  • Page 3 Preface Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. Version 1.0b Disclaimer The information in this document is subject to change without notice.
  • Page 4 Declaration of Conformity This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation. Canadian Department of Communications This class B digital apparatus meets all requirements of the Canadian Interference-causing Equipment Regulations.

  • Page 5: Table Of Contents

    T T T T T ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS Preface Chapter 1 Introducing the Motherboard Introduction....................1 Features.......................2 Motherboard Components...............4 Chapter 2 7 7 7 7 7 Installing the Motherboard Safety Precautions..................7 Choosing a Computer Case...............7 Installing the Motherboard in a Case............7...
  • Page 6 Integrated Peripherals..............32 Power Management Setup............36 PNP/PCI Configurations.............38 PC Health Status................39 Load Performance...............40 Load Optimized Defaults.............40 Set Supervisor/User Password............40 Save & Exit Setup Option.............41 Exit Without Saving..............41 Chapter 4 43 43 43 43 Using the Motherboard Software About the Software CD-ROM..............43 Auto-installing under Windows 2000/XP..........43 Running Setup................44 Manual Installation..................46...

  • Page 7: Introducing The Motherboard

    Chapter 1 Introducing the Motherboard Introduction Thank you for choosing the NFORCE4-A939 motherboard. This motherboard is a high performance, enhanced function motherboard that supports Socket 939 AMD Sempron/ Athlon 64/Athlon 64 FX/Athlon 64 X2 CPUs for high-end business or personal desktop markets.

  • Page 8: Features

    Feature Processor This motherboard uses a 939-pin socket that carries the following features: • Accommodates AMD Sempron/Athlon 64/Athlon 64 FX/Athlon 64 X2 proces- sors • Supports up to 2000 MT/s HyperTransport (HT) interface Speeds HyperTransport Technology is a point-to-point link between two devices, it enables integrated circuits to exchange information at much higher speeds than currently avail- able interconnect technologies.
  • Page 9 Onboard LAN (optional) The onboard LAN provides the following features: • 10/100/1000BASE-T IEEE 802.3 compliant • Supports GMII, TBI, reduced pin count GMII (RGMII), reduced pin count TBI (RTBI), and serial GMII (SGMII) interfaces • IEEE 802.3u compliant Auto-Negotiation • Prevents outgoing packets with spoofed IP source addresses and pro- vides logging/configuration capabilities Integrated I/O...

  • Page 10: Motherboard Components

    Motherboard Components Introducing the Motherboard...
  • Page 11 Table of Motherboard Components LABEL COMPONENT 1 CPU Socket Socket 939 for AMD K8 processor 2 CPUFAN1 CPU cooling fan connector 3 DIMM1~4 184-pin DDR SDRAM slots 4 ATX1 Standard 24-pin ATX power connector 5 IDE2 Secondary IDE connector 6 IDE1 Primary IDE connector 7 NBFAN1 Northbridge cooling fan connector...
  • Page 12 Memo Introducing the Motherboard...

  • Page 13: Installing The Motherboard

    Chapter 2 Installing the Motherboard Safety Precautions • Follow these safety precautions when installing the motherboard • Wear a grounding strap attached to a grounded device to avoid damage from static electricity • Discharge static electricity by touching the metal case of a safely grounded object before working on the motherboard •...

  • Page 14: Checking Jumper Settings

    Do not over-tighten the screws as this can stress the motherboard. Checking Jumper Settings This section explains how to set jumpers for correct configuration of the motherboard. Setting Jumpers Use the motherboard jumpers to set system configuration options. Jumpers with more than one pin are numbered.

  • Page 15: Checking Jumper Settings

    Checking Jumper Settings The following illustration shows the location of the motherboard jumpers. Pin 1 is labeled. Jumper Settings Jumper Type Description Setting (default) 3-pin CLEAR CMOS 1-2: NORMAL 2-3: CLEAR Before clearing the CMOS, make sure to turn the system off. 3-pin BIOS PROTECT 1-2: DISABLE...

