Replacing a dimm on an i/o module
Hide thumbs

Advertisement

Figure 1
1
On the memory slot on the front of the I/O module, rotate both spring clips out.
Step 10
Holding the edges of the DIMM with your fingers, slide it out of its memory slot
Step 11
and place it in an antistatic bag. See
78-100406-01
Metal Cover on the Back of the I/O Module
Metal Cover
Replacing Memory on a Cisco Nexus 7000 Series I/O Module
Replacing a DIMM on an I/O Module
Figure
2.
3
