FHDQ130
Fully optimised 130" all-in-one (AIO) QUAD LED display
Operation Manual
2019.11
Document version 1.70
Page 1 of 64

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FHDQ130 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Optoma FHDQ130

Summary of Contents for Optoma FHDQ130

  • Page 1 FHDQ130 Fully optimised 130" all-in-one (AIO) QUAD LED display Operation Manual 2019.11 Document version 1.70 Page 1 of 64...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Safety Notice Installation/Use Precautions of AIO Products Accessories Supplied Spare Parts Parts and Functions Interface Specifications Remote Controller Assembly Component Placement Intelligent Modules Installation Floor Stand Wall Mount Hanging How to Mount and Dismount Intelligent Module How to Assemble the Main Body How to Split the Main Body into two parts Packaging...
  • Page 3 Program Structure Program Page Program Window Program Edit Process Async Content Editing Publish Programs through USB/WIFI/LAN Publish Programs through USB disk Sync Playing Network and Management Connection and Management Add Group and Device APP Operation Instructions System Overview APP Installation Instructions APP Operating Instructions Search Terminals Terminal Control...

  • Page 4: Important Safety Notice

    Important Safety Notice ▪ Always ensure that the unit is properly earthed and power connections correctly made. ▪ This equipment must be supplied from a power system providing a protective earth connection and having a neutral connection, which can be reliably identified. ▪...

  • Page 5: Installation/Use Precautions Of Aio Products

    Installation/Use Precautions of FHDQ130 Products The interior design of FHDQ130 LED display screen is very sophisticated, but it basically has no dustproof/waterproof capability, please follow the following precautions during installation and use. 1) Screen storage/working environment requirements Storage temperature：-10~50℃；Relative humidity：10%~60%;...

  • Page 6: Accessories Supplied

    Accessories Supplied Item Description Photo Qty. AC Power Cable 14S-0GE16A-PZ-PF AC Power Cable 14S-0UL20A-PZ-PF AC Power Cable 14S-0BS13A-PZ-PF(Assembled) M10 Large-headed Screw 600-W32M10-20-PF Magnetic Tool 420-MAG130-A7-PF M4x10 Flat Head Screw 600-FM0410-DC-PF M10X16 Screw 600-HM1015-S0-PF M8x60 Expansion Screw 600- FM0860-10-PF M4x10 Screw(with plain and spring washer) 60S-WM0409-DC-PF M10 Flat Washer...

  • Page 7: Spare Parts

    Mounting Brace 420-TV1212-31-PF USB Flash Disk 333-DISK8G-00-PF Screwdriver 690-A25SDR-10-PF T-Hand Hex Key 690-DEM050-1A-PF Screwdriver 690-A15PBT-10-PF Infrared Remote Controller 898-IRC001-00-PF WIFI Dongle 898-00WUSB-00-PF Anti-static Gloves 690-ASHAND-20-PF Cordless Anti-static Wristband 690-ASWA15-00-PF EPE FOAM 540-A130BT-10/20-PF Accessories Check List Spare Parts Item Description Photo Qty.

  • Page 8: Parts And Functions

    Parts and Functions ◆ Interface Specifications Access SPECIFICATIONS Qty : 1 HDBaseT input Qty : 1 Panel Control: Telnet 3G-SDI Qty : 1 Qty : 1 RS232 Purpose : External Control (AMX) VGA input Qty : 1 Analog Audio Output Qty : 1 / stereo output 1/8″...

  • Page 9: Remote Controller

    Remote Controller Page 9 of 64...

  • Page 10: Assembly

    Assembly (Appendix E) for the detail dimensions. The list in table 1 is the main components of an FHDQ130 LED display. The intelligent modules are mounted to the front surface and the other main component locations are shown in Figure 1.

  • Page 11: Intelligent Modules

    ◆ Intelligent Modules The front face of the FHDQ130 LED display is fitted with 144 light emitting diode (LED) dot matrix modules known as Intelligent Modules. Each intelligent module is fitted with 14400 LEDs* plus associated drive electronics. Electrical connections (low voltage power, and digital data) are made to the rear of each intelligent module, from inside of the enclosure.

  • Page 12: Installation

    The FHDQ130 LED display is designed to be mounted on the stand (sold separately), on the wall or hanged(wall and hanging brackets included). When installing, it is important to ensure that the entire screen is correctly aligned, both vertically and horizontally.

  • Page 13: Wall Mount

    ◆ Wall Mount Mounting Plate Step1.Use 4 pcs M4x12 screws to install one side of the mounting brace to one mounting plate. Then install the mounting brace to another mounting plate. Mounting Brace M4x12mm Screw Page 13 of 64...
  • Page 14 Step2.Drill 30 pcs 10mm mounting holes (60-65mm depth) on the wall and install 2 pcs mounting plates with 30 pcs M8 x60 stainless steel expansion screws to the wall. Step3. After installing the mounting plates ,hang on the LED Display. Wall LED Display Mounting Plates...