  • Page 16: Connecting Case Components

    Connecting Case Components After you have installed the motherboard into a case, you can begin con- necting the motherboard components. Refer to the following: Connect the CPU cooling fan cable to CPUFAN1. Connect the case cooling fan connector to CASFAN1. Connect the Northbridge cooling fan connector to NBFAN1.
  • Page 17 CPUFAN1/CASFAN1/NBFAN1: FAN Power Connectors Signal Name System Ground +12V Power +12V Sense Sensor SJ1: Single-color LED header Signal Name ACPI LED Signal Name ACPI LED 5VSB ACPI LED function S4/S5 Light Blinking Blinking Dark ATX1: ATX 24-pin Power Connector Signal Name Signal Name +3.3V +3.3V...

  • Page 18: Front Panel Header

    Front Panel Header The front panel header (PANEL1) provides a standard set of switch and LED headers commonly found on ATX or Micro ATX cases. Refer to the table below for information: Signal Name Function Signal Name Function HD_LED_P Hard disk LED+ FP PWR/SLP *MSG LED+ HD_LED_N...
  • Page 19 On most motherboards, there are small surface-mount resistors near the processor socket, which may be damaged if the cooling fan is carelessly installed. Avoid using cooling fans with sharp edges on the fan casing and the clips. Also, install the cooling fan in a well-lit work area so that you can clearly see the motherboard and processor socket.

  • Page 20: Installing Memory Modules

    Installing Memory Modules This motherboard accommodates four 184-pin unbuffered DIMM and supports DDR400/ 333/266/200 DDR SDRAM. You must install at least one module in any of the four slots. Each module can be installed with 256 MB to 1 GB of memory; the total memory capacity is 4 GB.
  • Page 21 Table A: Unbuffered DIMM Support for 939-pin Maximum Chip Selects Data DRAM Speed MEMCS_1L_L* MEMCS_2H_L* MEMCS_2L_L* MEMCS_2H_L* DDR400 DDR400 Single rank DDR400 DDR400 Double rank DDR400 DDR400 Single rank DDR400 DDR400 Double rank DDR333 DDR400 Single rank Single rank bits DDR200 DDR400 Single rank Double rank...

  • Page 22: Installing A Hard Disk Drive/Cd-Rom/Sata Hard Drive

    Installing a Hard Disk Drive/CD-ROM/SATA Hard Drive This section describes how to install IDE devices such as a hard disk drive and a CD-ROM drive. About IDE Devices Your motherboard has a primary and secondary IDE channel interface (IDE1 and IDE2). An IDE ribbon cable supporting two IDE devices is bundled with the motherboard.
  • Page 23 About SATA Connectors Your motherboard features two SATA connectors supporting a total of two drives. SATA refers to Serial ATA (Advanced Technology Attachment) is the standard interface for the IDE hard drives which are currently used in most PCs. These connectors are well designed and will only fit in one orientation.

  • Page 24: Installing A Floppy Diskette Drive

    Installing a Floppy Diskette Drive The motherboard has a floppy diskette drive (FDD1) interface and ships with a diskette drive ribbon cable that supports one or two floppy diskette drives. You can install a 5.25- inch drive and a 3.5-inch drive with various capacities. The floppy diskette drive cable has one type of connector for a 5.25-inch drive and another type of connector for a 3.5-inch drive.
  • Page 25 PCIE x1 Slots The two PCI Express x1 slots are fully compliant to the PCI Express Base Specification revision 1.0a as well. PCIE x16 Slot The PCI Express x16 slot is used to install an external PCI Express graphics card that is fully compliant to the PCI Express Base Specifica- tion revision 1.0a.

  • Page 26: Connecting Optional Devices

    Connecting Optional Devices Refer to the following for information on connecting the motherboard’s optional devices: AUDIO1: Front Panel Audio header This header allows the user to install auxiliary front-oriented microphone and line-out ports for easier access. Signal Name Signal Name Function AUD_MIC Front Panel Microphone input signal...
  • Page 27 SATA1~SATA4: Serial ATA connectors These connectors are use to support the new Serial ATA devices for the highest date transfer rates (150 MB/s), simpler disk drive cabling and easier PC assembly. It eliminates limitations of the current Parallel ATA interface. But maintains register compatibility and software compatibility with Parallel ATA.

