitter/De-embedder 1x2 All Rights Reserved Version: CVHA2_2016V1.1...
- Page 2 Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. Altimium www.altimium.com...
- Page 3 Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. Altimium www.altimium.com...
-
Page 4: Table Of Contents
HDMI Audio Splitter/De-embedder 1x2 Table of Contents Introduction ......................1 1.1. Introduction to CVHA2 ................... 1 1.2. Features ......................1 1.3. Package Contents ..................1 Product Appearance ................... 1 System Connection .................... 3 3.1. Usage Precautions ..................3 3.2. System Diagram ..................... 3 3.3. -
Page 5: Introduction
HDMI Audio Splitter/De-embedder 1x2 1. Introduction 1.1. Introduction to CVHA2 CVHA2 is a high-quality HDMI audio splitter/de-embedder, with 1 HDMI and 1 split stereo audio output, HDCP compliant and HDTV compatible. The antistatic case design of CVHA2 provides good protection for stable performance, and its transmission resolution ups to 1920*1200@60Hz. - Page 6 ③ Power Indicator: It turns red when power on. ④ HDMI OUT: HDMI output port, used to connect to a display device, such as HDTV. ⑤ AUDIO OUT: Stereo audio output port, used to connect with an audio amplifier, such as a speaker. Altimium www.altimium.com...
-
Page 7: System Connection
1) System should be installed in a clean environment and has a prop temperature and humidity. 2) All of the power switches, plugs, sockets and power cords should be insulated and safety. 3) All devices should be connected before power on. 3.2. System Diagram Altimium www.altimium.com... -
Page 8: Connection Procedure
HDMI Audio Splitter/De-embedder 1x2 3.3. Connection Procedure Connect HDMI IN port of CVHA2 with HDMI source device, such as a DVD player. Connect HDMI OUT port of CVHA2 with display device, such as an HDTV. Connect AUDIO OUT port of CVHA2 with a speaker or earphone etc. -
Page 9: Application Solution
HDMI Audio Splitter/De-embedder 1x2 4. Application Solution 4.1. System Diagram Altimium www.altimium.com... -
Page 10: Product Assortment
④ Digital amplifier 2x20Watt@4Ohm power as default output power. Bridge connection to double the output power at 1x40Watt@8Ohm. 48V phantom power to support condenser microphone. MIC port can support balance/unbalance signal, suppress the external noise effectively. Altimium www.altimium.com... -
Page 11: Specification
>75dB@20Hz ~ 20KHz THD + Noise 0.3%@20KHz Separation General Input: 100VAC ~ Power Power 240VAC, 50/60Hz; Supply Consumption Output: 5VDC, 1A Temperature -20 ~ +70℃ Humidity 10% ~ 90% Case Product W69 x H28 x D52.5 mm 0.1Kg Dimension Weight Altimium www.altimium.com... -
Page 12: Panel Drawing
HDMI Audio Splitter/De-embedder 1x2 6. Panel Drawing 13.5 mm 69 mm 30 mm 65 mm HDMI OUT AUDIO OUT HDMI IN DC 5V Altimium www.altimium.com... -
Page 13: Troubleshooting & Maintenance
Maybe the video cables are in bad quality. 4) If the static becomes stronger when connecting the audio or video connectors, it probably due to bad grounding, please check the grounding and make sure it connected well, otherwise it would damage the converter. Altimium www.altimium.com... -
Page 14: Safety Operation Guide
6) As to non-professional or without permission, please DO NOT try to open the casing of the equipment, DO NOT repair it on your own, in case of accident or increasing the damage of the equipment. 7) DO NOT splash any chemistry substance or liquid in the equipment or around. Altimium www.altimium.com... -
Page 15: After-Sales Service
HDMI Audio Splitter/De-embedder 1x2 9. After-sales Service 1) If there appear some problems when running the CVHA2, please check and deal with the problems reference to this user manual. Any transport costs are borne by the users during the warranty. - Page 16 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
