  • Page 1 ASPIRATING SMOKE DETECTOR - 1 ZONE, 2 CHANNELS ART.IFT-P...

  • Page 3: Table Of Contents

    UMMARY 1 Description and operation ............................5 2 Installation and configuration ..........................8 3 Maintenance................................16 Specifications ..............................17 Connection examples ............................19...

  • Page 5: Description And Operation

    Tee fitting collector to connect two inlets. IFT-P monitors the airflow for both inlets. The analysis chamber consists of an optical chamber crossed by a laser beam, through which the air sample passes. Inside, a photoelectric sensor measures the amount of laser-produced light reflected by the particles of smoke as they pass through.
  • Page 6 1.3 Flow monitoring The monitoring system checks for any blockages, disconnections or gaps in the piping, making sure that the airflow level is not above or below the set thresholds. The flow thresholds are linked to the airflow specified during standardisation. Flow standardisation establishes the exact amount of air for that system during normal operation and sets this flow value to 100%.
  • Page 7 Power LED Blue LED, active when the detector is connected to the power supply. 1.6 Communication interfaces The IFT-P detector can be connected to a PC using the VSC software via an Ethernet port, a direct RS232 port or an RS485 port (RS232/RS485 converter).

  • Page 8: Installation And Configuration

      254.0 21.0 (0.83 170.0 (6.7 85.0 (3.35 180.0 140.0 (7.09 (5.5 164.5 (6.48 44.0 (1.73 208.5 (8.2 Figure 2-1: IFT-P Mounting diagram with dimensions...
  • Page 9 2.3 Connecting the detector The IFT-P detector is powered externally at 24 V. The inside of the detector can be accessed by removing the front cover. This is secured with four screws (one at each corner).
  • Page 10 Notes: please refer to appendix B for further information. 2.4 Connection interfaces The I/O connectors for the IFT-P detector are listed in the table below. Ethernet Allows TCP/IP connection with a PC which has VSC or VSM4 installed on it via LAN/WAN.
  • Page 12 CN3 - Auxiliary output 24 VDC Name Description 0VDC 24 VDC repeating output (to power an external warning device) 24VDC CN4: Remote reset input Name Description Input - 24 V opto-isolated input. Remote reset: Apply 24 V for 2 seconds. Remote isolate: Apply 24 V for at least 8 seconds.
  • Page 13 CN7 - Output relay Group Name Description FIRE 2 Fault relay activated when a fault event is detected. FIRE 1 Alarm relays (x 4) Alarm relay for each threshold (ALERT, ACTION, FIRE 1, FIRE 2) reached by the level of smoke detected. Notes: ACTION Maximum load for relays 2A @ 30 VDC.
  • Page 14 Connections for 4-relay expansion card (optional module) Output relay interface (i606) RELAY 1 Cable with minimum cross-section 7x 0.2 - 6A (24 AWG). Notes: maximum relay load 2A @ 30 VDC.  please refer to section D for further information. ...
  • Page 15 Piping Detector Input accommodated Max. length of piping IFT-P 25 mm (1 in) 25 mm 2 x 100 m External diameter 2.6 Startup After installation, the unit will need to be powered up in order to carry out the commissioning and procedures and ensure correct operation in accordance with the piping layout connected.

  • Page 16: Maintenance

    AINTENANCE Notes: maintenance should be performed by authorised personnel. 3.1 Inspection The following steps must be taken in accordance with local standards: 1. Check the LEDs at the front for fault indications; 2. Note any indications in your report; The following pages illustrate the maintenance procedures to be carried out for the detector. These procedures are only intended for authorised personnel.

  • Page 17: Specifications

    PECIFICATIONS Power supply Power supply 20 - 30 VDC Consumption (min.) Consumption (max.) 30 W Housing Dimensions 254 mm x 180 mm x 165 mm IP rating IP30 Operating conditions Operating temperature 0°C to 39°C Test temperature -10°C to 55°C Sampled air temperature -20°C to 60°C Humidity (non-condensing)
  • Page 18 Alarm Range 0.001 to 20% obs/m UL / ULC Special applications sensitivity  range is 0.001%/m – 1.6%/m (0.0003%/ft to 0.50%/ft). (For Special Applications approval must be obtained from the Local Authority with jurisdiction in the area). Open Area applications sensitivity ...

  • Page 19: Connection Examples

    ONNECTION EXAMPLES OUTPUT 2 OUTPUT 3 OUTPUT 4 VPS-250-E FUSE BOARD POWER SUPPLY PCB OUTPUT FAULT RELAY OUTPUT 1 DETECTOR I/O BOARD VBAT RS232 SHIELD RELAY OUTPUT FAULT...
  • Page 20 Figure B-1: Fault relay - Normally Closed...
  • Page 21 OUTPUT 2 OUTPUT 3 OUTPUT 4 VPS-250-E FUSE BOARD POWER SUPPLY PCB OUTPUT FAULT RELAY OUTPUT 1 DETECTOR I/O BOARD VBAT RS232 SHIELD RELAY OUTPUT FAULT Figure B-2: Fault relay - Normally Open...