  • Page 28: Connecting I/O Devices

    Connecting I/O Devices The backplane of the motherboard has the following I/O ports: PS2 Mouse Use the upper PS/2 port to connect a PS/2 pointing device. PS2 Keyboard Use the lower PS/2 port to connect a PS/2 keyboard. Parallel Port (LPT1) Use LPT1 to connect printers or other parallel communications devices.

  • Page 29: Using Bios

    Chapter 3 Using BIOS About the Setup Utility The computer uses the latest Award BIOS with support for Windows Plug and Play. The CMOS chip on the motherboard contains the ROM setup instructions for configuring the motherboard BIOS. The BIOS (Basic Input and Output System) Setup Utility displays the system’s configura- tion status and provides you with options to set system parameters.
  • Page 30 Press DEL to enter SETUP Pressing the delete key accesses the BIOS Setup Utility: Phoenix-AwardBIOS CMOS Setup Utility: Standard CMOS Features Load Performance Advanced BIOS Features Load Optimized Defaults Advanced Chipset Features Set Supervisor Password Integrated Peripherals Set User Password Save &...

  • Page 31: Updating The Bios

    Updating the BIOS You can download and install updated BIOS for this motherboard from the manufacturer’s Web site. New BIOS provides support for new peripherals, improvements in performance, or fixes for known bugs. Install new BIOS as follows: If your motherboard has a BIOS protection jumper, change the setting to allow BIOS flashing.

  • Page 32: Standard Cmos Features

    Standard CMOS Features This option displays basic information about your system. Phoenix-AwardBIOS CMOS Setup Utility Standard CMOS Features Date (mm:dd:yy) Wed, Oct. 25 2004 Item Help Time (hh:mm:ss) 9 : 33 : 26 IDE Channel 0 Master [WDC WD800bb-22FJA0] Menu Level IDE Channel 0 Slave [None] IDE Channel 1 Master...
  • Page 33 If you are setting up a new hard disk drive that supports LBA mode, more than one line will appear in the parameter box. Choose the line that lists LBA for an LBA drive. IDE Channel 0/1/2/3/4/5 Master & IDE Channel 0/1 Slave Leave this item at Auto to enable the system to automatically detect and configure IDE devices on the channel.

  • Page 34: Advanced Bios Features

    Advanced BIOS Features This option defines advanced information about your system. Phoenix-AwardBIOS CMOS Setup Utility Advanced BIOS Features Hard Disk Boot Priority [Press Enter] Item Help CPU Internal Cache [Enabled] External Cache [Enabled] Menu Level Quick Power On Self Test [Enabled] First Boot Device [Floppy]...
  • Page 35 First/Second/Third Boot Device (Floppy/Hard Disk/CDROM) Use these three items to select the priority and order of the devices that your system searches for an operating system at start-up time. Boot Other Device (Enabled) When enabled, the system searches all other possible locations for an operating system if it fails to find one in the devices specified under the First, Second, and Third boot devices.

  • Page 36: Advanced Chipset Features

    Summary Screen Show ( Enabled) This item determines whether the summary system information will be showed during boot- Advanced Chipset Features These items define critical timing parameters of the motherboard. You should leave the items on this page at their default values unless you are very familiar with the technical specifications of your system hardware.
  • Page 37 Timing Mode (Auto) This item enables you to specify the DRAm timing mode to be configured automatically or manually. • Memclock index value (Mhz) (200Mhz): When DDR Timing Setting by is set to Manual, use this item to set the DRAM frequency. •...

