Before Use
• INFORMATION ........................................................................................................ E-2
• CHECKING ACCESSORIES ................................................................................... E-3
• INSTALLATION ........................................................................................................ E-4
Others
• OPTIONS ................................................................................................................. E-5
• SPECIFICATION ...................................................................................................... E-6
Before using the display, read this manual carefully so that you know how to use the display correctly.
Refer to this manual whenever questions or problems about operation arise. Be sure to read and observe the safety
precautions (see the separate "Safety Precautions" manual).
Keep this manual where the user can see it easily.
* Installation and removal require special expertise. Consult your product dealer for details.
* When "English" is selected at "Language" of the on-screen display, "colour" will be displayed in the case of the E model and
"color" will be displayed for all other models.
The notation used in this user's manual is "color".
* The last digit of MODEL NO. (10 digit alphanumeric characters) indicated on the product means the body color indication
alphabet or the management number.
Contents
USER'S MANUAL
WIDE PLASMA DISPLAY
P42VHA40E
P42VHA40Z
Page
Advertisement
Related Manuals for Fujitsu PlasmaVision P42VHA40E
Summary of Contents for Fujitsu PlasmaVision P42VHA40E
-
Page 1: Table Of Contents
USER’S MANUAL WIDE PLASMA DISPLAY P42VHA40E P42VHA40Z Contents Page Before Use • INFORMATION ......................E-2 • CHECKING ACCESSORIES ................... E-3 • INSTALLATION ......................E-4 Others • OPTIONS ......................... E-5 • SPECIFICATION ...................... E-6 Before using the display, read this manual carefully so that you know how to use the display correctly. Refer to this manual whenever questions or problems about operation arise. -
Page 2: Information
INFORMATION • Receptacle Make sure that the power cable’s grounding wire is grounded. The display comes with a 3-prong power plug; one prong is connected to the grounding wire. If you have only a 2-hole receptacle, you will need to have it replaced. Contact your dealer for more information. •... -
Page 3: Checking Accessories
CHECKING ACCESSORIES Display Section Two AA batteries One power cable Two user's manuals One ferrite core One remote control Manual Manual No.:SFT-72SN Mfr.:TKK CONNECTING THE DISPLAY TO EXTERNAL EQUIPMENT Carefully check the terminals for position and type before making any connections. Loose connectors can result in picture or color problems. -
Page 4: Installation
INSTALLATION To prevent the display's internal components from overheating, make sure that the display is installed in a well-ventilated location. Be sure to use the optional stand, wall-mounting unit or the other unit when installing the display. Also, be also sure that your dealer performs the installation. -
Page 5: Options
To prevent injury, fire, and electric shock, arrange for options to be initially installed (or installed at a different location) by your dealer. CAUTION This display (P42VHA40) is for use only with Fujitsu General Limited's option (P-WB4201, P-CT4200, P-TT4202). Using this display with other option can cause instability resulting in possible injury. -
Page 6: Specification
• Viewing the screen constantly for extended periods can strain your eyes. Be sure to stay at a proper distance (at least 1.5 m or 5 feet for 42”) from the screen and to look occasionally away while working. • is a worldwide trademark of Fujitsu General Limited and is a registered trademark in Japan, the U.S.A. and other countries or areas.
