- Page 1 Model P4017 Single Channel USB Oscilloscope Quick Start Guide...
- Page 2 All replaced parts, modules and products become the property of BNC. To obtain service under this warranty, the customer must notify BNC of the defect before the expiration of the warranty period. Customer shall be responsible for packaging and shipping the defective product to the service center designated by BNC, and with a copy of customer proof of purchase.
-
Page 3: Table Of Contents
1. General Safety Requirements ..................1 2. Safety Terms and Symbols ....................2 3. Ports Introduction ......................5 P4017....................Error! Bookmark not defined. 4. How to Implement the General Inspection ..............6 5. How to Connect with PC ....................6 6. -
Page 4: General Safety Requirements
1. General Safety Requirements Before any operations, please read the following safety precautions to avoid any possible bodily injury and prevent this product or any other products connected from damage. To avoid any contingent danger, this product is only used within the range specified. Only the qualified technicians can implement the maintenance. -
Page 5: Safety Terms And Symbols
2. Safety Terms and Symbols Safety Terms Terms in this manual. The following terms may appear in this manual: Warning: Warning indicates the conditions or practices that could result in injury or loss of life. Caution: Caution indicates the conditions or practices that could result in damage to this product or other property. - Page 6 (30Vrms) or on circuits of more than 4800VA: ● Use only insulated probes and adapter supplied with the test tool, or indicated by BNC as suitable for the Oscilloscope. ● Before use, inspect probes and accessories for mechanical damage and replace when damaged.
- Page 7 1:1 test leads because the probe tip voltage will be directly transmitted to the Oscilloscope. ● Do not touch the exposed part of metal BNC. ● Do not insert metal objects into connectors. ● Always use the Oscilloscope only in the manner specified.
-
Page 8: Ports Introduction
3. Ports Introduction Model P4017 Figure 3-1 Ports of the Oscilloscope 1. Probe Compensation: Measurement signal (3.3 V/1 kHz) output 2. MULTI Connector (optional): Connect Q9 cable with the MULTI port 3. MULTI port: EXT trigger input, trigger output or Pass/Fail output 4. -
Page 9: How To Implement The General Inspection
Enclosure" of this Manual. You can check if you have all the accessories by referencing Appendix A. If it is found that there is any accessory lost or damaged, please get in touch with the distributor of BNC responsible for this service or the BNC's local offices. -
Page 10: How To Implement The Function Inspection
2. Set the Switch in the Oscilloscope Probe as 10X and Connect the Oscilloscope with CH1 Channel. Align the slot in the probe with the plug in the CH1 connector BNC, and then tighten the probe with rotating it to the right side. -
Page 11: How To Use The Probe Safely
2. Check the displayed waveforms and regulate the probe till a correct compensation is achieved (see Figure 7-2 and Figure 7-3). Overcompensated Compensated correctly Under compensated Figure 7-2 Displayed Waveforms of the Probe Compensation 3. Repeat the steps mentioned if needed. Figure 7-3 Adjust Probe 8. -
Page 12: Appendix
9. Appendix Appendix A: Enclosure Standard Accessories: Passive probe: 1.2 m, 1:1 (10:1) (2 for dual-channel, 4 for four-channel) 1x CD (Supplied Software) 1x USB cable 1x Quick Guide 1x AC-DC adapter (only for the model with LAN port) Options: ...