  • Page 38: Integrated Peripherals

    Integrated Peripherals These options display items that define the operation of peripheral components on the system’s input/output ports. Phoenix-AwardBIOS CMOS Setup Utility Integrated Peripherals IDE Function Setup [Press Enter] Item Help RAID Config [Press Enter] Onboard Device [Press Enter] Menu Level Super IO Device [Press Enter] : Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help...
  • Page 39 IDE DMA transfer access (Enabled) This item allows you to enable the transfer access of the IDE DMA then burst onto the PCI bus and nonburstable transactions do not. Serial-ATA 1/2 (Enabled) This item allows you to enable or disable the onboard SATA 1/2 devices. IDE Prefetch Mode (Enabled) The onboard IDE drive interface supports IDE prefetching, for faster drive access.
  • Page 40 Onboard Device (Press Enter) Scroll to this item and press <Enter> to view the following screen: Phoenix-AwardBIOS CMOS Setup Utility Onboard Device Item Help Init Display First [PCI Slot] OnChip USB [V1.1+V2.0V] USB Keyboard Support [Enabled] Menu Level USB Mouse Support [Enabled] AC97 Audio [Auto]...
  • Page 41 SuperIO Device (Press Enter) Scroll to this item and press <Enter> to view the following screen: Phoenix-AwardBIOS CMOS Setup Utility SuperIO Device Onboard FDC Controller [Enabled] Item Help Onboard Serial Port 1 [3F8/IRQ4] Onboard Serial Port 2 [2F8/IRQ3] Menu Level UART Mode Select [IRDA] UR2 Duplex Mode...

  • Page 42: Power Management Setup

    Power Management Setup This option lets you control system power management. The system has various power- saving modes including powering down the hard disk, turning off the video, suspending to RAM, and software power down that allows the system to be automatically resumed by certain events.
  • Page 43 Power On By Keyboard (Disabled) Enable or disable the function of waking up the system by the keyboard activity. • KB Power ON Password (Enter):Use this item to decide whether to enter the password when waking from keyboard. • Hot Key Power ON (Ctrl+F1): Use this item to allocate the hot key to wake up the system.

  • Page 44: Pnp/Pci Configurations

    PNP/PCI Configurations These options configure how PnP (Plug and Play) and PCI expansion cards operate in your system. Both the the ISA and PCI buses on the motherboard use system IRQs (Interrup ReQuests) and DMAs (Direct Memory Access). You must set up the IRQ and DMA assignments correctly through the PnP/PCI Configurations Setup utility for the motherboard to work properly.

  • Page 45: Pc Health Status

    PC Health Status On motherboards that support hardware monitoring, this item lets you monitor the parameters for critical voltages, temperatures and fan speeds. Phoenix-AwardBIOS CMOS Setup Utility PC Health Status Shutdown Temperature [Disabled] Item Help CPU Vcore Voltage Vcc 3V 3.31V Menu Level Vcc 2.5V...

  • Page 46: Load Performance

    Load Performance This option opens a dialog box that lets you install performance defaults for all appropriate items in the Setup Utility: Press <Y> and the <Enter> to install the defaults. Press <N> and then <Enter> to not install the defaults. If you want to make your system for greater effectiveness, then install the performance defaults.

  • Page 47: Save & Exit Setup Option

    Save & Exit Setup Highlight this item and press <Enter> to save the changes that you have made in the Setup Utility and exit the Setup Utility. When the Save and Exit dialog box appears, press <Y> to save and exit, or press <N> to return to the main menu. Exit Without Saving Highlight this item and press <Enter>...
  • Page 48 Memo Using BIOS...

  • Page 49: Using The Motherboard Software

    Chapter 4 Using the Motherboard Software About the Software CD-ROM The support software CD-ROM that is included in the motherboard package contains all the drivers and utility programs needed to properly run the bundled products. Below you can find a brief description of each software program, and the location for your motherboard version.

  • Page 50: Running Setup

    Setup Tab Setup Click the Setup button to run the software installation program. Select from the menu which software you want to install. Browse CD The Browse CD button is the standard Windows command that allows you to open Windows Explorer and show the contents of the support Before installing the software from Windows Explorer, look for a file named README.TXT, INSTALL.TXT or something similar.
  • Page 51 Click Next. The following screen appears: Check the box next to the items you want to install. The default options are recommended. Click Next run the Installation Wizard. An item installation screen appears: Follow the instructions on the screen to install the items. Drivers and software are automatically installed in sequence.