  • Page 15: Hanging

    ◆ Hanging Step1.Install 12pcs M10X16 screws(with a spring washer and flat washer) to the back side of LED display. M10X16 Screw M10 Flat Washer M10 Spring Washer Step2.Hang the LED display. If there is a crane, hang the LED display with the help of the crane. Page 15 of 64...

  • Page 16: How To Mount And Dismount Intelligent Module

    ◆ How to Mount and Dismount Intelligent Module The FHDQ130 LED display is designed for maintenance front access, When the intelligent module malfunction; please replace it by the following procedure. Note:1.Install the modules after the display is assembled, cut off the power.
  • Page 17 Step 4. Pull the right handle towards the center. Step 5. Ensure the magnet is locked. Detach the tile carefully. Step 6. Put down the intelligent module and tool together carefully onto an EPE (or other soft pad). Step 7. Push the lock toward inside and pull the right handle toward outside and lift the tool up carefully. Mount Intelligent Module 1.

  • Page 18: How To Assemble The Main Body

    ◆ How to Assemble the Main Body The main body of display is split into two pieces, and all the accessories are attached to each part before shipping. Please follow below procedures to assembly two parts into a whole display. Note: 1.Don’t grab the four corners of display (after finishing assembling) when you want to move it from the floor, or the display will become deformed and affect the alignment.
  • Page 19 Note: Before locking the side-locks, you need to loosen the side-locks clockwise in place firstly. Step3. Install 12 pcs M4 flat head screws. Step4. Install 11 pcs M4 button head cap screws(with a plain washer and spring washer). Step 5. Install and tighten 3 pcs black M4 flat head screws to both upper and lower side of the case. Page 19 of 64...
  • Page 20 Step 6. Install and tighten 3 pcs black M4 flat head screws to both top and bottom side of the case. Step 7. After assembling the main body , you need to connect all the cables and install back all the intelligent modules. Please refer to ‘How to dismount intelligent module’...

  • Page 21: How To Split The Main Body Into Two Parts

    Step 8. All the intelligent modules have labels stuck on the back side. Please follow below number to install back the intelligent modules. We recommend that all the intelligent modules are installed to the corresponding position on case ,or the screen will show color difference.
  • Page 22 Step 2.Loosening 3pcs black M3 flat head screws from both upper and lower sides of panel. Step 3.Loosening 3pcs black M3 flat head screws from both top and bottom sides of panel. Step 4. Disconnect all the cables which used to connect the left and right part. Power cable When disassembling ensure that you disconnect RJ45 and power...
  • Page 23 Step 5. Rotate side-locks clockwise to loosen. Step6. Loosening 12 pcs M4 flat head screws. Step7. Loosening 11 pcs black M4 button head cap screws(with a plain washer and spring washer). Step 8. Holding the reinforced rib and disassemble the display. Page 23 of 64...

  • Page 24: Packaging

    ◆ Packaging Flight Case 1. Put all intelligent modules into antistatic bags separately and set them into the flight case. 2. Take out an PE bag and put one part of display into the bag. Seal the bag. Use the same method to package the other part of display.

  • Page 25: Electrical

    ◆ Earth Leakage Considerations Each FHDQ130 LED display has earth leakage current contributions from twenty-five switched-mode power supplies and two filters. The total earth leakage current per LED display can be up to 25.35mA at 240V. If a 30mA RCD is used, then the maximum number of LED display s per section should be safely limited to 1.

  • Page 26: Ac Power

    ◆ AC Power The AC power cable is connected to the EMI filters and distributes to the power supply units inside the display. Color of Wire A.C. Supply connection (200V) A.C. Supply connection (240V) Brown AC. Live AC. Live Blue AC.

  • Page 27: Settings

    Settings ◆ Software Installation The software supports operating systems such as Windows XP \ Server 2003 \ Vista \ Windows 7 \ Windows 8\ Windows10. Recommended computer configuration is: CPU 2.0 GHZ above; Memory 1 GB or more; Independent graphics card, display memory 512MB or more, and must has the DVI or HDMI output interface; User can adjust configuration according to actual situation, mainly according to total LED screen pixels, program complexity and video whether is high-definition video source or not, etc.
  • Page 28 3. Check the components you want to install and uncheck the components you don’t want to install. Click [Install] to start the installation. Figure 3 4. Click [Finish] when control Q has been installed on your computer. Figure 4 5. The system automatically generates desktop shortcuts, double click to open the software. 6.

