Retekess TR505 User Manual

TR505 FM Transmitter User manual
Number Key
Microphone Volume
Soundtrack
/Volume
Songs/Currently
Playing Tracks
NEMO NIGHTWISH FLAC
Output Power
Current Working
Frequency
6.5mm Microphone
Interface
Power Switch Audio Line Interface
Power Outlet USB Audio Line
Interface
TF Card Outlet
PC Control Interface
Precautions For Use
• There is high pressure inside the machine,maintenance can only be operated
by professional and technical person.
• Please put the machine in a cool,dry and ventilated environment for use,the
ambient temperature should not be higher than 35 degree centigrades.
• After antenna installed, there should be 5 meters above from the ground and
wall spacing as standard installation environment.
• When installing the feed tube, be sure to tie the feed tube to the mounting rod
with a tie to prevent the feed tube from pulling loose on the connector.
• Do not turn on the machine without connecting the antenna.
• Please do not touch the antenna after machine is power on.
• Please do not use this machine in explosive atmospheres( eg gas stations,
gas,steam,etc).
• Please comply with local radio regulations.
1
Product Feature
• Display using high-standard OLED screen, 180-degree wide field of vision, high
contrast.
• Comes with high-fidelity TF card player, support lossless format FLAC / WAV,
compatible with a variety of other commonly used formats.
• TF card playback, support to display song name, sound mode, cycle mode
settings
• Support USB sound card input, to avoid the interference of audio line input
Function Key
• Support dynamic microphone, support reverb, delay parameter settings
Previous/Volume-
• Support reader mode, insert the data cable to connect the computer, you can
Next/Volume+
Play/Pause directly edit the TF card inserted in the machine
Return Key • Dedicated storage key, you can quickly store or set the frequency commonly
used
• Transmit power 0 ~ 25W continuously adjustable
• Standing wave protection, when the antenna is not connected or bad,
automatically enter the protection state
• Temperature protection, when the temperature inside the machine is too high,
automatically enter the protection state.
Digital Button Definition And Description
Temperature Display
Play Mode
Button
Currently Playing
Song
Numberic
Buttons
Reflect Power
Function Key Denifition And Instruction
Button
Function Key Denifition And Instruction
Frequency Setting
Short press the menu button
Figure 1 .
TNC Antenna Interface
Short press the
or
to exit the setting.
RF Power Setting
Short press the menu button
.
Figure 2
Short press the
or button the power to continuous step by 1 watt.Press the return key
to exit the setting.
Definition Instruction
At the current playing frequency, long press
Storage Key number keys to store the frequency, short press
the number key to extract the storage frequency.
Short press the switch to mute the sound, the
Mute screen soundtrack dispaly
mute switch again, turn off the mute mode.
Short Press Long Press
Menu
Previous Volume-
Next Volume+
Play/Pause
Return/Exit
, in the menu options interface, as shown in
or button frequency to step by 100K. Long press the
button frequency to continuous step by 1000K. Press the return key
, in the menu options interface, as shown in
or button the power to 0.1 watt step;Long press the
Figure 1 Figure 2
2
Sound Channel/Microphone volume
Short press the menu button
Figure 3 . Short press the
settings.
Short press the menu button
Figure 4 . Short press the
settings.
Press the return key to exit the setting.
Figure 3
MIC ECHO
Short press the menu button
Figure 5 . Short press the button
press the button , microphone reverb increases. Press the button
exit setting.
MIC Delay
1 to 8
Short press the menu button
Figure 6 . Short press the button
Short press the button , the microphone delay increases. Press the button
to exit setting.
, short press the
Figure 5
EQ Setting
Short press the menu button
Figure 7 . Short press the
Mode Selection: Normal - Classical - Pop - Rock - Jazz.
Press button to exit setting.
Loop mode
Short press the menu button
.
Figure 8
Short press the or
Mode Selection: All Cycles - Single Cycles - Shuffle.
Press the button to exit setting.
Figure 7
Language Selection
Short press the menu button
options interface, as shown in
Short press the or
selection.
Press the button to exit setting.
, in the menu options interface, as shown in
or button to adjust the sound channel
in the menu options interface, as shown in
or button to adjust the microphone volume
Figure 4
, in the menu options interface, as shown in
, microphone reverb decreases; Short
to
, in the menu options interface, as shown in
, the microphone to reduce the delay;
Figure 6
, in the menu options interface, as shown in
or to set Equalizer.
, in the menu options interface, as shown in
button to set cycle mode.
Figure 8
, in the menu
.
Figure 9
button for language
Figure 9
3