  • Page 52: Manual Installation

    Manual Installation Insert the CD in the CD-ROM drive and locate the PATH.DOC file in the root directory. This file contains the information needed to locate the drivers for your motherboard. Look for the chipset and motherboard model; then browse to the directory and path to begin installing the drivers.
  • Page 53 Caractéristiques Processeur Cette carte mère utilise un socket de 939 broches ayant les caractéristiques suivantes : • Reçoit les processeurs AMD Sempron/Athlon 64/Athlon 64 FX /Athlon 64 • Prend en charge des vitesses d’interface HyperTransport (HT) allant jusqu’à 2000MT/s La Technologie HyperTransport est une liaison point à...
  • Page 54 LAN interne (optionnel) Le LAN interne offre les caractéristiques suivantes: • Conforme 10/100/1000BASE-T IEEE 802.3 • Prend en charge les interfaces GMII, TBI, comptage de broches réduit GMII (RGMII), comptage de broches réduit TBI (RTBI), et série GMII (SGMII) • Auto-Négotiation conforme IEEE 802.3u •...
  • Page 55 Feature Prozessor Dieses Motherboard verwendet einen 939-Pin Socket mit den folgenden Eigenschaften: • Nimmt AMD Sempron/Athlon 64/Athlon 64 FX/Athlon 64 X2 Prozessoren • Unterstützt bis zu 2000MT/s HyperTransport (HT) Interface- Geschwindigkeiten HyperTransport Technologie ist ein Punkt-zu-Punkt Link zwischen zwei Geräten. Es ermöglicht integrierten Schaltkreisen einen Informationsaustausch mit wesentlich höherer Geschwindigkeit als bei gängigen Interconnect-Technologien.
  • Page 56 Integriertes LAN (optional) Das integrierte LAN bietet folgende Features: • Entspricht 10/100/1000BASE-T IEEE 802.3 • Unterstützt GMII, TBI, Reduced Pin-Count GMII (RGMII), Reduced Pin- Count TBI (RTBI) und serielle GMII (SGMII) Interfaces • Auto-Negotiation gemäß IEEE 802.3u • Verhindert das Aussenden von Datenpaketen mit gespooften IP- Herkunftsadressen und bietet Protokoll-/Konfigurationsfähigkeiten Integrierte I/O-Schnittstellen Das Motherboard verfügt über einen kompletten Satz von I/O-Schnittstellen und Anschlüssen:...
  • Page 57 Caratteristiche Processore La scheda madre utilizza una presa a 939 pin che offre le seguenti caratteristiche: • Compatibilità con processori AMD Sempron/Athlon 64/Athlon 64 FX/ Athlon 64 X2 • Supporto di velocità di interfaccia HyperTransport (HT) fino a 2000 MT/s La tecnologia HyperTransport consente il collegamento point-to-point fra due dispositivi e quindi un trasferimento di informazioni tra circuiti integrati molto più...
  • Page 58 integrata (opzionale) La funzionalità LAN integrata sulla scheda offre le seguenti caratteristiche: • Conforme a IEEE 802.3 10/100/1000BASE-T • Supporto di interfacce GMII, TBI, GMII a ridotto numero di pin (RGMII), TBI a ridotto numero di pin (RTBI) e GMII seriali (SGMII) •...