  • Page 29: Software Settings

    ◆ Software Settings After starting the Control Q software, you can see the software interface show as below. Include play interface (Figure 5)and main interface(Figure 6). Figure 5 Main interface include six section:1.Menu 2.Main Toolbar 3. Program Edit Toolbar 4. Program Public 5.Program Property 6.
  • Page 30 1. Click [Control]-[LED Screen Setting], there will show a popup window to input the password [optoma]. Figure 7 Figure 8 Page 30 of 64...
  • Page 31 Figure 9 Page 31 of 64...

  • Page 32: Usb/Wifi/Lan Connection Settings

    ◆ USB/WIFI/LAN Connection Settings After connecting successfully, you can send related screen parameters, upload programs, manage programs, cloud management, etc. 1. USB Connection (1) Power on LED connect your PC via USB-A to USB-C cable (Use USB-B config port on AIO QUAD display, (2) Click the icon to enter Program Publish interface.
  • Page 33 2. USB Disk Play Approach There are two ways for playing the USB port media content: Approach 1 : Plug & Play Media content will be played automatically within alphabet order. Approach 2: Programmed Play 1) Program needs to use Control Q to edit in advanced 2) Store program into USB System Control Board supports the Media formats .ts .mp4 .avi .mkv .mov .bmp .jpg .png .jpeg The media files and program are stored in the USB disk in the same time.
  • Page 34 Figure 13 Step 2. Click Control\Screen Size and Count Setting, then key in width=1920,Height=1080. Figure 14 Figure 15 Page 34 of 64...
  • Page 35 Step 3. Open software Control Q and click a : Play Box Management b : USB Disk Figure 16 Step 4. In Program Editing Area, Click c : Press “+” d : Normal page Figure 17 Figure 18 Page 35 of 64...
  • Page 36 Step 5. Click e : Press “+” f : File Window Figure 19 Figure 20 Page 36 of 64...
  • Page 37 Step 6. Click g : Press “+” h : then Add the file type what you want to play Note : In order to make the video to fit the screen, the Video resolution must be 1920x1080. Figure 21 Step 7. Then we can see the content window for editing. If you want to add more content, repeat Step3~6. Figure 22 Step 8.
  • Page 38 Figure 23 Step 9. Click Mouse right button / Publish program to the selected USB disk, key in Publishing Name / OK Figure 24 Page 38 of 64...
  • Page 39 Figure 25 Step 10. After publishing program successfully Insert USB disk into System Control Board USB port Switch the signal source to the internal Media player(System Control Board) Wait a moment, the content will paly. Note: A rotating circle on the LED’s upper left corner will appear during the updating procedure. You may unplug the USB drive after the circle disappears.
  • Page 40 Before using WiFi please connect USB dongle (provided) to the USB 2.0 port of the AIO QUAD and power on. (1) Click LED after connecting successfully, then click [More] and input password ‘optoma’ in the pop-up display window, you will see the interface showed below. Check [WIFI] in network tab, and input your WIFI login information for [SSID] and [Password], then click [Apply] and [Refresh] to complete setting, click [ Detail...] to...
  • Page 41 4. WIFI Hotspot Input [SSID] and [Password] to use a WIFI Hotspot. [Band]: 2.4GHz or 5GHz, 5GHz is available if your smartphone or PC can support 5GHz WIFI. [Channel]: There are 1-14 optional channels to avoid network jam. Figure 29 5.

  • Page 42: Basic Settings

    ◆ Basic Settings ▪ Ensure LED display is functioning normally before setting LED display parameters. ▪ Connect LED display to PC with a standard USB-A Male to USB-B Male cable to set LED display parameters. 1. Play Box Date and Time: Click [Modify] to set up date and time, or time zone as well. 2.
  • Page 43 6. Playing Parameters (1)Screen Resolution The [Width] / [Height] has to be equal to or slightly larger than the actual screen resolution. (2)Output Every Frame (Default) Every Other Frame (Choosing [every other frame] can help avoid lag when image loading area is too large). (3)Control Area Suggest to select [Custom] in control area, and modify the values according to your network interface control area, click [Apply] to complete setting.

  • Page 44: Program Editing

    Program Editing ◆ Main Toolbar The main toolbar provides the most commonly used tool shortcut icons, including program file operation, display / hide of the play window, switch between dual monitor, editing / stowage of the software main interface, program playback, sending program to dual mode card , close / display large screen, cloud release, view help and other functions.

  • Page 45: Program Edit Toolbar

    ◆ Program Edit Toolbar From left to right 1. Add program windows or play content bars: Add program windows or play content bars in the corresponding position. 2. Copy: Copy the selected items and everything below. 3. Paste: Paste the copied contents 4.

  • Page 46: Program Page

    LED display: It decided what to display to the LED large screen. Each "LED display" is a parallel relationship and can add multiple program pages. Program page: normal page and global page. Play content: The specific content displayed on the LED screen. Including video, picture, GIF, FLASH, text files, Office files, Excel worksheet, clock, timing, web page, database, weather forecast, external video, environmental information, sports score, desktop copies.

