- Page 1 Manual DigitRadio 50 DAB/DAB+ UKW radio clock...
-
Page 2: Table Of Contents
Contents Pictures Safety of the appliance Security Setting up the device Disposal Guidelines and standards Properties of the device Preparing the device for operation Improve antenna reception Usage of headphones Switching the device on/off Initial use Volume adjustment Set display brightness Select DAB-/FM-Operation DAB mode What is DAB? - Page 3 Call Favorites Display Scan Settings Audio Setup Sleep Timer Alarm Clock Configure Alarm clock Snooze current alarm Switch running alarm clock off Time Set time / date manually Automatic update of time-/date Setting the Clock Format Setting the date format Language Factory setting Software version...
-
Page 4: Pictures
Pictures 1 2 3 4 5 6 7 8 1 2 display mode / menu Volume 3 / Standby 4 Tune / Select 5 6 DC jack 3.5mm stereo headphone jack 7 Snooze / Dimmer wire antenna 8 4... -
Page 5: Safety Of The Appliance
Safety of the appliance Please read all the safety instructions carefully and save this manual for future refer- ence. Always follow all warnings and instructions in this manual and on the back of the device. Security • The device should be connected only through the AC adapter to a mains voltage of 230 V, 50 Hz power. Never attempt to operate the unit with a different voltage. -
Page 6: Disposal
Disposal Risk of suffocation • Risk of suffocation due to the Packaging and its parts for children. Disposal of packaging • The packaging of your device consists entirely of recyclable materials. Please follow these sorted according to the “Dual System”. • About current means of disposal contact your dealer or at your community waste facility. -
Page 7: Properties Of The Device
Package Contents Please make sure that all items shown below are available : • DAB / DAB FM Clock Radio with wire antenna, • Power Supply, 6V, 500 mA, • Manual. Properties of the device The DAB + digital radio is a new digital format, through which you can hear crystal clear sound in CD quality. The radio receives on FM frequencies 87.5-108 MHz ( analogue) 174.9 to 239.2 MHz and DAB (digital). You can save 10 station on favorite program places the DAB or FM mode. The display has a light. This can be activated at different stages (see display illumina- tion ). Preparing the device for operation Connect the device with the supplied AC adapter to the mains (230 V ~ / 50 Hz). -
Page 8: Switching The Device On/Off
>If you want to listen through the speakers again, unplug the headphones from the headphone jack of the device. Switching the device on/off > You turn the device turn on or off by pressing volume / standby ( 3). Initial use When you use the device for the first time, as well as after calling the factory setting and switching on again, the channel search for DAB radio stations starts automatically. During scanning, the display shows the progress of information and the number of radio stations found. -
Page 9: Dab Mode
After changing only the small DAB or the FM logo is displayed right next to the time. DAB mode What is DAB? DAB is a new digital format, through which you can hear crystal clear sound in CD quality. DAB Broadcast a high-speed data stream in the radio channel. In difference to conventional analog radio DAB transmits multiple channels on the same transmitter. This is called ensemble or multiplexes. An ensemble consists of the radio station as well as several service components or data services, which are sent individually by the radio stations. Learn e.g. under www.digitalradio.de or www.digitalradio.ch. Data compression Digital radio uses the of advantages of human hearing. The human ear does not perceive sounds that are below a certain minimum level. -
Page 10: Automatic Search
Digital radio does not only offer perfect sound quality but also additional information. This may relate to the current program (e.g. title, artist) or might be independent (e.g., news, weather, traffic tips). Automatic Search As described in the initial installation the unit restarts automatically at the first start to search for DAB programs. This automatic search can also be restarted manually without having to revert to the factory setting. >To open the menu, press Mode / Menu (2). >Turn Tune / Select (4) until you have reached the menu point Full Scan. >Now press Tune/ Select ( 4) to start the search. After completion of the station search the last played radio station will be played. -
Page 11: Select Radio Program
Select radio program >Rotate Tune / Select ( 4) until the desired radio station is displayed. >Press Tune/ Select ( 4) to switch to the selected radio station. Save Favorites >To open the menu, press Mode / Menu (2). >Turn Tune / Select (4) until you have reached the point to save Progr. >Now press Tune/ select ( 4). -
Page 12: Drc ( Data Compression)
