Retekess TT107 Instructions

Wireless Transmission System
Model: TT107
Power
Turn off receiver
mute
Audio input port
Charging mouth
Power
The volume +
The volume -
EU Importer
Name：Germany Retevis Technology GmbH
Address：Uetzenacker 29,38176 wendeburg
Henan Eshow Electronic Commerce Co., Ltd
Add: 7/F, Sanjiang Building, No.170 Nanyang Road, Huiji District,
Zhengzhou, Henan, China
Speech transmitter: TT107

1. ON/OFF operation

●
Power on: in the shutdown mode, long press "switch key" for 2 seconds,
the red light goes out, and when the blue light comes on, let go.
●
Power off: in power-on mode, press "on/off" button for 2 seconds, until all
indicator lights go off.
2.
Operation
●
Pairing:in the shutdown mode, long press "switch key" for 6 seconds until
the red and blue lights flash alternately, and the transmitter enters the pairing
mode, In the matching mode, the transmitter and receiver can be paired at
close range (within 2 meters). Press any key to exit the pairing mode and
then speak.
●
Deputy transmitter: the main transmitter enters pairing mode ,The
transmitter that needs to be copied hold down "mute" button and then
press "on/off" button for 6 seconds. blue light and power lights on for 2
seconds at the same time, after the successful copy of the blue light long
bright, sub machine short press the switch key, shutdown can be.
(Note: after successful replication, there is no distinction between the main
transmitter and the secondary transmitter, depending on which one connects
to the receiver first.)
●
Mute: press "mute" to start and turn off the mute function.When mute, the
blue light is on for 2 seconds and off for 0.5 seconds; Non-mute: the blue
light is on for 0.5 seconds and off for 2 seconds.
●
Turn off receiver: in connection mode of transmitter, press "turn off
receiver button" for 5 seconds until red and blue lights flash simultaneously,
indicating it is in turn off receiver mode, Press any key to exit the state.
●
Channel switching: in the boot mode, long press "mute" for 3 seconds, and
the red light displays for 1 second, indicating that the channel has switched
to the next channel, and the receiver will automatically follow.
●
Delete the secondary transmitter: the main transmitter is in working mode,
the secondary transmitter holds down "mute" and "turn off receiver" and then
holds down the power button for 6 seconds. The red and blue flash
alternately, and the power lamp lights up for 2 seconds, completing the
deletion function, It is only used to delete the secondary transmitter, but the
main transmitter cannot be deleted.

3. The LED display

●
Working mode: blue light is on for 0.5 seconds and off for 2 seconds
●
Pairing mode: red and blue lights flashing alternately
●
Turn off receiver mode: red and blue lights flash together
Charging mouth
●
Mute mode: blue light is on for 2 seconds and off for 0.5 seconds
●
Low electric prompt: red light flashing slowly
●
Channel change: red light for 1 second
●
Duplicate transmitter: blue light on for 2 seconds/power on for 2 seconds
4.power consumption
Speech receiver: TT107
1. ON/OFF operation
2.Operation
3. The LED display
4.power consumption
1
●
Delete transmitter: red and blue alternating flicker
corresponding pairing mode
●
Connection mode: 54mA
●
Power on: in the shutdown mode, long press "on/off" for 1.5
seconds, the red light goes out, and when the blue light comes on,
let go.
●
Power off: in power-on mode, press "on/off" button for 1.5 seconds
until all indicator lights go off.
●
Pairing: turn on the receiver, close to the transmitter, keep the blue
light on, pairing is successful.
●
Power saving mode: after the transmitter is turned off, the receiver
enters power saving mode after 30 seconds.
●
Connection mode: blue light is on for 0.5 seconds and off for 2
seconds
●
Connectionless mode: blue light is on for 0.5 seconds and off for 1
second
●
Power saving mode: the blue light is on for 0.5 seconds and off for 5
seconds
●
Low electric prompt: red light flashing slowly
●
Connection mode: 16mA
●
Power saving mode: 1mA

Precautions

●
The transmitter and receiver are not used for a long time.
Please charge every 3 months to protect the battery. (If the
battery is not used or charged for a long time, it will cause the
battery to be not durable.)
