1. Technical description.

1.1 General description.

The foot-operated button is used for transmitting signal indicating alarm situation occurrence, calling help (e.g. to
the alarm central, monitoring transmitter, controller). The foot-operated button converts the signal of pressed button into a
change of the alarm status. The PN-K foot-operated button is equipped with numerous programming functions which
enable the flexible adjustment to requirements of a particular installation. The pushbutton detector is made according to
the optical technology. The output signal is presented in a form of shorting/opening contacts of reed relay switch
(noiselessly). The atni-sabotage contact is based on a microswitch with gold-covered contacts the PCB surface has been
covered with lacquer to provide protection against damp and dust. The button has got a compact casing and is equipped
with rubber anti-slip feet.
Information about types:
Model
AWZ 700
PN
AWZ 710
PN-K

1.2 Description of elements and connectors on PCB.

Table 1.
Nr
[rys.1]
[1]
[2]
[3]
[4]
[5]
Table 2.
[1] [4]
TAMP
12V
GND
RST
C
NO
Foot-operated emergency button.
Foot-operated emergency button.
Foot-operated emergency button, programmable.
Anti-sabotage switch connector
Wire holder
PROG/RESET button
Supply connector and button output
LED (red) operations signaling (programming)
NC anti-sabotage switch output
Supply output DC (12V= +U, GND)
Button reset output
NC alarm transmitter output
1
AWZ 710
PN-K
v.1.0
Edition: 3 from the 9
Supercedes edition: 2 from the 10
Description
Element description
Connectors descriptions
EN
th
September 2010
th
July 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AWZ 710 PN-K and is the answer not in the manual?

Questions and answers

Summary of Contents for Pulsar AWZ 710 PN-K

  • Page 1 AWZ 710 PN-K v.1.0 Foot-operated emergency button. Edition: 3 from the 9 September 2010 Supercedes edition: 2 from the 10 July 2009 1. Technical description. 1.1 General description. The foot-operated button is used for transmitting signal indicating alarm situation occurrence, calling help (e.g. to the alarm central, monitoring transmitter, controller).
  • Page 2 Fig. 1. The view of PCB. 1.3 Technical parameters: - electric al parameters (tab.3) - mechanical parameters (tab.4) Table 3. Supply voltage 11V÷14V/DC (-/+5%) Current consumption 17mA/30mA (R=NO/R=NC) ALARM transmitter 0,5A@30Vdc/50Vac max. ALARM transmitter contacts C/NC ALARM transmitter operations mode monostable (210s max.), bistable or latch programming function RST output (RESET)
  • Page 3 6. Switch on DC supply (red LED shall flashes; signalization of operation start) 7. Program the button mode (see programming procedure). 8. Screw the button using two screws. 9. Perform functional tests. 3. Optical signalization. The button is equipped with the LED that indicates operations or programming status. LED- red: •...
  • Page 4 4.2. Programming diagram. 5. Service and operation. It is not necessary to perform any special maintenance operations, but if the power supply interior is significantly dusty, it shall be vacuum-cleaned by the compressed air.
  • Page 5 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (manufacturer) grants a two-year quality warranty for the equipment, starting from the date of purchase placed on the purchase order. 2. Should such purchase order be missing when the claim is submitted, the three-year guarantee period is counted from the date of the manufacturing of the device.
