EXIRA SHOWER SET INSTALLATION
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing plumbing fixtures. Signature
Hardware accepts no liability for any damage to the
plumbing, floor, walls, tub, or for personal injury during
installation.
Observe all local plumbing and building codes.
Unpack and inspect the items for shipping damage. If
any damage is found, contact our Customer Relations
team at 1-866-855-2284.
GETTING STARTED
Ensure that you have gathered all the required
materials that are needed for the installation.
For the following installation instructions, it is
assumed that the wall has been opened and that the
existing shower set has been removed.
Before you begin, the main water supply to your home
should be shut off.
TOOLS AND MATERIALS:
Plumbers
Adjustable
Tape
Wrench
Tape Measure
Drill
Soldering Kit
Wood Blocking
(for copper pipe)
Level
Exira Shower Set Installation Instructions
SKU(s): 925470
Phillips
Screwdriver
Hex Wrench
½" Test Plug
Pencil or
Marker
1
Advertisement
Related Manuals for Signature Hardware EXIRA
Summary of Contents for Signature Hardware EXIRA
- Page 1 For the following installation instructions, it is assumed that the wall has been opened and that the Pencil or existing shower set has been removed. Level Marker Before you begin, the main water supply to your home should be shut off. Exira Shower Set Installation Instructions...
-
Page 2: Step 1: Valve Installation
The Important: Handle screws may be located in the small nipple should extend 9/16” beyond the finished wall. box containing other hardware. Do not discard. COLD Exira Shower Set Installation Instructions... -
Page 3: Step 2: Trim Installation
IMPORTANT: COMPLETE THE CONSTRUCTION OF YOUR WALL, INCLUDING ANY FINISHED WALL MATERIALS SUCH AS TILE, BEFORE PROCEEDING WITH THE REMAINDER OF THE INSTALLATION. STOP Exira Shower Set Installation Instructions... - Page 4 Remove the bar, then attach the brackets to the wall using the provided anchors and screws. Important: If drilling through tile, you must use a masonry drill bit and drill carefully. Exira Shower Set Installation Instructions...
- Page 5 fittings. Be sure to use the plumber’s tape to the threads before tightening. Hand decorative escutcheons to conceal the rough-ins. tighten the connections firmly. Apply thread sealant or plumber’s tape to the threads before tightening. Exira Shower Set Installation Instructions...
- Page 6 12. Turn the main water supply back on, and test the heads to the installed shower arms. Apply thread completed shower system. Ensure that there are no sealant or plumber’s tape to the threads before leaks and that all functions are working properly. tightening. Exira Shower Set Installation Instructions...