>Now press Tune / Select ( 4). >Select the desired favorite place by turning Tune / Select (4). >Start the playback of favorites by pressing Tune / Select (4). DRC ( data compression) The compression rate compensates varying dynamics and the associated volume varia- tions. -
Page 13: Display
>Now press Tune/ Select ( 4). >Select by rotating Tune / Select (4 ): • Yes, if you remove the transmitter • No if you want to cancel. >Confirm your selection by pressing Tune/ Select (4). Display >Open the menu by pressing the Mode / Menu (2). >Turn Tune / Select (4) until you have reached the point display. >Press Tune/ Select ( 4). -
Page 14: Manual Tuning
setting. Manual Tuning >Turn Tune / Select (4) until the frequency of the desired station appears. After a moment, the station will be played and the channel and program information will appear in the display in case of transmission from the station. Save favorites >To open the menu, press Mode / Menu (2). -
Page 15: Display
>Select the desired favorite place by turning Tune / Select (4). >Start a playback of favorites by pressing Tune / Select (4). Display >Open the menu by pressing the Mode / Menu (2). >Turn until you have reached the point display Tune / Select (4). >Press Tune/ Select ( 4). >Select by rotating Tune / Select (4) the display, which will be shown in the bottom line and press Enter to confirm Tune / Select (4). -
Page 16: Sleep Timer
>Now press Tune/ Select ( 4). >Rotate Tune / Select ( 4) to choose whether the sound should be played exclusively in mono ( mono only ) or, if available, also in stereo ( Stereo Audio ). If the sound is reproduced noisy, so the selection of mono only lead to a reduction of the noise. Sleep Timer The sleep timer can set the rest time for shutdown of your device. >Open the menu by pressing the Mode / Menu (2). - Page 17 Then proceed with selecting Alarm Clock. Alternatively >Open the menu by pressing the Mode / Menu (2) button. >Turn Tune / Select ( 4) until you have reached the point alarm clock. >Now press Tune/ Select ( 4). >Choose by rotating Tune / Select ( 4) the alarm clock, you like to enable or disable, create or edit.
- Page 18 > By turning Tune / Select (4) you select the duration (15, 30, 45, 60 or 90mins) for which the Device will be turned on, if not switched of manually before and confirm by pushing Tune / Select (4). > By rotating Tune / Select (4) you can now select the source (Buzzer, DAB or FM), which should be reproduced after switching on the device and confirm this by pushing Tune / Select (4). > If you have chosen DAB or FM in the previous step, choose now the radio station by turning Tune / Select (4) which should be played out after switching on the device and confirm by pushing Tune / Select (4). Note that you can only choose those previously served as favorite or last one played.
-
Page 19: Snooze Current Alarm
In the display the message that the alarm is stored appears. With an active alarm in the display you see the respective alarm icon next to the time displayed. Snooze current alarm Does the alarm clock switch on to set selected time, you have the possibility to let it snooze for additional five minutes before it restarts. > Push Snooze / Dimmer (7) to let the alarm clock snooze. The screen now displays the time until the displayed the next time the alarm Switch running alarm clock off >... -
Page 20: Automatic Update Of Time-/Date
The hours will start to flash. > Choose now by turning and pressing Tune / Select (4) the hour and minute of the current time and the date, month and year of the current date. The message of saving the time appears in the display. Automatic update of time-/date >Turn Tune / Select (4) until you have reached the point Auto Update. -
Page 21: Language
>Now press Tune/ Select ( 4). >Rotate Tune / Select ( 4) to whether the date in the format ( DD-MM -YYYY ) or ( MM-DD -YYYY ) should be displayed. >Confirm your selection by pressing Tune/ Select (4). Language >Open the menu by pressing the Mode / Menu (2). >Turn until you have reached the point Language / Select (4). >Now press Tune/ Select ( 4). >Rotate Tune / Select ( 4) to choose the desired operating language (German, English, Italiano, or Francais) out. -
Page 22: Software Version
>Rotate Tune / Select ( 4) to run the reset to factory setting ( Yes ) or to cancel (No). >Confirm by pressing Tune/ Select (4). When running the factory setting, the device restarts and is after that in standby mode. >Switch the device on by pressing Volume / standby ( 3 ) and then proceed as de- scribed under initial installation. - Page 23 Your device bears the CE symbol and complies with all requisite EU standards. Subject to change for amendments and pushing errors Version 2013 Duplication and reproduction only with the publisher’s approval TechniSat and DigitRadio are registered trademarks of TechniSat Digital AG Postfach 560 D-54541 Daun Germany www.technisat.com...
