CAUTION!
DO NOT OPEN
RISK OF ELECTRICAL
SHOCK
RIGHT
ANALOG OUTPUT
EMC 1_MKV.indd 1
C L A S S 1 L A S E R
P R O D U C T
Class A Laser Product
Complies with 21 CFR
1040.10 and 1040.11
L
R
LEFT
EMC 1 MKV
Reference CD player
Owner's Manual
EMC 1 MKV
F U S E :
200-240VAC: 1AT/250V
100-120VAC: 1AT/250V
VOLTAGE SELECTOR
MAINS INPUT
EN
ENGLISH
DESIGNED AND MANUFACTURED BY
EMC 1 MKV Balanced
Reference CD Player
BREIVIKVEIEN 7, 4120 TAU, NORWAY
S/N:
MAINS:115/230VAC
SPDIF
SPDIF
12 V
OUTPUT
OUTPUT
RS - 232
TRIGGER
TOSLINK
INPUT
COAX
21.11.2019 17:16:39
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ELECTROCOMPANIET EMC 1 MKV
Summary of Contents for ELECTROCOMPANIET EMC 1 MKV
- Page 1 EMC 1 MKV DESIGNED AND MANUFACTURED BY EMC 1 MKV Balanced F U S E : C L A S S 1 L A S E R Reference CD Player P R O D U C T BREIVIKVEIEN 7, 4120 TAU, NORWAY...
- Page 2 Welcome to the world of Electrocompaniet! We thank you for choosing an Electrocompaniet high-end product. At Electrocompaniet we are relentlessly focused on developing audio equipment that is capable of bringing the fabulous experience of the concert hall into the very heart of your home.
-
Page 3: Important Notice
For optimal sonic performance, the EMC 1 MKV should be burned in for a minimum time of 72 hours. The easiest way to burn in your EMC 1 MKV is to put a disc in REPEAT mode with the rest of your system turned off. In daily operation, switch off the CD player by using the STANDBY button on the remote. -
Page 4: Setup Procedure
Setup procedure How to remove a CD transport screws. 1. Remove the two wing bolts and the wing nut located underneath the unit. Remove Remove Remove 2. Unscrew the Allen screws holding the gold sign marked «Reference CD player » with the smallest Allen key and remove the transport lock bracket. -
Page 5: Navigator Controls
EMC 1 MKV 1. PLAY button 2. STOP button DESIGNED AND MANUFACTURED BY EMC 1 MKV Balanced F U S E : C L A S S 1 L A S E R Reference CD Player 3. NEXT TRACK button... -
Page 6: Remote Control
When using the remote control, the front end of the remote control should be pointed to the front panel of your EMC 1 MKV. A free line of sight is required between the remote and the infrared sensor on the front panel. -
Page 7: Loading A Disc
Start with the amplifier(s), then the signal sources. Loading a Disc 1. Load the disc by gently pushing the drawer marked: ELECTROCOMPANIET towards the rear of the unit. «Open» is shown on the display. 2. Place the disc on the spindle.Then place the CD-clamp on the spindle. The clamp now securely fastens the disc. -
Page 8: Technical Specifications
Technical specifications The following technical data were measured on randomized test objects and are typical data. All measurements are made at 120V / 240V // 50Hz / 60Hz. Mains fuse: 1 AT /250VAC Output level:............(unbalanced) 2.3Vrms/(balanced) 4.6Vrms Noise floor:...................... < -130dB Frequency deviation:................ - Page 9 1. A sales slip or other proof of purchase if repair is claimed under warranty. 2. A proforma invoice with value of goods, stating that the EMC 1 MKV is returned to Norway for repair. 3. An accompanying letter describing faults, symptoms, or problems with the unit.
-
Page 10: Ir Remote Control Codes
IR Remote control codes RC6 codes are denoted as xxx.yyy. xxx is 8 bit adress. yyy is 8 bit command code. All numbers in decimal. All RC6 codes are mode 0. Key label Code Type Code Hex STANDBY 04.0C 04.01 04.02 04.03 04.04... - Page 11 EMC 1_MKV.indd 11 21.11.2019 17:16:40...
- Page 12 Verify line voltage before use. Do not remove cover. No user serviceable parts inside. Refer servicing to qualified service personal. The warranty is void if the product is tampered by non-authorised personnel.Use only authorized Electrocompaniet service center. REV 1.0 2019 Designed and manufactured in Norway www.electrocompaniet.com...