  • Page 59 Característica Procesador Esta placa principal usa un zócalo de 939-pin que lleva las sigtes. características: • Acomoda procesadores AMD Sempron/Athlon 64/Athlon 64 FX/Athlon 64 • Soporta hasta las velocidades de interfaz 2000MT/s HyperTransport (HT) La Tecnología HyperTransport es un vínculo punto a punto entre dos dispositivos, habilita circuitos integrados para intercambiar la información en velocidades más rápidas que las tecnologías de interconexión disponibles actualmente.
  • Page 60 LAN Abordo (optativo) El LAN abordo provee las sigtes. características: • Conformidad 10/100/1000BASE-T IEEE 802.3 • Soporta GMII, TBI, GMII (RGMII) de cuenta de pin reducida, TBI (RTBI), e interfaces de GMII (SGMII) serial • Autonegociación con conformidad IEEE 802.3u •...
  • Page 61 Características Processador Esta motherboard usa uma ficha de 939 pin que possui as seguintes características: • Acomoda processadores AMD Sempron/Athlon64/Athlon 64 FX/Athlon64 • Suporta velocidades de interface de HyperTransportTM (HT) até 2000MT/ Tecnologia de HyperTransport Té um link ponto-a-ponto entre dois dispositivos, permite circuitos integrados para trocar informação a velocidades muito mais elevadas que as disponíveis actualmente em tecnologias de interconexão.
  • Page 62 Onboard LAN (opcional) O onboard LAN fornece as seguintes características: • Compatível com 10/100/1000BASE-T IEEE 802.3 • Suporta GMII, TBI, contagem reduzida de pinos GMII (RGMII), contagem reduzida de pinos TBI (RTBI), e interfaces de série GMII (SGMII) • Auto-Negociação compatível com IEEE 802.3u •...
  • Page 63 機能 プロセッサ このマザーボードには、次の機能を持った939ピンソケットが一つあります： • AMD Sempron/Athlon 64/Athlon 64 FX/Athlon 64 X2 プロセッサ取り 付け可能 • 転送率が最大2000MT/秒までの HyperTransport (HT)インターフェース を採用 HyperTransport 技術とは、二つのデバイスを1対1( point-to-point)で接続する技 術であり、従来のインターコネクト技術に比較して、集積回路同士の情報交換を高速化 します。 チップセット NVIDIA® CrushK8-04 (CK8-04) はシングルチップのもので、実証済みの信頼性と高 性能性を提供します。 • HyperTransport x16でAMD Sempron/Athlon 64/Athlon 64 FX/Athlon 64 X2 プロセッサとの1.0 GHzのアッププリンクとダウンリンクを実現 •...
  • Page 64 オンボードLAN (オプション) オンボードLANは、次の機能を提供します。 • 10/100/1000BASE-T IEEE 802.3に準拠 • GMII、TBI、reduced pin count GMII (RGMII)、reduced pin count TBI (RTBI)、およびシリアルGMII (SGMII) インターフェースに対応 • IEEE 802.3u 準拠の自動折衝機能を導入済み • 悪意なIPアドレスが含まれているパケットの出力や履歴の記録、構成の設定が 可能 統合の入出力ポート マザーボードには、次のI/Oポートやコネクタを揃えています。 • マウスとキーボード用のPS/2ポート x2 • シリアルポート x1 • パラレルポート x1 • USBポート x4 •...
  • Page 65 특성 프로세서 본 마더보드는 다음과 같은 특성을 지닌 939 핀 소켓을 사용합니다: • AMD 샘프론 애슬론 64/애슬론 64 FX/애슬론 64 X2 프로세서 사용 • HyperTransport (HT) 인터페이스 속도 최대 2000MT/s 지원 HyperTransport 기술은 두 장치간의 point-to-point 링크로, 집적 회로가 기존의 상호...
  • Page 66 보드 내장 LAN (선택 사항) 보드 내장 LAN 은 다음과 같은 특성이 있다: • 10/100/1000BASE-T IEEE 802.3 부합 • GMII, TBI, reduced pin count GMII (RGMII), reduced pin count TBI (RTBI), serial GMII (SGMII) 인터페이스 지원 • IEEE 802.3u 부합 Auto-Negotiation •...
  • Page 67 功能 處理器 本主機板配備具有如下功能的939針插槽: ‧ 適用於AMD Sempron/Athlon 64/Athlon 64 FX/Athlon 64 X2 處理器； ‧ 支援高達2000MT/秒的HyperTransport (HT)介面傳輸速率。 HyperTransport 技術為以點對點方式連接兩台設備的技術，藉此，積體電路間能夠以 後高於現有各種內部連接技術(interconnect technology)技術的速度來交換資訊。 晶片組 NVIDIA® CrushK8-04 (CK8-04)採單晶片設計，具有令人贊賞的可靠性及效能。 ‧ HyperTransport x16，其提供對AMD Sempron/Athlon 64/Athlon 64 FX/Athlon 64 處理器高達1.0GHz上行及下行連接； ‧ 2.3介面，其支援高達5個PCI插槽； ‧ 2個獨立的SATA 控制器，其具有整合型PHY，各自能夠支援2個master模式 的硬碟； ‧ 1000BASE-T/100BASE-T/10BASE-T的IEEE 802.3 NVIDIA MAC；...
