7. Displays and Error Messages

7.1 Display

7.2 Error messages

36
During the boot phase of the control (after switching on the machine)
you will see first a display test, triggering once all luminous elements
of the display.
Then follows the "no-Pr---" display if no programme is contained in the
memory or the display of a sequence of figures if one or several
programmes are contained in the memory. For instance the figure
sequence "012-0565" is composed as follows: The first three figures
indicate the number of programmes and the last four figures the
number of all the assigned programme steps.
Then follows the changeover to the mode of operation that was active
prior to the switch off..
Error Explanation
number
Error 100 Undervoltage
Error 101-112 Processor error
Ir n
Error 200 No 24V power supply
Error n Error in data transmission
Error 300-324 to the sewing motor
HHH Reinforcing tape
Blinking not attached
band-err Tape feed has not reached Operate switch "b14" and
the forward limit switch
"b14".
P0 Er TA1 Undervoltage (<178V)
or
short power outage
Sewing motor not ready,
301
time out while receiving
receipt
communication error,
302
wrong byte, time out while
receiving status
303 STX not received, internal
hardware error, i.e.
commutator not plugged
in
304 wrong byte quantity sent
305
checksum error
310 STX not received
(command
SENDE_FLAG)
Remedy
Check mains voltage
---
Check power pack
Reset;
Check power supply to the
sewing motor;
Check cable;
Change drive control;
Change controller
Remove the remaining
band from the throat
plate canal (see Instructions
Part I, item. 4.9)
bring the tape feed into the
base position.
(Tape shears cut)
Check mains voltage
change DA-/Efka-control
change DA-/Efka-control
change DA-/Efka-control
change DA-/Efka-control
change DA-/Efka-control
change DA-/Efka-control
