Summary of Contents for Harman JBL DSi Series
- Page 1 Power amplifiers QUICKSTART GUIDE MODELS | SA4, SA4-D, MA4, MA4-D, LA4, LA4-D...
- Page 2 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. mantenimiento. • Consult the dealer or an experienced radio/TV technician for help. JBL DSI SERIES POWER AMPLIFIERS...
-
Page 3: What's Included
SA4 Amplifier with Analog only Inputs Trademark Notice: Com-Tech, BCA, JBL, Amcron, DriveCore, Drivecore MA4 Amplifier with Analog only Inputs Install are Trademarks of HARMAN International.. LA4 Amplifier with Analog only Inputs WHATS INCLUDED SA4-D SA4 Amplifier with Analog + AES67 Inputs... -
Page 4: Front Panel Overview
LCD will flash “Mute”. Turns the amplifier power on or off. The Power button has an integrated power symbol that illuminates blue when the power is on and green when the power is off. JBL DSI SERIES POWER AMPLIFIERS... -
Page 5: Rear Panel Overview
REAR PANEL OVERVIEW COOLING VENTS AES67 PRIMARY / GENERAL PURPOSE INPUT ETHERNET Do not block/cover these vents. SECONDARY PORTS /OUTPUT (GPIO) (NETWORK CONTROL) PORT These two RJ45 connectors are This 8-pin block connector Connect this RJ45 port to used for AES67 Audio transport combines the 2-in, 2-out GPIO a computer or network for and are available only on the... -
Page 6: Installing The Amplifier
The rack should be a minimum of 2 inches (5.1 cm) away from the amplifier, and the back of the rack should be a minimum of 4 inches (10.2 cm) from the amplifier back panel. JBL DSI SERIES POWER AMPLIFIERS... -
Page 7: Hardware Setup
HARDWARE SETUP CONNECTING THE AC POWER CORD Connect your amplifier to the AC mains power outlet using the supplied AC power cord. First, connect the IEC end of the cord to the IEC connector on the amplifier. Then plug the other end of the cord to the AC mains. WARNING: The third (ground) prong of the supplied AC power cord connector is a required safety feature. -
Page 8: Wiring Input Connectors
Distance Wire Size Up to 25 ft. (7.6m) 16 AWG 26-40 ft. (7.9-12.2m) 14 AWG 41-60 ft. (12.5-18.3m) 12 AWG Figure 4c: Wiring output connectors > 60 ft (18.3m) 10 AWG JBL DSI SERIES POWER AMPLIFIERS... -
Page 9: Front Panel Menus & Navigation Overview
FRONT PANEL MENUS & NAVIGATION OVERVIEW MENU STRUCTURE The below diagram shows the DSI 2’s front panel menu Turn ENCODER structure, as well as how to navigate and control Home Screen channel volume. Adjusts System Volume(all channels) Press CH1 SELECT Button (hold button for CH1 Info) Turn ENCODER CH1 Selected... -
Page 10: The Home Screen
IP address, DSi 2 configuration, channel volume settings, and more. Current Device Preset Device IP Address HiQnet ID Configuration Figure 5a: Home screen Channel Volume Settings Error Messages Are Displayed Here Figure 5b: Home screen layout JBL DSI SERIES POWER AMPLIFIERS... - Page 11 DSI SERIES FEATURES Please refer to the DSi User Guide for in depth descriptions and instruction on the following features. CONFIGURING THE AMP Read how to configure the DSi 2 amplifier for your application using the front panel user interface. This includes assigning input channels, editing internal routing and DSP settings, and configuring output mode settings.
- Page 12 DEFECT. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATIONS OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. Refer to User Manual Page 79 & 80 for more details. © 2020 Harman International Industries, Incorporated CAT CTA 01/20...
