Step 1: Unpack the two large packages

Carefully take out the main body, back cushion, seat cushion, pillow,
remote control, and armrests from the boxes.
Note: i7 PLUS requires at least two people to assist with
assembly.

Step 2: Assemble the Armrests

Please refer to Fig.3 and Fig.4 and follow the steps (1-5) below to
install the armrests.
1. Assemble armrest air tubes (Fig.3). Make sure the color
marks/numbers are matched.
2. Fix air tubes. Make sure air tubes are not bent (Fig.3).
3. Insert the axle into the located slot on the seat frame (Fig.3 and
Fig.4).
Fig.3: Armrest Installation
11
ATTENTION:
Be sure no children, pets, or objects
are around chair. Allow enough
space for installation
.
