- Page 1 Queue Wireless Calling System User Manual T116 EU Importer Name：Germany Retevis Technology GmbH Address：Uetzenacker 29,38176 wendeburg...
-
Page 2: Product Introduction
Retekess T116 Queue Wireless Calling System User Manual Product introduction Thanks for using our company's wireless calling system, it adopts RF wireless technology with millions of different learning codes. The system consists of 1 call button keypad and 20 portable receivers, the receiving pager supports 999-channel extensions, the call button keypad has 20 battery charging slots. -
Page 3: Technical Data
The diagram of the receiver Paper slot Reset Pair Mode Built-in battery Charging pins Transparent cover Stickers Front Side Back Technical data Receiver Working voltage DC 3.7V (Rechargeable battery) Charging voltage DC 5V Working frequency 433.92MHz Standby current 10±5mA Working current 100±20mA (Max.) Receive sensitivity -107±2dBm... -
Page 4: Function Description
Operation instruction 1. Open the package, connect the call button keypad to power, it executes the self-testing procedure, then power icon turns on. 2. When guest places an order, the service people give one receiver to him(her) and note down the number. -
Page 5: Packing List
Five mode cycle switching, when switching to the corresponding mode, the receiving card shall remind the time 5 sec according to the corresponding reminder mode. Change Stickers Take out the transparent plexiglass cover in the front of the pager, then put a Sticker inside the paper slot, and then put back the cover. - Page 6 Exposure awareness can be facilitated by the use of a product label directing users to specific user awareness information. Your Retekess radio has a RF Exposure Product Label. Also, your Retekess user manual, or separate safety booklet includes information and operating instructions required to control your RF exposure and to satisfy compliance requirements.
- Page 7 RED Directive 2014/53/EU and the ROHS Directive 2011/65/EU and the WEEE Directive 2012/19/EU; the full text of the EU declaration of conformity is available at the following internet address: www.retekess.com. • Disposal The crossed-out wheeled-bin symbol on your product, literature, or packaging reminds...
- Page 8 • The operating temperature of the EUT can’t exceed the specified range. Approved Accessories • This radio meets the RF exposure guidelines when used with the Retekess accessories supplied or designated for the product. Use of other accessories may not ensure com- pliance with the RF exposure guidelines and may violate regulations.
