- Page 1 User Manual SP4H2-4K 4K HDMI Splitter 1x4 All Rights Reserved Version: SP4H2-4K_2016V1.0...
- Page 2 Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. Altimium www.altimium.com...
- Page 3 Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. Altimium www.altimium.com...
-
Page 4: Table Of Contents
4K HDMI Splitter 1x4 Contents 1. Introduction ......................... 1 1.1 Introduction to SP4H2-4K .................. 1 1.2 Features ......................1 1.3 Packing List ....................... 1 2. Panel Description ......................2 3. System Connection ..................... 4 3.1 Usage Precautions .................... 4 3.2 System Diagram ....................4 3.3 Connection Procedures .................. -
Page 5: Introduction
1. Introduction 1.1 Introduction to SP4H2-4K SP4H2-4K is a HDMI splitter featuring the capability to repeat HDMI or DVI source to 4 displays synchronously. Compliance with HDMI 2.0& HDCP2.2, SP4H2-4K provides comprehensive resolution capacities up to 4K& 1080p 3D. It’s capable to automatically recognize the resolution and HDCP compliant status of the input signal. -
Page 6: Panel Description
⑥ as DVD/ Blue-ray Note: a) Pictures shown in this manual are for reference only, different model and specifications are subject to real product. b) Output HDCP compliant status depends on input signal. When the input signal is Altimium www.altimium.com... - Page 7 Dolby Digital, DTS, DTS-HD), while DVI signal contains solely video signal. d) SP4H2-4K is capable to switch input signal format according to the displays. e) For example, when the input signal is HDMI and the display can only support DVI signal, SP4H2-4K will switch the signal into DVI format.
-
Page 8: System Connection
Connect a HDMI/ DVI source device (e.g. Blue-ray DVD) to the IN socket of SP4H2-4K with HDMI cable. Step2. Sequentially connect HDMI displays to OUT 1 ~ OUT 4 sockets of SP4H2-4K with HDMI cables. Step3. Plug a DC 5V power adapter to the power port of SP4H2-4K. -
Page 9: Edid Management
4K HDMI Splitter 1x4 3.4 EDID Management SP4H2-4K comprises 1 HDMI input port & 4 HDMI output ports, and it possess built-in EDID management function. When all output ports are connected with displays, the source device will gain the EDID data from the display connected output 1 port. At this point, if you disconnect the output 1 display and want the source device to gain the EDID from the output 2, the SP4H2-4K need to be restarted. -
Page 10: Specification
In-built EDID management Support Dolby D (True HD)/ DTS (HD-Master Audio)/ HDMI Embedded Audio General Reference Temperature 0~ 55℃ 10% ~ 90% Humidity 输入:100V~240V AC Power Power 6.5W (Max) Consumption 输出: DC5V 2A Dimension 152mmx 11mmx 70mm Weight 140g (W*H*D) Altimium www.altimium.com... -
Page 11: Supported Input Video Formats
3840 x 2160@25Hz 3840 x 2160@30Hz 3840 x 2160@60Hz 1080P 3D@60Hz Note: SP4H2-4K supports 4k& 3D HDMI signals, please adopt quality HDMI cables compliant with HDMI1.4 for better transmission when connecting 4K or 3D sources. Altimium www.altimium.com... -
Page 12: Panel Drawing
4K HDMI Splitter 1x4 5. Panel Drawing SP4H2-4K HDMI2.0 & HDCP2.2 152 mm Altimium www.altimium.com... -
Page 13: Troubleshooting & Maintenance
No HDMI signal output in The connecting cables may Check whether the cables SP4H2-4K while local not be connected correctly are connected correctly HDMI input is in normal or it may be broken. and in working condition. -
Page 14: After-Sales Service
4K HDMI Splitter 1x4 7. After-sales Service If there appear some problems when running SP4H2-4K, please check and deal with the problems referring to this user manual. Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: We warrants that its products will be free from defects in materials and workmanship for three years, which starts from the first day you buy this product (The purchase invoice shall prevail). - Page 16 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
