Technical Bulletin
Type
Policy Letter
√ Service Information
Attention
Service Managers
√ Service and Parts Managers
Models
AAV1200AGW, AAV1200AJW, AAV1200AKW, AAV1200ARW,
AAV1200AWW, AAV2200AGW, AAV2200AJW, AAV4200AGW,
ALW221RJW,CAV1000AWW, CAV2000AGW, CAV2000AJW,
CAV2000AKW, CAV2000AWQ, CAV2000AWW, CAV4000AWW,
CW5000W, CW6000Q, CW6000W, CW7500Q, CW7500W, DLW231RAW,
HAV1200ARW, HAV1200AWQ, HAV1200AWW, HAV2360AWW,
HAV2460AWW, HAV2557AWW, HAV2558AWW, HAV3460AWW,
HAV4200AKW, HAV4200ATW, HAV4200AWW, HAV4657AWW,
JAV4200AWQ, LNC6760B71, LNC6762B01, LNC6762B71, LNC6764A71,
LNC6766B71, MAV2200AJW, NAV3200AWW, NAV4200AGW,
NAV4200AKW, PAV1200AWW, PAV2200AAW, PAV2200AGW,
PAV2300AGW, PAV2300AWW,PAV2360AWW, PAV3200AAW,
PAV3200AGW, PAV3240AWW, PAV3300AGW,PAV3300AKW,
PAV3300AWW, PAV3360AWW, PAV4960AWW, PAV5000AWQ,
PAV5000AWW, PAV5057AWW, PAV5058AWW, PAV5157AWW,
PAV5158AWW, PAVT234AWW, PAVT244AWW, PAVT344AWW,
PAVT444AWW
Issue
Wash basket leans to one side, generally to the right as you face the washer
during spin cycle.
Warranty
Standard product manufacturing warranty applies.
Action
Replace original base with Kit 12002701. The replacement of the base, new snubber,
and six springs (included in the Kit) will reduce tub lean to an acceptable level.
NOTE: Some tub lean is normal.
1. Disconnect power supply to unit.
2. Tilt washer and remove belt from underside of base.
3. Remove back cover to access and remove drain hose clamps.
NOTE: There will be water remaining in the hose from the last cycle.
© 2005 Maytag Services
Date:
September 2005
No:
TDL-0050B-B
ITDL-0020A-B
Page 1 of 4
Supersedes TDL-0050A-B
ITDL-0020-B
Brand
Admiral
Amana
Crosley
Jenn-Air
Magic Chef
Maytag
Maytag Performa
Product
Laundry

Advertisement

Table of Contents

   Summary of Contents for Maytag AV1200AWQ

  • Page 1 1. Disconnect power supply to unit. 2. Tilt washer and remove belt from underside of base. 3. Remove back cover to access and remove drain hose clamps. NOTE: There will be water remaining in the hose from the last cycle. © 2005 Maytag Services...
  • Page 2 Repeat for both sides. Remove front panel by removing screws, one on each side of the top edge of front panel. 6. Remove motor ground wire, motor shield, and motor wire harness connector. Page 2 of 4 TDL-0050B-B © 2005 Maytag Services 9/30/2005 ITDL-0020A-B...
  • Page 3 11. Be sure to wash hands to remove any dirt or grease before handling new snubber. Clean new snubber with alcohol before installing. Install new snubber. Insure snubber is centered. Snubber TDL-0050B-B Page 3 of 4 © 2005 Maytag Services ITDL-0020A-B 9/30/2005...
  • Page 4 Check all hoses and wires to make sure they are secure. 18. Test washer. Page 4 of 4 TDL-0050B-B © 2005 Maytag Services 9/30/2005 ITDL-0020A-B...
