StorNext G300 Gateway
Appliance Site Planning
Product Overview
The StorNext G300 Gateway Appliance combines industry-proven
Quantum hardware and StorNext software into one convenient, out-of-
the-box solution. Your StorNext G300 system software has been pre-
installed and is ready to operate with a minimum of additional
configuration required at time of installation. This guide provides an
overview of site characteristics, physical requirements, and environmental
specifications essential for the installation of the StorNext G300 Gateway
Appliance.
Note: Make sure to take the online training for the StorNext G300
Gateway Appliance in order to make the best use of your product.
The online training is available at
ServiceandSupport/StorageCareLearning/Index.aspx
Guide
www.quantum.com/
G300 Gateway Appliance
Contents
Product Overview................................... 1
Gateway Appliance ................................ 2
Installation Requirements...................... 2
Rack Compatibility ............................. 2
Setup .................................................. 2
Hardware Description ............................ 3
Service .................................................... 6
Warranty ............................................ 6
Service Package Upgrades ................. 6
StorNext G300 Specifications ................ 7
EMI Certification ................................ 7
Physical Characteristics...................... 7
Environmental Specifications ............ 9
Quantum Customer Suport ................. 10
www.quantum.com
Advertisement
Table of Contents
Related Manuals for Quantum StorNext G300
Summary of Contents for Quantum StorNext G300
-
Page 1: Table Of Contents
StorNext G300 Gateway Appliance. Note: Make sure to take the online training for the StorNext G300 Gateway Appliance in order to make the best use of your product. The online training is available at www.quantum.com/... -
Page 2: Included With Your Stornext G300 Gateway Appliance
G300 Gateway Appliance Site Planning Guide Included With Your StorNext G300 Gateway Appliance The StorNext G300 Gateway Appliance is fully configured to your specifications and pre- tested in the factory. Every StorNext G300 Gateway Appliance configuration arrives with all necessary parts included. Each system comes with an accessory kit containing rack- mount hardware and ships with StorNext G300 Gateway software installed from the factory. -
Page 3: Hardware Description
G300 Gateway Appliance Hardware Description The StorNext G300 Gateway Appliance ships with two 3.5” 500GB 7.2K RPM SATA hard disk drives (HDD) in a 1+1 RAID 1 configuration for the G300 platform software. StorNext G300 Gateway servers include the following components: •... - Page 4 Number Number Location Port Function Network Bonds eth0 Embedded Reserved for Port 1 Quantum Service eth1 Embedded LAN Client Network Bond 1 – This port can be Port 2 (1 GbE) bonded alongside the other LAN client ports (Eth6 - Eth11) or configured as a standalone port.
- Page 5 G300 Gateway Appliance bonded (bond1) or configured as individual network interfaces (see Table 2 on page 5 for port descriptions). Figure 2 on page 5 to view port assignments (ethernet ports denoted in yellow) and (fiber channel ports denoted in green) for the G302 Gateway Appliance. Figure 2 G302 Port Numbers Table 2 G302 Network Ports Physical...
-
Page 6: Service
Bronze Support Plan. This includes next business day on-site response, 5x9 telephone support, and on-line resources. This warranty covers the StorNext G300 gateway Appliance and all drives, and includes firmware downloads, telephone support, and Internet access to Quantum’s online Customer Support web site. -
Page 7: Stornext G300 Shipping Information
1 StorNext G301 69.3 lbs (31.4 kg) 1 StorNext G302 64.6 lbs (29.3 kg) StorNext G300 Specifications This section lists characteristics and specifications of the StorNext G300 Gateway Appliance. These characteristics and specifications are categorized as follows: • EMI Certification •... - Page 8 Maximum Operating BTUs 825 BTU/hr Caution: To safeguard continuous operations in the event of a power outage, Quantum recommends that you connect the StorNext G300 gateway appliance to a UPS (uninterruptable power supply). Two circuits should be used (one per power supply).
-
Page 9: Environmental Specifications
G300 Gateway Appliance Environmental Table 7 provides various StorNext G300 gateway appliance environmental specifications. Specifications Table 7 Environmental Specifications Climatic Environment Temperature and Altitude Operating 10 to 35°C (50 to 95°F) with a maximum temperature gradation of 10°C per hour Note: 35 °C (95 °F) is the maximum temperature for the... -
Page 10: Quantum Customer Suport
©2015 Quantum Corporation. All rights reserved. Quantum and the Quantum logo are registered trademarks of Quantum Corporation and its affliates in the United States and/or other countries. All other trademarks are the property of their respective owners. Protected by Pending and Issued U.S.