  • Page 47: Program Window

    Global Page: A program page that has been played during playback and can contain multiple windows Global page and normal page are synchronized, and the global page is always located at the top of the normal page. If you want to display content such as clock, weather forecast, corporate logo, etc. in a fixed location, you can edit the media to the global page.

  • Page 48: Program Edit Process

    ◆ Program Edit Process 1. Set the screen size It is very important to set the screen size correctly , Otherwise, the program may display incomplete or abnormal display . 2. How to set the screen size Click the main menu [Control Screen] → [Screen Management], pop-up screen management window, set the number of LED screen, the starting position, size, etc..

  • Page 49: Publish Programs Through Usb/Wifi/Lan

    ◆ Publish Programs through USB/WIFI/LAN The same method can be used in USB/WIFI/LAN connections. (1)In program editing area , after finishing program editing, select the program page that you are going to publish; (2)In [Program Publish], click [Normal Page 1] and then right-click LED display to choose [Publish current program to the selected player], rename and upload the program to publish.
  • Page 50 Figure 11 Note: Recommend to remove previous contents of the USB disk before using it to update or play new contents, so as to avoid any problems. (3) Auto identify the inserted USB disk click [USB Disk] to choose [F]. 1.

  • Page 51: Sync Playing

    Note: A rotating circle in LED upper left corner will appear during the update procedure. You may unplug the USB disk after the circle disappears. Figure 13 ◆ Sync Playing In sync play, your LED plays contents sent to its HDMI port by an external source like your PC. display Note: LED display...

  • Page 52: Network And Management

    (2) Network management: After the controlled terminal (PC, Mobile devices, etc) and LED are connected display into the same LAN, unplug the USB cable,select [LAN] ,right-click and choose[Refresh], FHDQ130 processor will auto identify LED and place it into Default Group. You can manage your LED under Default Group.

  • Page 53: App Operation Instructions

    APP Operation Instructions ◆ System Overview 1) Optoma Control Q supports system which is higher than Android 5.0. 2) Optoma Control Q supports all the C series products. ◆ APP Installation Instructions Log in Google Play and search LH display , download and install the App.

  • Page 54: Search Terminals

    ◆ Search Terminals Click the icon at the top left corner and select the terminal list. The terminal list will display all the devices in the current LAN, as shown below. If the list doesn’t display any device, you can pull down or hit the to refresh list.
  • Page 55 Signal： Asynchronous and synchronous HDMI switching Terminal：on/off switch，volume adjustment Screen： on/off switch Brightness and color temperature：Brightness/color temperature adjustment B. Programs Click [PROGRAMS] and select the program to complete the program switch. Long press the program 2 seconds to enter the delete selection, you can choose to delete the program you want to delete. C.

  • Page 56: Edit Program

    ◆ Edit Program Open the APP, click the top right button to select [Edit Program], and enter the editing interface. Please refer to below screenshots for details. A. Set the screen size Click here Page 56 of 64...
  • Page 57 B. Set the window size and add content Maximize the Delete ,Item ,Upload window Add file(phote,video,text,clock) Manually drag to change window size Set the window size Border setting Page 57 of 64...

  • Page 58: Version Information

    C. Upload program New program Upload Program Layer selection Long press to move the program up and down ◆ Version Information Select the terminal in the terminal list, and then click the upper right button to view it, as shown below. Page 58 of 64...

  • Page 59: Appendix

    SPECIFICATIONS Appendix A Parameter Unit Value Brightness Nits 600(Max) Color temperature deg. K 6,500 Viewing angle - Horizontal (50% brightness) deg. 160(+80/-80) Viewing angle - Vertical (50% brightness) deg. 160(+80/-80) Panel weight(max) kg / lb 125/275.5 weight(max)(sq.m) kg / lb 26/57 Panel diagonal/ Display diagonal mm / ft...
  • Page 60 PC Compatibility Refresh Rate Mode Resolution (Hz) HMDI 1 HDBT HDMI 2 SVGA 800 x 600 1024 x 768 720p 1280 x 720 WXGA 1280 x 800 SXGA 1280 x 1024 FWXGA 1366 x 768 SXGA+ 1400 x 1050 WXGA+ 1440 x 900 UXGA 1600 x 1200...

  • Page 61: B Procedure For Intelligent Module Replacement

    Appendix B Procedure for Intelligent Module Replacement When you find the intelligent module is malfunctioning, you can replace it with the following procedure: 1. Power off the LED display; 2. Locate the problem intelligent module; 3. Remove the intelligent module with the magnetic tool; 4.

  • Page 62: D Mechanical Assembly

    Appendix D Mechanical Assembly Page 62 of 64...
  • Page 63 Page 63 of 64...

  • Page 64: E Rs232 Commands

    Appendix E RS232 Command List Appendix F WiFi Password 123456789 Page 64 of 64...
