Propane tank not included
1AA battery needed, not included
WARNING
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
An LP-cylinder not connected for use should not be stored in the vicinity of this or any other appliance.
DANGER
This appliance complies with "ANSI Z21.97-2014/CSA 2.41-2014, Outdoor Decorative Gas Appliances.
Origin of Country: China
ASSEMBLY INTRUCTION
ITEM#：L-OF141PST
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a camper, tent, car or home.
WARNING: For Outdoor Use Only.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and
immediately call your gas supplier or fire department.
WARNING:
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Read
the installation, operating and maintenance instructions
thoroughly before installing or servicing this equipment.
1 / 12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L-OF141PST and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sunjoy L-OF141PST

Summary of Contents for Sunjoy L-OF141PST

  • Page 1 ASSEMBLY INTRUCTION ITEM#：L-OF141PST WARNING: For Outdoor Use Only. DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, keep away from the appliance and immediately call your gas supplier or fire department.

  • Page 2: Table Of Contents

    Limited warranty……………………………………………………………….….…… 11-12 Cleaning and maintenance………………………………………………………………12 GENERAL INFORMATION Important: For technical assistance on assembly or replacement parts, please call Sunjoy Industries at 1(866) 578-6569 from 8:00 AM EST to 8:00 PM PST. You may email to customer.care@sunjoygroup.com or visit www.sunjoyonline.com to...

  • Page 3: Specification

    SPECIFICATION Matheson LP Fireplace Product name Model NO. L-OF141PST Rated Heat Input 64,500 BTU / HR Fuel Propane-LP Gas Supply 20 lb. LP-Gas cylinder Manifold Pressure 11 Inches W.C. Orifice Size (diameter) 2.48 mm / 0.097 in Gas Supply Pressure Max.250 PSI...
  • Page 4  Inspect the gas connections of the appliance prior to each use. Do not to operate the unit if there is a gas leak. Have the appliance inspected annually by a qualified service person.  The pressure regulator and hose assembly provided with the appliance must be used. The replacement part must be the same as the part specified by manufacturer.

  • Page 5: Expanded View

    EXPANDED VIEW If you want to replace the parts listed, please contact Customer Service Center: 1(866) 578-6569 Origin of Country: China 5 / 12...

  • Page 6: Parts List

    PARTS LIST Label Part Number Description OF0141XXX01 Small Top OF0141XXX02 Big Top (pre-assembled) Inner Tank (pre-assembled) OF0141XXX03 Furnace OF0141XXX04 Base OF0141XXX05 Log Rack OF0141XXX06 LPUXLT00 Burner (pre-assembled) OF0141XXX07 Bowl (pre-assembled) LPDHZXY2L10 Ignition Wire (pre-assembled) LPRD07 Thermocouple (pre-assembled) OF0141XXX12 Pipework (pre-assembled) OF0141XXX13 Nozzle Subassembly (pre-assembled) LPDHQ2W30D27...

  • Page 7: Installation

    INSTALLATION Fig.3: Put Small Top (A) on the assembled Fig.1: Put Furnace (D) on Base Fig.2: Put Log Rack (F) on Base (E) fireplace body as shown in Fig 3. (E) as shown in Fig 1. as shown in Fig 2. Fig.4: Set up the Firewood as below: Put Firewood (2) on Log Rack (F) as shown in Fig 4-1.

  • Page 8: Location

    LOCATION Your Gas appliance must be installed on a flat, stable surface, away from any combustible materials or construction. SET-UP Your Gas appliance comes assembled, ready for a Gas connection. 1- Place the appliance on any level, outdoor, non-combustible surface. NOTE: Do not place this appliance on grass or dirt area.

  • Page 9: Operation

    Fig 6 Fig.6 Fig.7 OPERATION LEAK TEST !!!WARNING!!!  Do not use an open flame to check for leaks.  Do not smoke during testing.  Do not test indoors.  A leak check must be performed whenever the gas cylinder is replaced. Make sure the control knob is on the “OFF”...

  • Page 10: Storage And Maintenance

    NOTE: While in use, the burner flame should be mainly blue in appearance with a small amount of yellow. The flame can be identified by the following figure. H IG H Y ELLO W T IP B LU E LO W Correct Flame BLUE Incorrect Flame...

  • Page 11: Trouble Shooting

    • Permanent installation and repair should be done by a qualified service person. The appliance should be inspected annually by a qualified service person. TROUBLE SHOOTING PROBLEM OBSERVED POSSIBLE CAUSE CORRECTIVE MEASURES —Gas leak —See “If you smell gas:” on front cover of Gas odor manual —Check all gas connections...

  • Page 12: Cleaning And Maintenance

    CLEANING AND MAINTENANCE  To enjoy outstanding performance of your appliance for years make sure to perform the following maintenance activities on a regular basis.  Keep exterior surfaces clean.  Use warm soapy water for cleaning. Never use flammable, corrosive or abrasive cleaners. ...