  • Page 68 內建區域網路 (選購) 內建區域網路提供下列功能： ‧ 相容於10/100/1000BASE-T IEEE 802.3； ‧ 支援GMII、TBI、接腳精簡(reduced pin count)型GMII (RGMII)、接腳精簡型； TBI (RTBI)、及序列GMII (SGMII)介面； ‧ IEEE 802.3u相容自動交涉功能； ‧ 防止內含惡意IP位址的封包輸出，並提供履歷記錄/組態設定功能。 整合 I/O 主機板具有一組齊全的 I/O 連接埠及連接頭： • 2 個 PS/2 埠，供滑鼠與鍵盤使用； • 1 個串列埠； • 1 個平行埠； • 4 個USB埠； • 1 個區域網路埠(選購)； •...
  • Page 69 功能 处理器 主板使用一个 939-pin 插座，此插座具有以下特点： • 支持 AMD Sempron/Athlon 64/Athlon 64 FX/Athlon 64 X2 处理器 • 支持 2000MT/s HyperTransport (HT) 接口速度 HyperTransport 技术是一种在两台设备间进行点到点连接的技术，它可以让集成电 路使用比当前互连技术更高的速度进行信息交换。 芯片组 NVIDIA® CrushK8-04 (CK8-04) 是一种能提供高可靠性和高性能的单芯片。 • HyperTransport x16 技术，到 AMD Sempron/Athlon 64/Athlon 64 FX/Athlon 64 X2 处理器 的上行链路和下行链路带宽可达 1.0 GHz •...
  • Page 70 Onboard LAN（可选） 板上集成的 LAN 提供以下功能： • 符合 10/100/1000BASE-T IEEE 802.3 标准 • 支持 GMII、TBI、减引线数 GMII (RGMII)、减引线数 TBI (RTBI) 和串行 GMII (SGMII) 接口 • 符合 IEEE 802.3u 标准的自协商功能 • 防止带有欺骗性 IP 源地址的外出包，提供记录/配置功能 集成 I/O 此主板具有完整的 I/O 端口和插孔： • 2 个用于连接鼠标和键盘的 PS/2 端口 •...
  • Page 71 Характеристики Процессор Плата использует сокет 939-pin и обладает следующими характеристиками: • Размещает процессоры AMD Sempron/Athlon64/Athlon 64 FX/Athlon64 • Поддерживает технологию 2000MT/s HyperTransport (HT) Технология HyperTransport обеспечивает связь двух устройств по протоколу point- to-point, позволяя гораздо более быстрый обмен информацией между интегральными микросхемами, чем...
  • Page 72 Встроенный сетевой адаптер LAN (опционально) Встроенный сетевой адаптер LAN обладает следующими характеристиками: • Совместимость с технологией 10/100/1000BASE-T IEEE 802.3 • Поддержка интерфейсов GMII, TBI, RGMII, RTBI, a также серийного интерфейса SGMII • Совместимость с технологией IEEE 802.3u Auto-Negotiation • Предотвращает формирование фиктивных адресов IP выходящих пакетов...
  • Page 73 Cechy Procesor Ta płyta główna zaopatrzona jest w podstawkę dla procesorów z 939 nóżkami i charakteryzuje się następującymi cechami: • Przystosowany do obsługi procesorów Sempron/Athlon 64/Athlon 64 FX/ Athlon 64 X2 firmy AMD • Obsługuje złącze HyperTransport (HT) z szybkością do 2000MT/s Technologia HiperTransportu jest protokołem komunikacji między dwoma urządzeniami, który umożliwia układom zcalonym wymieniać...
  • Page 74 Zintegrowana obsługa sieci LAN (opcjonalnie) Zintegrowana obsługa sieci LAN posiada następujące właściwości: • Zgodne z IEEE 802.3 - 10/100/1000BASE-T • Obsługuje interfejsy: GMII, TBI, RGMII, RTBI i szeregowy SGMII. • Zgodny z IEEE 802.3u Auto-Negotiation • Zapobiega generowaniu fikcyjnych adresów IP żródła wychodzących pakietów i zapewnia możliwość...
  • Page 75 Vlastnosti Procesor Tato základní deska využívá 939kolíkovou patici nabízející následující vlastnosti: • Podpora procesoru AMD Sempron/Athlon 64/Athlon 64 FX/Athlon 64 X2 • Podpora rychlostí rozhraní HyperTransport (HT) až 2000 MT/s Technologie HyperTransport je přímým spojením mezi dvěma zařízeními, umožňující integrovaným obvodům výměnu informací vyššími rychlostmi, než jaké nabízejí současné technologie.
