KGANP45011HW
SAFETY REQUIREMENTS
Installing and servicing heating equipment can be hazardous due to
gas and electrical components.
personnel should install, repair, or service heating equipment.
Untrained service personnel can perform basic maintenance
functions such as cleaning and replacing air filters. All other
operations must be performed by trained service personnel. When
working on heating equipment, observe precautions in the
literature, on tags, and on labels attached to or shipped with the
furnace and other safety precautions that may apply.
Follow all safety codes. In the United States, follow all safety
codes including the National Fuel Gas Code (NFGC) ANSI
Z223.1- -2006/NFPA 54- -2006. In Canada, refer to the National
Standard of Canada Natural Gas and Propane Installation Code
(NSCNGPIC) CAN/CGA- -B149.1 and .2- -M- -05.
Wear safety glasses and work gloves.
available during Start- -up, Adjustment steps, and service calls.
Recognize safety information. This is the safety- -alert symbol
When you see this symbol on the furnace and in instruction
manuals be alert to the potential for personal injury.
Understand the signal words DANGER, WARNING, or CAUTION.
These words are used with the safety- -alert symbol. DANGER
identifies the most serious hazards, those that will result in severe
personal injury or death. WARNING signifies a hazard that could
result in personal injury or death. CAUTION is used to identify
unsafe practices that may result in minor personal injury or product
and property damage. Note is used to highlight suggestions that
will result in enhanced installation, reliability, or operation.
This conversion kit shall be installed by a qualified service agency.
Please read these instructions completely before attempting
installation. Consult gas supplier and tables in National Fuel Gas
Code NFPA 54/ANSI Z223.1, 2006 or latest edition. In Canada,
the National Standard CAN/CGA B149- -1 and B149- -2- -05.
Installation Instructions
Only trained and qualified
Have fire extinguisher
NATURAL GAS TO PROPANE
Description
Burner Orifice #55
Honeywell Conv. Kit #396221
Switch, Low Pressure (LGPS)
Fitting Assy.
Wire Assy.
Label, Field Conversion
Label, Propane Conversion
Label, Derate
Instructions
Orifices for High Altitude Conversion
(Refer to Table 1 - - for required orifice)
Description
Burner Orifice #56
.
CERTIFIED
1
CONVERSION KIT
PG9YAA
Parts List
Part #
1011354
1172953
1008801
1009775
1173071
1009678
333681--- 101
2505235
IIKKGANP4501--- 001
Part #
1011355
Qty.
5
1
1
1
1
1
1
1
1
Qty.
5
Advertisement
Table of Contents
Related Manuals for Carrier PG9YAA
Summary of Contents for Carrier PG9YAA
- Page 1 KGANP45011HW NATURAL GAS TO PROPANE CONVERSION KIT PG9YAA Installation Instructions SAFETY REQUIREMENTS Parts List Installing and servicing heating equipment can be hazardous due to gas and electrical components. Only trained and qualified Description Part # Qty. personnel should install, repair, or service heating equipment.
-
Page 2: General Information
Disassembly WARNING FIRE, EXPLOSION, ELECTRIC SHOCK, CARBON MONOXIDE HAZARD Failure to follow this warning could result in personal injury, death, or property damage. This conversion kit shall be installed by a qualified service technician in accordance with the Manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. -
Page 3: High Altitude Installation
MANIFOLD PRESSURE AND ORIFICE SIZE FOR HIGH ALTITUDE APPLICATIONS PROPANE GAS MANIFOLD PRESSURE (IN WC) MEAN ELEVATION FEET ABOVE SEA LEVEL HEATING VALUE AT 0 to 2000 2001 to 3000 3001 to 3999 4001 to 5000 5001 to 6000 6001 to 7000 7001 to 8000 ALTITUDE BTU/CU. -
Page 4: Gas Pressure
Left Side Entry Right Side Entry Manual shut- off valve 1″ close nipple Drip Leg Alternative & Union # installation LP Low Pressure Switch Detail # Union should be outside cabinet except when Use elbows and 1″ close nipple to connect valve clearances disallow, then it may be installed to piping when using right side gas pipe entry. -
Page 5: Checking Input Rate
Start- -up and Check- -out Main Burner Flame Check Check for the following: (See Fig. 8) 1. Remove the plug from the Inlet Pressure Tap on gas valve and install a manometer. (Fig. 5) S Stable and blue flames. Dust may cause orange tips or wisps of 2. - Page 6 Catalog No: IIKKGANP4501---001 Copyright 2007 CAC / BDP D 7310 W. Morris St. D Indianapolis, IN 46231 Printed in U.S.A. Edition Date: 09/07 Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations. Replaces: NEW...
