Planet Networking & Communication HDP-5260PT User Manual page 47

Door Phone
Field Name
Description
Enable Access Table
Hot Key Dialed Mode
Selection
Call Switched Time
Day Start Time
Day End Time
Address of Log Server
Port of Log Server
Enable Log Server
Enable Indoor Open
Enable Card Reader
Limit Talk Duration
Door Unlock Indication
Remote Access Code
Check Length
720p SIP Multi-unit Apartment Vandalproof Door Phone with RFID & PoE
Description
password length is 4.
Device description displayed on IP scanning tool
software.
Enable Access Table: enter <Access Code> for
opening door during calls.
Disable Access Table: enter <Remote Password> for
opening door during calls.
<Primary/Secondary> mode allows system to call
primary extension first; if there is no answer, it would
cancel the call and then call secondary extension
automatically.
<Day/Night> mode allows system to check the calling
time belonging to Day or Night time, and then decide
to call number 1 or number 2 automatically.
Users just press speed dial key once.
The period between hot keys dialing to the first and
second number.
The start time of the day when you select
<Day/Night> mode.
The end time of the day when you select <Day/Night>
mode.
Log server address (IP or domain name)
Log server port (0-65535)
Enable or disable to connect with log server
Enable or disable to use indoor switch to unlock the
door.
Enable or disable card reader for RFID cards.
If enabled, calls would be forced to end after talking
time is up.
Indication tone for door unlocked. There are 3 types of
tone: silent, short and long beeps.
The remote access code length would be restricted
with it. If the input access code length is matched with
it, system would check it immediately.
47
HDP-5260PT
Initial Value
HDP-5260PT Video
Sip Door phone
Enable
Primary /secondary
16 seconds
06:00
18:00
0.0.0.0
514
Disable
Enable
Enable
Enable
Long beep
4