  • Page 76 Vestavění síťové rozhraní LAN (volitelně) Vestavěné síťové rozhraní LAN nabízí následující možnosti: • Podpora standardu 10/100/1000BASE-T IEEE 802.3 • Podpora GMII, TBI, GMII (RGMII) s redukovaným poètem kolíkù, TBI (RTBI) s redukovaným poètem kolíkù a sériové rozhraní GMII (SGMII) • Podpora IEEE 802.3u s automatickým vyjednáváním •...
  • Page 77 Caracteristici Procesorul Această placă de bază utilizează un soclu 939, având următoarele caracteristici: • Funcţionează cu procesoare AMD Sempron/Athlon64/Athlon 64 FX/ Athlon64 X2 • Suportă interfeţe HyperTransport (HT) cu viteze de până la 2000 MT/s Tehnologia HyperTransport este o legătură punct-la-punct între două aparate, care permite viteze mult mai mari de schimb al informaţiilor între circuitele integrate, decât cel asigurat de tehnologiile de interconectare actuale.
  • Page 78 Onboard LAN (opţional) Onboard LAN are următoarele caracteristici: • Compatibil cu 10/100/1000BASE-T IEEE 802.3 • Suport pentru GMII, TBI, GMII (RGMII) cu număr redus de ace, TBI (RTBI) cu număr redus de ace şi interfeţe seriale GMII (SGMII) • Auto-negociere compatibilă cu IEEE 802.3u •...
  • Page 79 Спецификация Процесор Тази дънна платка използва 939-щифтов цокъл (939-pin socket) със следните параметри: • Поддръжка на процесори AMD Sempron/Athlon 64/Athlon 64 FX/Athlon 64 X 2 • Поддръжка на технологията HyperTransport (HT) със скорост до 2000MT/s Технологията HyperTransport е връзка точка-до-точка (point-to-point) между две...
  • Page 80 Интегриран мрежов контролер (опция) Спецификация на интегрирания мрежов контролер: • Съвместимост с 10/100/1000BASE-T IEEE 802.3 • Поддръжка на интерфейси GMII, TBI, reduced pin count GMII (RGMII), reduced pin count TBI (RTBI), и serial GMII (SGMII) • Функция Auto-Negotiation съвместима със спецификацията IEEE 802.3u •...
  • Page 81 Jellemző Processzor Ez az alaplap 939 tűs foglalattal rendelkezik, ennek jellemzői pedig a következők: • AMD Sempron/Athlon 64/Athlon 64 FX/Athlon 64 X2 központi egységekkel működik • Maximum 2000 MT/s HyperTransport (HT) sebességű interfészt támogat A HyperTransport technológia egy ponttól pontig való kapcsolat két készülék között, és segítségével az integrált áramkörök közötti információcsere sebessége sokkal nagyobb, mint a jelenleg rendelkezésre álló...
  • Page 82 Alaplapon levő LAN (választható) Az alaplapon levő LAN jellemzői: • 10/100/1000BASE-T IEEE 802.3-vel kompatibilis • GMII, TBI, csökkentett tűszámú GMII (RGMII), csökkentett tűszámú TBI (RTBI) és soros GMII (SGMII) interfészek támogatása • IEEE 802.3u-val kompatibilis automatikus kezelő • Megakadályozza hamisított IP forráscímmel rendelkező csomagok kimenését és naplózási/konfigurálási lehetőségeket kínál Beépített I/O Az alaplapot az I/O portok és csatlakozók teljes készletével szerelték fel:...
