Malem MO7
Wireless Alarm + Record
Wetness Sensor
and
Toilet Trainer
Wireless 16 Channels 433MHz
Please read the instructions carefully before use.
For best results and trouble free operation, all instructions must be
adhered to and followed.
Caution:
The wetness Sensor is not intended to replace proper adult
supervision.
Advertisement
Related Manuals for Malem MO7
Summary of Contents for Malem MO7
- Page 1 Malem MO7 Wireless Alarm + Record Wetness Sensor Toilet Trainer Wireless 16 Channels 433MHz Please read the instructions carefully before use. For best results and trouble free operation, all instructions must be adhered to and followed. Caution: The wetness Sensor is not intended to replace proper adult...
- Page 2 Rx (4 X AA). 3. Remove isolating tags from battery compartments of both Tx (remove first) and Rx if new from Malem Medical. Rx will beep until signal is received from Tx. Allow up to 13 seconds. (Battery saving feature).
- Page 3 6. Attach Tx to pyjama or night dress top. With Bed-Mat, place Tx beside the bed or attach to head board. 7. Once Tx detects wetness, it will send a signal to the Rx. Please allow up to 13 seconds for the Rx to alarm.
- Page 4 Malem Wireless Alarm Enuresis Alarm Bed-Mat Sensor Instructions: Place the Bed-Mat over the mattress in the area which is normally wetted and gently tie down. Cover the bed-mat with a Clean Dry Cotton sheet and/or Bath Towel and make the bed up as usual.
- Page 5 Malem Wireless Alarm + Record Wetness Sensor and Toilet Trainer Wireless 16 Channels 433MHz Please read the instructions carefully before use. For best results and trouble free operation, all instructions must be adhered to and followed. Caution The wetness Sensor is not intended to replace proper adult supervision.
-
Page 6: Description And Function
Description and Function The wetness Sensor consists of a small Transmitter (Tx) and a portable Receiver (Rx). The Tx is powered by 2 X AAA alkaline batteries. The Rx is powered either by 4 X AA Alkaline batteries or via a 6 Volt power supply (not supplied). The Tx can be attached to the supplied Easy-Clip Sensor or to Standard sensor or to a Bed-Mat (optional extra). - Page 7 Hint: Place batteries in Tx before Rx. Average battery Life is about 7 days. External mains adaptor 6V DC +ve centre pin (not supplied) can be used to power the Rx. Encode Switch Make sure the encode switch is set to match the setting in the Tx encode switch. Red LED Indicator The Red LED will be ON and beep sound is activated until the Rx receives normal signals from the Tx.
- Page 8 Slide switch: Sound + LED + Motor or LED + Motor only (NO Sound). The Motor indicates the ability to plug in the optional Vibrating unit for silent alarm indication. Slide Switch: Message or Sounds or Melody. Choice of: recorded message or music or user’s name, inbuilt alarm sounds or inbuilt music.
- Page 9 The Wetness Sensor is guaranteed for one year. This excludes batteries, sensors and damage caused by accident, flood or misuse. Transmitting Frequency 433 MHz. Model No: MO7 CE Mark: Yes. EMC Tested and approved: Yes. EC- Certificate of Conformity according to the Electromagnetic Compability Directive (89/336/EEC).
- Page 10 Malem Wireless Alarm + Record MODEL MO7 Rx & Tx Red LED, flashes once/5 seconds (standby) Flashes once/second (wet) Standyby - Flash once/5 secs Alarm - Flash once/sec Use 2 x AAA Alkaline batteries Please observe correct polarity when replacing batteries...
- Page 11 Malem Wireless Alarm + Record Lift to remove belt clip Receiver (Rx) External Code Switch Vibrator (Remove Cover) (optional settings must Extra) match in Tx and Rx OPEN Volume control Test Button Press and hold DC 6C Power in to confirm...
- Page 12 Malem Medical 10 Willow Holt, Lowdham Nottingham NG14 7EJ, England, UK Tel: + 44 (0)115 966 4440 Fax: + 44 (0)115 966 4672 E-mail: malem@malem.co.uk Web: www.malem.co.uk © Malem Medical 2003...
