2 HP
2 Tank Air Compressor
Model 39750
ASSEMBLY and OPERATING INSTRUCTIONS
www.HarborFreight.com
Copyright
1999 by Harbor Freight Tools. All Rights Reserved.
No portion of this manual or any artwork contained herein may be reproduced
in any shape or form without the express written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353
Advertisement
Table of Contents
Related Manuals for Central Pneumatic 39750
Summary of Contents for Central Pneumatic 39750
- Page 1 Brought to You by Augusta Flint 2 HP 2 Tank Air Compressor Model 39750 ASSEMBLY and OPERATING INSTRUCTIONS www.HarborFreight.com Copyright 1999 by Harbor Freight Tools. All Rights Reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools.
-
Page 2: Specifications
It must be understood by the operator that common sense and caution are factors which cannot be built into this prod- uct, but must be supplied by the operator. Page 2 SKU # 39750 REV 06/03... - Page 3 If there is any doubt, do not operate the tool. 16. MAKE SURE ALL EQUIPMENT IS RATED TO THE APPROPRIATE CAPACITY. Do not attempt any operations or hook up any equipment that would exceed the rated capacities of this tool. Page 3 SKU # 39750...
-
Page 4: Electrical Set Up
Brought to You by Augusta Flint FEATURES OF YOUR #39750 AIR COMPRESSOR Handle OFF / AUTO Switch Air Filter Assembly Pressure Gauge Cylinder Air Outlet with Control Lever Oil Dipstick Power Cord Pressure Release Valve Electric Motor Cover Oil Drain Plug... -
Page 5: Setup And Operation
For best service, incorporate an oiler, a regulator, and a filter in line as shown in the above diagram. Hoses, Couplings, Fittings, Oilers, Regulators, and Filters are all available from Harbor Freight Tools. Page 5 SKU # 39750... -
Page 6: Operation
Never place flammable objects near the compressor. Never spray water or flammable liquids toward or near the compressor. Always turn the OFF/AUTO switch into the OFF position when the compressor is not in use. Do not transport the compressor while the tanks are under pressure. Page 6 SKU # 39750... -
Page 7: Maintenance
WARNING: Always turn off the compressor, unplug it from its power source, and release pressure from the air tanks before attempting any maintenance. MODEL # 39750 TWIN TANK AIR COMPRESSOR Please see Compressor Assembly Diagram on Page 8 Part # Description... - Page 8 Brought to You by Augusta Flint PARTS DIAGRAM MODEL # 39750 TWIN TANK AIR COMPRESSOR Please see Compressor Assembly Parts List on Page 7 Wiring Diagram Regulator Gauge To Reset White Switch Black Black White Line In Green To Windings...
