305
Clamp Meter
Users Manual
PN 4045148
June 2012, Rev.1, 12/13
© 2012, 2013 Fluke Corporation. All rights reserved. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 305 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fluke 305

  • Page 1 Clamp Meter Users Manual PN 4045148 June 2012, Rev.1, 12/13 © 2012, 2013 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
  • Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY This Fluke product will be free from defects in material and workmanship for two years from the date of purchase. This warranty does not cover fuses, disposable batteries, or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
  • Page 3: Table Of Contents

    Table of Contents Title Page Introduction ......................... 1 How to Contact Fluke ....................1 Safety Information ...................... 2 How to Clean the Product ..................8 Specifications ......................9 Electrical Specifications ..................9 Mechanical Specifications ..................10 Environmental Specifications ................10...
  • Page 4 Users Manual...
  • Page 5: Introduction

    Introduction The Fluke 305 Clamp Meter (the Product) measures ac and dc voltage, ac current, resistance, and continuity. Warning Read "Safety Information" before you use the Product. How to Contact Fluke To contact Fluke, call one of the following telephone numbers: •...
  • Page 6: Safety Information

    Users Manual Or, visit Fluke's website at www.fluke.com. To register your product, visit http://register.fluke.com. To see, print, or download the latest manual supplement, visit http://us.fluke.com/usen/support/manuals. Safety Information A Warning identifies conditions and procedures that are dangerous to the user. A Caution identifies conditions and procedures that could cause damage to the Product or the equipment under test.
  • Page 7 Clamp Meter Safety Information • Hold the Product behind the tactile barrier. See The Clamp Meter item ①. • Do not use test leads if they are damaged. Examine the test leads for damaged insulation or exposed metal. Check test lead continuity. •...
  • Page 8 Users Manual • Measure a known voltage first to make sure that the Product operates correctly. • Use only probes, test leads, and adapters supplied with the Product. • Remove all probes, test leads, and accessories that are not necessary for the measurement.
  • Page 9 Clamp Meter Safety Information • Do not use the Product if it is damaged. • Do not use the Product if it operates incorrectly. • Before each use, examine the Product. Look for cracks or missing pieces of the clamp housing. Also look for loose or weakened components.
  • Page 10 WEEE Directive Annex I, this product is classed as category 9 "Monitoring and Control Instrumentation" product. Do not dispose of this product as unsorted municipal waste. Go to Fluke’s website for recycling information.
  • Page 11 Clamp Meter Safety Information Table 1. Symbols (cont) Symbol Meaning Symbol Meaning MEASUREMENT CATEGORY II is MEASUREMENT applicable to test and measuring CATEGORY III is applicable circuits connected directly to utilization to test and measuring circuits CAT II CAT III connected to the distribution points (socket outlets and similar part of the building’s low-...
  • Page 12: How To Clean The Product

    Users Manual Note The Measurement Category (CAT) and voltage rating of combinations of test probes, test probe accessories, current clamp accessories, and the Product is the LOWEST rating of individual components. How to Clean the Product Regularly wipe the case with a damp cloth and mild detergent. ...
  • Page 13: Specifications

    Clamp Meter Specifications Specifications Electrical Specifications AC Current (Jaw) Range ............. 999.9 A Resolution ..........0.1 A Accuracy ..........1.5 % ±5 digits (45 Hz to 400 Hz) Note Add 2 % for position sensitivity. AC Voltage Range ............ 600.0 V Resolution ..........
  • Page 14: Mechanical Specifications

    Users Manual Resolution ..........0.1 Ω/1 Ω Accuracy ..........1 % ±5 digits Continuity Beeper........≤70 Ω Mechanical Specifications Size (L x W x H) ........(207 x 75 x 34) mm Weight ............. 205 g Environmental Specifications Operating Temperature ......0 °C to +40 °C Storage Temp .........
  • Page 15 Clamp Meter Specifications Electromagnetic Compatibility ....Applies to use in Korea only. Class A Equipment (Industrial Broadcasting & Communication Equipment) This product meets requirements for industrial (Class A) electromagnetic wave equipment and the seller or user should take notice of it. This equipment is intended for use in business environments and is not to be used in homes.
  • Page 16: The Clamp Meter

    Users Manual The Clamp Meter gqg008.eps...
  • Page 17 Clamp Meter The Clamp Meter gqg001.eps...
  • Page 18 Users Manual 2:00 HOLD 2:00 gqg002.eps...
  • Page 19 Clamp Meter The Clamp Meter 600 V 600 V 300 V 300 V CLAMP METER CLAMP METER 600 V 600 V 300 V 300 V gqg003.eps...
  • Page 20 Users Manual >30 V CLAMP METER 600 V 300 V gqg004.eps...
  • Page 21 Clamp Meter The Clamp Meter CLAMP METER CLAMP METER 600 V 600 V 300 V 300 V < 70 gqg005.eps...
  • Page 22 Users Manual HOLD > 30 V 20 V gqg006.eps...
  • Page 23 Clamp Meter The Clamp Meter gqg007.eps...
  • Page 24 Users Manual...
