SC TERMINALI OPERATORE UNIVERSALI
SC UNIVERSAL OPERATOR TERMINALS
SC TERMINAUX OPERATEURS UNIVERSELS
SC UNIVERSELLE BEDIENTERMINALS
SC TERMINALES DE OPERADOR UNIVERSALES
SC 通用操作终端
Dimensioni - Forature / Dimensions - Holes / Dimensions - Trous / Abmessungen -
Bohrungen / Dimensiones y perforaciones / 外观尺寸-开孔尺寸
SC110A - SC210A
Rev. 0
Date: 31/10/2012
29015.840.050
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ESA SC210A
Summary of Contents for ESA SC210A
- Page 1 SC TERMINAUX OPERATEURS UNIVERSELS SC UNIVERSELLE BEDIENTERMINALS SC TERMINALES DE OPERADOR UNIVERSALES SC 通用操作终端 Dimensioni - Forature / Dimensions - Holes / Dimensions - Trous / Abmessungen - Bohrungen / Dimensiones y perforaciones / 外观尺寸-开孔尺寸 SC110A - SC210A Rev. 0 Date: 31/10/2012 29015.840.050...
- Page 2 Posteriore / Rear side / Face arrières / Rückseite / Posterior / 背部面板 SC110A – SC210A Connettore di alimentazione USB-B Power supply connector Porta seriale per il trasferimento del progetto Connecteur d'alimentation Serial port to transfer the project Anschluß für die Spannungsversorgung Port sériel pour le transfert du projet...
- Page 3 Alimentazione / Power supply / Alimentation / Spannungsversorgung / Alimentación / 供电 Power supply 4 pins connector +L 24 VDC M 0 V Not connected PE Protective ground Attenzione: Queste due configurazioni danneggiano gravemente il SC. Warning: These two configuration will seriously +24V damage components.
- Page 4 / Mettre au rebut les batteries usagées conformément aux lois en vigueur. / Entsorgen Sie die gebrauchten Batterien gemäß den örtlichen Umweltschutzbestimmungen. / Deseche las baterías utilizadas de acuerdo con las normas locales. / 根据当地法规处理使用过的电池。 ESA elettronica S.p.A. Via Padre Masciadri, 4/A I – 22066 Mariano Comense (CO) Tel.
