Thank you for purchasing this quality product.Be sure to check all packing
material carefully for small parts，which may have came loose inside the
carton during shipment，Count all parts and material hardware,then
compare with parts list to be sure all parts are present.If any parts
are missing or damaged，phone，fax，or mail to our Customer Servic
Department for efficient and speedy service . Please indicate the
model number and code letter of part(s) needed.
IMPORTANT NOTE: Follow instructions listed below in proper sequence as
numbered to assure fast, easy and correct assembly.
A
TOP PANEL-1PC
D
SHELF-1PC
G
D15
CAM LOCKS-4PCS
J
M3.5*30
SCREWS-9PCS
NOTE: THE SURFACE WITH THE STICKER IS THE BACK SIDE.
PARTS LIST
B
LEFT SIDE FRAME-1PC
E
SUPPORTING RAIL-1PC
H
L BRACKET-4PCS
K
D8*30
WOOD DOWELS-4PCS
2/7
C
RIGHT SIDE FRAME-1PC
F
D15
CAM BOLTS-4PCS
I
M3.5*15
SCREWS-16PCS
