Pedicraft Canopy Enclosed Bed
Before using the Canopy Enclosed Bed, carefully read this Operations Manual.
Be sure you understand all the information in this manual before using the bed.
Instructions for Use .........................................................................................................
Cleaning Instructions ......................................................................................................
Maintenance & Warranty ................................................................................................
Bed Assembly Instructions .............................................................................................
Canopy Cover Installation Instructions .......................................................................
Zip-Out Mesh Bottom Cleaning Instructions ..............................................................
For technical assistance call 800-223-7649
Pedicraft, Inc
4134 St. Augustine Road
Jacksonville, FL 32207
800-223-7649
904-396-9627
Fax 904-346-3947
www.pedicraft.com
Operations Manual
3
4
5
6
9
17
Rev. 9 - 091919
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Pedicraft Canopy Enclosed Bed
- Page 1 Pedicraft Canopy Enclosed Bed Operations Manual Before using the Canopy Enclosed Bed, carefully read this Operations Manual. Be sure you understand all the information in this manual before using the bed. Instructions for Use …………………………………………………………………………………………… Cleaning Instructions ………………………………………………………………………………………… Maintenance & Warranty ……………………………………………………………………………………...
-
Page 2: Maintenance Check
2 of 18 Note to end user: Record the following information about your bed and retain this manual for reference. Please have this information available if you contact Pedicraft about your bed. Model number _________________ Serial number _________________ Date received... - Page 3 Do not substitute the mattress provided with this bed with any other type or • size of mattress. The mattress must fit snugly to prevent gaps which may entrap the patient. Pedicraft Inc. 4134 St. Augustine Rd. Jacksonville, FL 32207 Ph: 904-396-9627 Rev. 9 - 091919...
-
Page 4: Cleaning Of Metal Surfaces
Wipe clean all parts of the Canopy Bed Cover with lukewarm, soapy water on a regular basis. The Canopy Enclosed Bed is equipped with a zip-out Bottom Mesh Section so that it can be easily removed and immersed in lukewarm, soapy water for thorough cleaning. -
Page 5: Warranty
• Warranty Pedicraft, Inc. guarantees the Canopy Bed frame components to be free of defects in workmanship or materials for a period of three years from the date of shipment to the purchaser. The Canopy Bed Mattress and Canopy Cover and bed frame padding and covers are guaranteed to be free of defects in workmanship or materials for a period of ninety (90) days from the date of shipment to the purchaser. - Page 6 2" bolts. Do not fully tighten. If bed is a height adjustable model, continue to next figure. If not, skip to figure 11. Pedicraft Inc. 4134 St. Augustine Rd. Jacksonville, FL 32207 Ph: 904-396-9627 Rev. 9 - 091919...
- Page 7 Reattach nut and washers. Tighten securely. Figure 7 Repeat to attach 3 remaining hydraulic cylinders at corners of bed. Figure 8 Secure hydraulic cables to bed frame with cable ties. Pedicraft Inc. 4134 St. Augustine Rd. Jacksonville, FL 32207 Ph: 904-396-9627 Rev. 9 - 091919...
- Page 8 Mattress Deck, Lower Support Bars, Upper Support Bars. With one person at each end of Bed Frame, raise Bed to upright position. Pedicraft Inc. 4134 St. Augustine Rd. Jacksonville, FL 32207 Ph: 904-396-9627 Rev. 9 - 091919...
- Page 9 These components will be used in numeric order. Please do not unwrap these components until they are to be installed so that they remain clean. Pedicraft Inc. 4134 St. Augustine Rd. Jacksonville, FL 32207 Ph: 904-396-9627 Rev. 9 - 091919...
- Page 10 Figure 20 Grasp each corner zip and place each end on opposite sides of the corner post of the bed. Pedicraft Inc. 4134 St. Augustine Rd. Jacksonville, FL 32207 Ph: 904-396-9627 Rev. 9 - 091919...
- Page 11 Figure 24 Zip closure should finish below the vinyl- coated padding (and above the hydraulic leg on height adjustable beds) on each corner post. Pedicraft Inc. 4134 St. Augustine Rd. Jacksonville, FL 32207 Ph: 904-396-9627 Rev. 9 - 091919...
- Page 12 Each person takes two corners of canopy cover and places them firmly over top of frame posts. Figure 28 The cover will now drop into place ready for the following actions. Pedicraft Inc. 4134 St. Augustine Rd. Jacksonville, FL 32207 Ph: 904-396-9627 Rev. 9 - 091919...
- Page 13 Otherwise skip to figure 39. Zipper is to be matched to zipper on Canopy cover. Figure 31 Join open ended zipper. Figure 32 Close zipper. Pedicraft Inc. 4134 St. Augustine Rd. Jacksonville, FL 32207 Ph: 904-396-9627 Rev. 9 - 091919...
- Page 14 Locate zipper ties for just-completed attachment of Padded Head and Foot Board to the Canopy Cover. These ties are marked with a thick gray stitch. Pedicraft Inc. 4134 St. Augustine Rd. Jacksonville, FL 32207 Ph: 904-396-9627 Rev. 9 - 091919...
- Page 15 Canopy Cover, close matching zippers on all sides. Figure 40 Continue to attach the zip-out bottom to Canopy Cover by closing matching zippers on all four sides. Pedicraft Inc. 4134 St. Augustine Rd. Jacksonville, FL 32207 Ph: 904-396-9627 Rev. 9 - 091919...
- Page 16 WARNING: Failure to tie both zipper ties around the bed leg could result in the patient exiting the bed. Wrap Velcro tabs at corners to complete the Canopy Cover installation. Pedicraft Inc. 4134 St. Augustine Rd. Jacksonville, FL 32207 Ph: 904-396-9627 Rev. 9 - 091919...
- Page 17 Untie zipper ties and unzip all four sides of the zip-out bottom. Remove zip-out bottom and clean according to cleaning instructions included in this manual. Pedicraft Inc. 4134 St. Augustine Rd. Jacksonville, FL 32207 Ph: 904-396-9627 Rev. 9 - 091919...
- Page 18 WARNING: Failure to tie all 4 zipper ties around the bed leg could result in the patient exiting the bed. Figure 52 Assembly is complete. Pedicraft Inc. 4134 St. Augustine Rd. Jacksonville, FL 32207 Ph: 904-396-9627 Rev. 9 - 091919...
